Inspection, Cleaning, and Storage Procedures for �M™ Versaflo™
PAPR TR-���, TR-����, and TR-���
Introduction
The 3M™ Versaflo™ TR-300, TR-300+, and TR-600 Powered Air Purifying Respirator (PAPR) assemblies are designed to be
used with certain 3M breathing tubes and headgear to form a complete respirator system.
Occupational use of respirators must be in compliance with applicable health and safety standards. By United States
regulation, employers must establish a written respirator protection program meeting the requirements of the Occupational
Safety and Health Administration (OSHA) Respiratory Protection standard 29 CFR 1910.134 and any applicable OSHA
substance specific standard. OSHA 1910.134 states that employers shall ensure that respirators are inspected, cleaned,
and properly stored.
This Technical Bulletin will review the 3M recommended cleaning procedures as well as inspection and storage guidelines
for the 3M™ TR-300, TR-300+, and TR-600 PAPR assemblies. Refer to the TR-300, TR-300+, and TR-600 PAPR User
Instructions as well as the User Instructions for your specific headgear for proper assembly, use and limitations of your
specific respirator system.

Inspection

The 3M™ TR-300, TR-300+, and TR-600 PAPR must be inspected before each use to ensure good operating condition.
Detach the belt, battery pack, breathing tube, headgear, filter cover, filter, and prefilter or spark arrestor/prefilter (if used)
from the motor/blower. If any damage, non-functionality, or signal observations as noted below are discovered during the
inspection, remove PAPR system from use and service or replace as appropriate. The 3M™ Versaflo™ TR-300, TR-300+,
and TR-600 Series Parts and Accessories exploded view posters may be helpful for identifying components
versaflo).

Motor/blower

: Except for removing the filter cover, filter/cartridge, high efficiency filter, and prefilter or prefilter/spark arrestor and
NOTE
filter latch assembly, the main housing of the motor/blower cannot be opened and has no user serviceable parts.
The filter cover must be intact with no cracks or other damage.
The main housing or case of the motor/blower unit must be intact with no cracks, holes, or other damage. The plastic
should not be discolored, chalky, or soft as these may be signs of deterioration of the housing.
The area of the motor/blower unit under the filter or filter/cartridge should be clean and free of contaminants. Contam-
ination noted here may indicate improper/lack of filter installation or damage to the filter or filter gasket.
The user interface (motor blower display) should be clean. All LED segments should be lit and clearly visible during initial
start-up of the motor/blower. Excessive build-up of materials on the display may mask a visual alarm from the wearer.
The ON/OFF switch should be intact with no cuts, tears or holes.
The filter release button should function smoothly and hold the filter or filter/cartridge securely onto the motor/blower.
The filter cover should sit securely onto the filter or filter/cartridge (if used for TR-600).
The outlet of the motor/blower (i.e. where the breathing tube attaches) should be inspected for any damage, dirt, debris,
or other contamination which may interfere with proper attachment of the breathing tube.
Technical Bulletin
August, 2020
Revision �
(3M.com/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Versaflo TR-300 and is the answer not in the manual?

Questions and answers

Summary of Contents for 3M Versaflo TR-300

  • Page 1 This Technical Bulletin will review the 3M recommended cleaning procedures as well as inspection and storage guidelines for the 3M™ TR-300, TR-300+, and TR-600 PAPR assemblies. Refer to the TR-300, TR-300+, and TR-600 PAPR User Instructions as well as the User Instructions for your specific headgear for proper assembly, use and limitations of your specific respirator system.
  • Page 2 • Check the low airflow alarm by fully covering the airflow outlet as described in the PAPR User Instructions or in Tech- nical Data Bulletin #221 – Conducting Airflow Check on the 3M™ Versaflo™ PAPR TR-600. Filters and Filter Accessories •...
  • Page 3 Attach the air inlet and air outlet cleaning and storage plugs (3M™ Cleaning and Storage Kit TR-653) into the TR-600 (see Fig 1). The TR-600 can now be rinsed under running water, submersed in water, or put in a respirator washer for...
  • Page 4 • If needed, the battery strap included with the 3M™ Cleaning and Storage Kit TR-653 can be used to protect the pads during cleaning. With the strap in place, the battery can now be rinsed under running water, immersed, or put in a respi- rator washer for further cleaning.
  • Page 5 • The 3M™ Easy Clean Belt TR-327/TR-627 is made of plastic buckles, vinyl urethane leads, and a hip belt with a non-porous outer material and closed cell foam inner material that can be wiped down or submersed in a soapy water solution.
  • Page 6 HE filter, prefilter, and spark arrestor/prefilter should be stored at temperatures and conditions similar to the motor/blower. Store the filter and spark arrestors in the original 3M packaging until ready for installation in the motor/blower. HE filters should not be stored long-term on the motor/blower as this may damage the filter gasket. HE filters have a shelf life of 5 years when stored in their original packaging.
  • Page 7 1:10 ratio of bleach to water (0.5% sodium hypochlorite) Hydrogen Peroxide – 30% 3M™ C Diff Disinfectant (EPA ID 71847-6) Clorox Healthcare Bleach Wipes (EPA ID 67619-12) - 0.55% Sodium Hypochlorite Clorox Healthcare Bleach Trigger Spray (EPA ID 56392-7) – 0.65% Sodium Hypochlorite Sani-Cloth®...
  • Page 8 Personal Safety Division In United States of America © 3M 2020. All rights reserved. Technical Service: 1-800-243-4630 3M and Versaflo are trademarks of 3M 3M Center, Building 235-2W-70 Customer Service: 1-800-328-1667 Company and affiliates. Used under St. Paul, MN 55144-1000 3M.com/workersafety...
