TCL L32E5510S Operation Manual page 5

HDMI 1
or
HDMI 2
or
HDMI 3
Y
COMPONENT
Pb/Cb
IN
Pr/Cr
CMP IN
adapter
L
AUDIO IN
R
AUDIO IN
adapter
VGA
R
AUDIO
L
AV IN
VIDEO
or
AV IN adapter
ANTENNA IN
HDMI1 or HDMI2 or HDMI3 socket (input)
The HDMI (High-Definition Multimedia Interface) socket
blu ray, PC with a compatible video card installed, certain DVD players or a
high-definition compatible digital satellite decoder. This socket p
uncompressed digital connection that carries both video and audio data by way of
an integrated mini-plug cable.
YPbPr component sockets (input) or CMP adapter
Note: The CMP adapter
cable with YPbPr component sockets
These YPbPr sockets can be used to connect a device that has component video
sockets, such as a DVD player. The component sockets can recognize if the device
or you're connecting to is Y Pb Pr compatible or Y Cb Cr compatible. The component
sockets provide excellent picture quality because the video is separated into three
separate parts.
AUDIO IN or AUDIO IN adapter sockets (input)
Note: T he AUDIO in adapter
in adapter cable with audio L & R sockets,
These AUDIO IN L & R sockets can be used to connect a range of equipment,
including video recorders, camcorders, satellite receivers, DVD players, or games
or
consoles. AUDIO IN sockets (or AUDIO in adapter) are shared by VGA and YPbPr
(or CMP adapter) sockets.
VGA socket (input)
This socket can be used to connect a computer.
AV RCA audio + video sockets (input) or AV IN adapter socket
Note: the AV IN adapter
cable with VIDEO and AUDIO L & R IN sockets.
The AV IN sockets can be used to connect a range of equipment, including video
recorders, camcorders, decoders, satellite receivers, DVD players, or games
consoles. The VIDEO IN socket provides
ANTENNA IN socket (input)
This socket can be used to connect the outside aerial or cable network.
Connections and Setup
socket can be used to connect the attached CMP adapter
socket can be used to connect the attached AUDIO
and be used to obtain sound.
socket can be used to connect the attached AV adapter
composite video connection.
5
can be used to connect a
rovides an
socket input
