LIGHT INC ERA SPOT-200 LED Manual

Dual overlapping prism, clear optic system, linear frost
Hide thumbs

Advertisement

Table of Contents

ERA SPOT-200 LED
MANUAL
DUAL OVERLAPPING
PRISM
CLEAR
OPTIC SYSTEM
LINEAR
FROST
www.light-inc.nl
MOVING HEAD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ERA SPOT-200 LED and is the answer not in the manual?

Questions and answers

Related Manuals for LIGHT INC ERA SPOT-200 LED

Summary of Contents for LIGHT INC ERA SPOT-200 LED

  • Page 1 MOVING HEAD ERA SPOT-200 LED MANUAL DUAL OVERLAPPING PRISM CLEAR OPTIC SYSTEM LINEAR FROST www.light-inc.nl...

  • Page 2: Safety Information

    THANK YOU FOR PURCHASING OUR PRODUCTS Every unit has been thoroughly tested and has been shipped in perfect operating condition. Carefully check the outer and inner packaging for damage that may have occurred during shipping. If the carton appears to be damaged, carefully inspect your fixture for any damage and be sure all accessories necessary to operate the unit have arrived intact.

  • Page 3: Installation

    2. INSTALLATION cord through the holes at the bottom of the base and around the truss. Rigging 1. Clamps 2. Safety wire 3. Omega holder 4. Quick-lock fastener 5. Attachment point WARNING: • • Power connection Connect the power cord as follows: WARNING: •...

  • Page 4: Setup And Configuration

    DMX terminator DMX terminator 3. SETUP AND CONFIGURATION 3. SETUP AND CONFIGURATION Front panel operation Front panel operation DMX Address: DMX Address: System Settings: System Settings:...
  • Page 5 1. Display reverse direction: 1. Display reverse direction: 2. Language setting: Set the system language, switch between Chinese and English 2. Language setting: Set the system language, switch between Chinese and English 3. Channel mode: Set the channel mode, the number of menu options indicates the number of channels 3.

  • Page 6: Operation Menu

    4. OPERATION MENU 1. Address setting, 2. Setting, 3. Info , 4. Manual, 5. Status, 6. 7. Reset, 8. Level 1 Level 2 Level 3 Level 4 Content Address Setting 1 - 512 Dis_Reve Natu/Rev1 Language Engh/Chin 14CH/16CH RunMode DimCurve Squa/Pres/SCur/Line SETTING ShortCut...
  • Page 7 Level 1 Level 1 Level 2 Level 2 Level 3 Level 3 Level 4 Level 4 Content Content Address Setting Address Setting 1 - 512 1 - 512 Natu/Err Natu/Err Effect DMX Effect DMX Natu/Err Natu/Err Focus Hall Focus Hall Natu/Err Natu/Err Color Hall...

  • Page 8: Dmx Protocol

    Level 1 Level 2 Level 3 Level 4 Content Address Setting 1 - 512 0-255 PanFine 0-255 Tilt 0-255 TiltFine 0-255 T-nonpolar 0-255 0-255 Strobe 0-255 Dimmer 0-255 DMX LEVEL Color 0-255 StaticGB 0-255 Prism 0-255 PrismRot1 0-255 PrismRot2 0-255 Frost 0-255 Focus...
  • Page 9 DMX Channel DMX Channel Value Function Value Function Short mode Standard mode Short mode Standard (14CH) (16CH) Mode Dimmer Strobe 0-255 0-100% Close Colors Strobe: Slow->Fast Open 104-107 Open 9-17 108-207 Pulse strobe: Slow->Fast 18-26 208-212 Open 27-35 Red + Dark Green Strobe at random: slow speed 36-44 Dark Green...

  • Page 10: Component Order Codes

    DMX Channel Value Function Short mode Standard mode (14CH) (16CH) Prism 2 0-63 Stop 64-255 Prism 2 in 6 Facet Linear Prism positioning and rotation 0-127 Prism positioning 128-190 Anti-clockwise rotation:Fast->Slow 191-192 Stop 193-255 Clockwise rotation:slow->fast Frost 0-63 Stop 64-255 0-100% Focus 0-255...

  • Page 11: Technical Data

    7. APPEARANCE Head Base 8. TECHNICAL DATA Electric parameters The specification of the light source Input voltage : 100V~240V AC, 50/60Hz Light Source: 200W White LED COB Input power: Color temperature: 300W@240V 7600K±200K Power factor : PF>0.90 Rated life: 20000hrs Color Fixed Gobo Wheel 1White light + 7 colors.
  • Page 12 Prism/frost Control • 1 6- facet linear prism and 1 8-facet prism • International standard DMX 512 protocol • bi-directional rotation from slow to fast • 3-pin interface • both can be overlapped • 14channels in short mode and 16channels in standard mode Focus Focus...

  • Page 13: Troubleshooting

    9. TROUBLE SHOOTING Problem Action Check the fuse on the power socket. Check the lamp. to the controller Make sure the fan is working well or fans and their shields are not blocked. Make sure the LED is within its lifespan. Beam appears dim, Low in brightness Remove dust or grease from the lenses.
  • Page 16 ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE BSL B.V. SPAARPOT 19 | 5667 KV GELDROP | THE NETHERLANDS | +31 (0)40 750 24 95 WWW.BSL-LIGHTING.COM | WWW.LIGHT-INC.EU...
