Summary of Contents for PlayAlive Wave
- Page 1 Installation manual Wave...
-
Page 2: Table Of Contents
Connecting the power cable Pulling devicenet cables Installation of satellites Installation of game controller Start up Turn the system on Start a game and test the setup Games included in Wave Wave games Appendix General introduction to PlayAlive’s technology platform... -
Page 3: Component Overview
P00256 1 x Game controller 6 x Satelite P00499 P00020 Steel components 1 x Wave left leg 4 x Wave middle pillar 1 x Wave right leg Other 8 x Hexagon bolt 18 x Countersunk screw 16 x Washer M10... -
Page 4: Construction
Overview of construction site The area for the placement of the wave should have a diameter of minimum 5.3 m. The Wave must have a power cable of 230V drawn to the middle pillar. Later in the installation process an electrician must be respon- sible for the connection, see section 4.1. -
Page 5: Assembling Wave
Casting the Wave Once the Wave has been assembled it is ready to be placed in the dug out holes and thereafter cast. Please note, that the Wave’s legs and middle pillar should be cast around 0.4 meters below the surface. -
Page 6: Installation Of Electronic Components
3. Take a new red PlayAlive cable and push it through the satellite hole in the middle of the left leg. Push it downwars and pull it out of the satellite hole at the bottom of the right leg. -
Page 7: Installation Of Satellites
Chogori Connector end plug. 3. The satelittes must be fixed to the Wave with 3 Countersunk M5 x 12 mm screws. The screws can be screwed into the Wave with just the use of ones fingers. Do not use force as it might cause cold welding. -
Page 8: Start Up
Please study the games in section 6.1 and test them out on the Wave. For questions please feel free to contact PlayAlive. holding the game con- troller and the satellites If the satellites aren’t working as stated, please see installationsteps... -
Page 9: Games Included In Wave
Games included in Wave Wave games Games will rotate so the Wave is always new and exciting. An example of a rotation of 4 games can be seen below. Agent In the game “Bloks,” players are challenged to match blocks of the same color with each other. -
Page 10: Appendix
You should also be careful when pulling cables during the installation. Please be aware that the PlayAlive cables are not designed to be pulled in the connector. Therefor when pulling the cables, please pull on the cable and not on the connector.
