vc999 PACKAGING plus+ CM800 Operations & Parts Manual

Vacuum chamber machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CM800
VACUUM CHAMBER MACHINE
OPERATION & PARTS MANUAL
419 E. 11TH AVE. NORTH KANSAS CITY, MO 64116 USA
+1 800-728-2999
SALES@VC999.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PACKAGING plus+ CM800 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for vc999 PACKAGING plus+ CM800

Summary of Contents for vc999 PACKAGING plus+ CM800

  • Page 1 CM800 VACUUM CHAMBER MACHINE OPERATION & PARTS MANUAL 419 E. 11TH AVE. NORTH KANSAS CITY, MO 64116 USA +1 800-728-2999 SALES@VC999.COM...
  • Page 2 CM800 Chamber Machine Operation and Parts Manual 800 LR-FB-L Safe Operation Practices General Operation Read, understand, and follow all instructions in the manual and on the machine before starting. Keep this manual in a safe place for further and regular reference and for ordering replacement parts.

  • Page 3: Table Of Contents

    CM800 Chamber Machine Operation and Parts Manual Content Chapter 1 Safety precautions 1.1 Precautions of transportation, installation and packing 1.2 Precautions before and after machine starting Chapter 2 Overall description of the machine 2.1 Features of the machine 2.2 Function of the machine 2.3 Product proper for this machine 2.4 Usage life of the machine 2.5 Marking location and content description...
  • Page 4 CM800 Chamber Machine Operation and Parts Manual V1.01 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...

  • Page 5: Precautions Of Transportation, Installation And Packing

    CM800 Chamber Machine Operation and Parts Manual Chapter 1 Safety precautions 1.1 Precautions of transportation, installation and packing 1.1.1 Preparations before installation 1.1.1.1 Power requirement: Voltage: Look at the nameplate Current: Look at the nameplate Frequency: 50/60Hz Phase: 3Ø 1.1.1.2 Installation requirement 1.1.1.2.1 Prevent to install the machine in the environment full of dust and corrosive atmosphere with acid and alkali.
  • Page 6 CM800 Chamber Machine Operation and Parts Manual 800 FB 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 7 CM800 Chamber Machine Operation and Parts Manual 800 L 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 8 CM800 Chamber Machine Operation and Parts Manual 800LR 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...

  • Page 9: Precautions Before And After Machine Starting

    CM800 Chamber Machine Operation and Parts Manual 1.1.2 Preparations during transportation 1.1.2.1 The weight of this machine is 180-220kg, so that the loading capacity of any handling device is recommended to be more than 1000kg. If you are not sure of the safe loading capacity, please contact the manufacturer of such handling device.
  • Page 10 CM800 Chamber Machine Operation and Parts Manual 1.2.1.2 Check that whether the voltage is correct. 1.2.1.3 Confirm that whether the electric power and its rating is sufficient. 1.2.1.4 Check that whether all the safety related devices are normal, and notice that whether anyone within the danger zone.

  • Page 11: Chapter 2 Overall Description Of The Machine

    CM800 Chamber Machine Operation and Parts Manual Chapter 2 Overall description of the machine 2.1 Features of the machine 2.1.1 The machine main body is made of stainless steel with features of well endurance. Also, it’s flat packing table design make easy loading/unloading and cleaning without space limit.

  • Page 12: Marking Location And Content Description

    CM800 Chamber Machine Operation and Parts Manual 2.4 Marking location and content description 2.4.1 Nameplate: stuck on the right/upper side of the machine 2.5.2 Warning sign: stuck on the rear side of the machine 2.5 Specification of the machine 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...

  • Page 13: Chapter 3 Function Description Of The Pushbuttons On The Panel

    CM800 Chamber Machine Operation and Parts Manual Type XtraVac800 Machine dimension 920 x 800 x 1080 mm Vacuum chamber 836 x 710 x 230 mm dimension Sealing line dimension 800 mm x 2 Optional accessory Nitrogen filling function Machine weight 200 kg Motor 3 kW...
  • Page 14 CM800 Chamber Machine Operation and Parts Manual Memory set display (10 sets) Vacuum time display Nitrogen filling time display Sealing time display Cooling time display Memory release key Memory input key Reserved key E-stop key Time increase key Time decrease key 3.1 Memory set display(A): display the current memory set (e.g.
  • Page 15 CM800 Chamber Machine Operation and Parts Manual 3.3 Nitrogen filling time display(C): display the current setting of nitrogen filling time (unit: 1/s) 3.4 Sealing time display(D): display the current setting of sealing time (unit: 0.1/s) 3.5 Cooling time display(E): display the current setting of cooling time (unit: 0.1/s) 3.6 Memory release key(F): press key for modifying memory function 3.7 Memory input key(G): press key for locking memory function 3.8 Reserved key(H): key reserved for further use.

  • Page 16: Chapter 4 Instructions Of Operation, Maintenance And Troubleshooting

    CM800 Chamber Machine Operation and Parts Manual Chapter 4 Instructions of operation, maintenance and troubleshooting 4.1 Operation sequence: 4.1.1 Press power switch, then the indicator of the display screen is lit. 4.1.2 Press “memory release” key, then the display screen starts flashing. 4.1.3 Press “...
  • Page 17 CM800 Chamber Machine Operation and Parts Manual 1. air release hole 2. oil filling hole 3. oil sight glass 4. oil draining hole 4.3 Troubleshooting Situation Reason Measure Sealing line is not Heat-resistance cloth is Replace it complete damaged Poor sealing on bag mouth Heating wire is burned Replace it Insufficient vacuum...

  • Page 18: Chapter 5 Related Environment And Accessories Of The Machine

    CM800 Chamber Machine Operation and Parts Manual Chapter 5 Related environment and accessories of the machine 5.1 Accessory: 5.1.1 Standard accessory: 5.1.1.1 Heat-resistance cloth: 1 piece 5.1.1.2 Heating wire: 2 pieces 5.1.2 Optional accessory 5.1.2.1 Nitrogen filling function 5.1.2.2 Nitrogen container: 6000 liters. 5.1.2.3 High pressure hose: inner diameter 7.5 mm 5.1.2.4 Solenoid valve for nitrogen filling: 7 mm 5.2 Airborne noise level: 80 dB(A)
  • Page 19 CM800 Chamber Machine Operation and Parts Manual 800-A Spare Parts List 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 20 CM800 Chamber Machine Operation and Parts Manual 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 21 CM800 Chamber Machine Operation and Parts Manual 800 -B Spare Parts List Description Part Number XVT456315 Heat-resistance cloth XVT456316 Heating wire XVT467873 Round Head Screw XVT464559 Rubber gasket XVT464564 Heating wire fixing plate XVT464574 Round head screw XVT464565 Heating wire fixing support XVT467947 Teflon tape fixing plate FB/ L XVT69158...
  • Page 22 CM800 Chamber Machine Operation and Parts Manual 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 23 CM800 Chamber Machine Operation and Parts Manual 800 -C Spare Parts List XVT466714 XVT458062 XVT70835 XVT458060 XVT458060 XVT70835 XVT468225 XVT70988 XVT467877 XVT71285 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 24 CM800 Chamber Machine Operation and Parts Manual 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 25 CM800 Chamber Machine Operation and Parts Manual 800-D Spare Parts List 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 26 CM800 Chamber Machine Operation and Parts Manual 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 27 CM800 Chamber Machine Operation and Parts Manual 800-E Spare Parts List 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 28 CM800 Chamber Machine Operation and Parts Manual 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@...
  • Page 29 CM800 Chamber Machine Operation and Parts Manual 800-F Spare Parts List 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 30 CM800 Chamber Machine Operation and Parts Manual 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 31 CM800 Chamber Machine Operation and Parts Manual 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 32 CM800 Chamber Machine Operation and Parts Manual 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 33 CM800 Chamber Machine Operation and Parts Manual 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 34 CM800 Chamber Machine Operation and Parts Manual 5.2A 5.2A 1 3 5 2 4 6 2 4 6 I> I> I> 220V 220V/50V DATE NAME PAGE Electric power diagram PROCESSED 220V 3 60HZ CHECKED STANDARD 5.2A 5.2A 380V 220V 1 3 5 I>...
  • Page 35 CM800 Chamber Machine Operation and Parts Manual 6.3A 6.3A 6.3A 6.3A 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 36 CM800 Chamber Machine Operation and Parts Manual 7.12D 7.10D 7.9D 7.7D 7.5D 7.4D 7.2A 7.2A 7.2A 7.2A 7.2A 7.2A 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 37 CM800 Chamber Machine Operation and Parts Manual 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 38 CM800 Chamber Machine Operation and Parts Manual 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 39 CM800 Chamber Machine Operation and Parts Manual 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
  • Page 40 CM800 Chamber Machine Operation and Parts Manual 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 (800) -2999 Sales@ .com...
