DANGER:
Instructions:
STEP 1:
Disconnect the power cord to the range. Turn off the gas at the gas supply
valve.
STEP 2:
Slide the range out from the cabinet.
STEP 3:
Remove the grates.
WARNING: Do not disassemble the range until it has cooled.
STEP 4:
Remove and retain the three (3) screws on the front of the existing backguard.
STEP 5:
Remove the two (2) top screws on the back of the side panels.
STEP 6:
Remove the existing backguard.
RANGE MODEL: ER30G
Backguard Kits
AERB30G03, AERB30G06, AERB30G09
Electric shock and explosion hazard! Before installation,
disconnect the power cord and shut off the gas supply
valve.
Continued on back...
Backguard height varies with kit
Backguard Removal
INSTALLATION
INSTRUCTIONS
Part No. 106191 Rev. B
