- Page 1 CM610FB VACUUM CHAMBER MACHINE OPERATION & PARTS MANUAL 419 E. 11TH AVE. NORTH KANSAS CITY, MO 64116 USA +1 800-728-2999 SALES@VC999.COM...
- Page 2 Safe Operation Practices General Operation Read, understand, and follow all instructions in the manual and on the machine before starting. Keep this manual in a safe place for further and regular reference and for ordering replacement parts. Only allow people who familiar with the instructions to operate the machine. Be sure to know controls and how to stop the machine quickly.
-
Page 3: Table Of Contents
Content Chapter 1 Safety precautions 1.1 Precautions of transportation, installation and packing 1.2 Precautions before and after machine starting Chapter 2 Overall description of the machine 2.1 Features of the machine 2.2 Function of the machine 2.3 Product proper for this machine 2.4 Usage life of the machine 2.5 Marking location and content description 2.6 Specification of the machine... -
Page 4: Precautions Of Transportation, Installation And Packing
Chapter 1 Safety precautions 1.1 Precautions of transportation, installation and packing 1.1.1 Preparations before installation 1.1.1.1 Power requirement: Voltage: Look at the nameplate Current: Look at the nameplate Frequency: 50/60Hz Phase: 3Ø 1.1.1.2 Installation requirement 1.1.1.2.1 Prevent to install the machine in the environment full of dust and corrosive atmosphere with acid and alkali. - Page 5 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
-
Page 6: Precautions Before And After Machine Starting
1.1.2 Preparations during transportation 1.1.2.1 The weight of this machine is 180-220kg, so that the loading capacity of any handling device is recommended to be more than 1000kg. If you are not sure of the safe loading capacity, please contact the manufacturer of such handling device. If the situation is clearly understood, don’t try to handle the machine by yourselves. - Page 7 1.2.2 Precautions after machine starting 1.2.2.1 Confirm that whether the display is correct. 1.2.2.2 Confirm that whether the sound coming from pump running is normal (refer to clause 3.12.2). 1.2.2.3 Wear safety shoes, protection clothes and mask to ensure safety and hygiene of the operator.
-
Page 8: Chapter 2 Overall Description Of The Machine
Chapter 2 Overall description of the machine 2.1 Features of the machine 2.1.1 The machine main body is made of stainless steel with features of well endurance. Also, it’s flat packing table design make easy loading/unloading and cleaning without space limit. -
Page 9: Marking Location And Content Description
2.4.5 If there is any abnormal or unstable situation during the warranty period, please inform us or our agent. We will improve it immediately. 2.5 Marking location and content description 2.5.1 Nameplate: stuck on the right/upper side of the machine 2.5.2 Warning sign: stuck on the rear side of the machine 419 E. -
Page 10: Specification Of The Machine
2.6 Specification of the machine Type 700 x 570 x 975 mm Machine dimension 638 x 482 x 155 mm Vacuum chamber dimension Sealing line dimension 610mm x 2 Optional accessory Nitrogen filling function Machine weight 200 kg Motor 3 kW Heater 2.2 kW 360mm... -
Page 11: Chapter 3 Function Description Of The Pushbuttons On The Panel
Chapter 3 Function description of the pushbuttons on the panel Memory set display (10 sets) Vacuum time display Nitrogen filling time display Sealing time display Cooling time display Memory release key Memory input key Reserved key E-stop key Time increase key Time decrease key 419 E. - Page 12 3.1 Memory set display (A): display the current memory set (e.g. ”3” means the 3 set) 3.2 Vacuum time display (B): display the current setting of vacuum time (unit: 1/s) 3.3 Nitrogen filling time display(C): display the current setting of nitrogen filling time (unit: 1/s) 3.4 Sealing time display (D): display the current setting of sealing time (unit: 0.1/s) 3.5 Cooling time display (E): display the current setting of cooling time (unit: 0.1/s)
-
Page 13: Chapter 4 Instructions Of Operation
Chapter 4 Instructions of operation 4.1 Operation sequence: 4.1.1 Press power switch, then the indicator of the display screen is lit. 4.1.2 Press “memory release” key, then the display screen starts flashing. 4.1.3 Press “ ” or “ ” to input set number and time. 4.1.4 Then, press “Memory input”... -
Page 14: Chapter 5 Instructions Of Maintenance And Troubleshooting
Chapter 5 Instructions of maintenance and troubleshooting 5.1 Maintenance: 5.1.1 Cleaning of vacuum chamber 5.1.1.1 If the working process is finished, use clean and wet cloth to wipe the vacuum chamber and sealing set. 5.1.2 Vacuum oil replacement. 5.1.2.1 Recommended vacuum oil: BP Engergol RC100, Esso Nuto H100, Mobil Rarus 427. -
Page 15: Troubleshooting
5.2 Troubleshooting Situation Reason Measure Sealing line is not Heat-resistance cloth is Replace it complete damaged Poor sealing on bag mouth Heating wire is burned Replace it Insufficient vacuum Vacuum oil is not enough Fill it Oil quality becomes worse Replace it Rubber gasket is damaged Replace it... -
Page 16: Chapter 6 Related Environment And Accessories Of The Machine
Chapter 6 Related environment and accessories of the machine 6.1 Accessory: 6.1.1 Standard accessory: 6.1.1.1 Heat-resistance cloth: 1 piece 6.1.1.2 Heating wire: 2 pieces 6.1.2 Optional accessory 6.1.2.1 Nitrogen filling function 6.1.2.2 Nitrogen container: 6000 liters. 6.1.2.3 High pressure hose: inner diameter 7.5 mm 6.1.2.4 Solenoid valve for nitrogen filling: 7 mm 6.2 Airborne noise level: 80 dB (A) 6.3 Storage condition:... - Page 17 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 18 610 - A Spare Parts List NO. Description Component No Remark Hex. Screw 004-04-01-012 Hinge 003-06-01-001 Flat washer 004-06-01-006 Hex. Nut 004-05-02-004 Limit switch 006-05-01-001 Limit switch plate 004-03-19-002 Flat washer 004-06-01-007 Spring washer 004-06-02-007 Round head screw 004-04-03-003 Shaft core 004-01-01-003 Flat washer 004-06-01-001...
- Page 19 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 20 610 - B Spare Parts List NO. Description Component No Remark Heat-resistance cloth 009-03-02-001 Heating wire 009-03-03-015 Round head screw 004-04-03-003 Round head screw 004-04-03-003 Round head screw 004-04-03-003 Rubber gasket 009-09-02-020 Heating wire fixing plate 009-03-06-001 Round head screw 004-04-03-009 Heating wire fixing support 009-03-04-002...
- Page 21 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 22 610 -C Spare Parts List NO. Description Component No Remark Sealing pad 009-10-05-007 Sealing unit 002-03-01-005 Air bag cover 004-03-02-003 Air bag 009-18-02-004 Round head screw 004-04-03-003 Round head screw 004-04-03-003 Spring washer 004-06-02-007 Spring washer 004-06-02-007 U-shape board 004-03-07-002 Air bag support 002-03-05-003 Round head screw...
- Page 23 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 24 610 - D Spare Parts List NO. Description Component No Remark 004-04-03-003 Immerse head screw Panel frame 006-10-03-005 Cover film 006-10-02-002 Aluminum plate 006-10-07-015 006-10-01-003 Main switch 006-18-03-016 Vacuum gauge 009-15-01-001 Round head screw 004-04-03-002 Wires / 12P 006-12-04-007 Wires 006-12-06-002 Panel box 006-10-04-001...
- Page 25 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 26 610 - E Spare Parts List NO. Description Component No Remark 009-16-01-002 Control Box 006-06-01-004 Switching power supply 006-06-03-001 Sealing contactor(380/415V) 006-03-01-040 Transformer(0V/220V) 006-14-01-002 Gland 009-14-01-004 Terminal block 009-14-01-005 Fuse holder 006-21-22-006 07-1 Fuse 006-02-02-003 Sealing valve 009-16-01-006 Control box cover 419 E.
- Page 27 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 28 610 - F Spare Parts List NO. Description Component No Remark Nipple Tri-piping connector 008-05-02-003 Vacuum valve 006-02-01-001 Bending pipe 008-02-02-004 Vacuum pump Depends O ptional accessory Induction fan 006-20-01-001 Hex. Nut 004-05-02-007 Spring washer 004-06-02-007 Round head screw 004-04-03-005 419 E.
- Page 29 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 30 610 - G Spare Parts List NO. Description Component No Remark 050-02-25-001 009-05-01-021 Handle Backing plate 009-25-02-068 Base 050-02-25-002 Power cable 006-11-04-009 Gland 006-14-01-003 Cable 006-11-01-004 Complete lid w/ sealing bar 5099 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 •...
- Page 31 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 32 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 33 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 34 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 35 5.2A 5.2A 1 3 5 2 4 6 2 4 6 I> I> I> 220V 220V/50V DATE NAME PAGE Electric power diagram PROCESSED 220V 3 60HZ CHECKED STANDARD 5.2A 5.2A 380V 220V 1 3 5 I> I> I> 380V/50V 2 4 6 1 3 5 L1 L2 L3 PE DATE...
- Page 36 6.3A 6.3A 6.3A 6.3A 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 37 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 38 8.2A 8.2A 8.2A 8.2A 8.2A 8.2A 8.4D 8.5D 8.7D 8.9D 8.10D 8.12D 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 39 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 40 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 41 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 42 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
- Page 43 419 E. 11th Ave. North Kansas City, MO 64116 USA +1 800 728-2999 • Sales@ .com...
