Table of Contents

Version 1.0
Published April 2018
Copyright©2018 ASRock INC. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identification or explanation and to the owners' benefit, without intent to
infringe.
Disclaimer:
Specifications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock. ASRock assumes no responsibility for
any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or fitness for a particular
purpose.
In no event shall ASRock, its directors, officers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of profits, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the documentation or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
"Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate"
ASRock Website: http://www.asrock.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 760GM-HDV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASROCK 760GM-HDV

Summary of Contents for ASROCK 760GM-HDV

  • Page 1 (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 2 If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply) The terms HDMI™...
  • Page 3 760GM-HDV Motherboard Layout CPU_FAN1 ATX12V1 HDMI2 USB 2.0 T: USB2 B: USB3 RoHS 760G USB 2.0 Top: T: USB0 RJ-45 Chipset B: USB1 PCIE1 CHA_FAN2 SB710 PCIE2 CMOS BATTERY Chipset USB6_7 USB4_5 PANEL 1 CLRMOS1 PCI1 HD_AUDIO2 SATAII_1 (PORT 1)

  • Page 4: Table Of Contents

    No. Description ATX 12V Power Connector (ATX12V1) CPU Fan Connector (CPU_FAN1) CPU Socket CPU Heatsink Retention Module 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1) ATX Power Connector (ATXPWR1) SATA2 Connector (SATAII_4 (PORT4)) Chassis Fan Connector (CHA_FAN2) System Panel Header (PANEL1) SATA2 Connector (SATAII_3 (PORT3)) SATA2 Connector (SATAII_2 (PORT2)) SATA2 Connector (SATAII_1 (PORT1))
  • Page 5 760GM-HDV I/O Panel No. Description No. Description PS/2 Mouse Port USB 2.0 Ports (USB23) LAN RJ-45 Port* HDMI Port Line In (Light Blue)** DVI-D Port Front Speaker (Lime)** D-Sub Port Microphone (Pink)** PS/2 Keyboard Port USB 2.0 Ports (USB01) * There are two LEDs on the LAN port. Please refer to the table below for the LAN port LED indications.
  • Page 6 ** To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module and enable the multi- channel audio feature through the audio driver. Please set Speaker Configuration to “7.1 Speaker”in the Realtek HD Audio Manager. Function of the Audio Ports in 7.1-channel Configuration: Port Function...
  • Page 7 If you require technical support related to this motherboard, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.
  • Page 8 1.2 Specifications • Micro ATX Form Factor Platform • Solid Capacitor design • Supports Socket AM3+ processors • Supports Socket AM3 processors: AMD Phenom II X6 / X4 / X3 / X2 (except 920 / 940) / Athlon II X4 / X3 / X2 / Sempron processors • Supports 8-Core CPU • Supports AMD OverDrive...
  • Page 9 760GM-HDV • Supports DVI-D with max. resolution up to 1920x1200 @ 75Hz • Supports D-Sub with max. resolution up to 2048x1536 @ 60Hz • Supports HDCP with DVI-D and HDMI Ports • Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback with DVI-D Port • 7.1 CH HD Audio (Realtek ALC887 Audio Codec)

  • Page 10: Cpu Fan Connector (Cpu_Fan1)

    • ErP/EuP ready (ErP/EuP ready power supply is required) tions * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.
  • Page 11 CPU you adopt. If you want to adopt DDR3 1800/1600 memory module on this motherboard, please refer to the memory support list on our website for the compatible memory modules. ASRock website: http://www.asrock.com 2. Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows®...
  • Page 12 Chapter 2 Installation This is a Micro ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.
  • Page 13 760GM-HDV 2.1 Installing the CPU Unplug all power cables before installing the CPU.
  • Page 15 760GM-HDV 2.2 Installing the CPU Fan and Heatsink After you install the CPU into this motherboard, it is necessary to install a larger heatsink and cooling fan to dissipate heat. You also need to spray thermal grease between the CPU and the heatsink to improve heat dissipation. Make sure that the CPU and the heatsink are securely fastened and in good contact with each other.
  • Page 16 2.3 Installing Memory Modules (DIMM) This motherboard provides two 240-pin DDR3 (Double Data Rate 3) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR3 DIMM pairs. 2.
  • Page 17 760GM-HDV...
  • Page 18 2.4 Expansion Slots (PCI and PCI Express Slots) There is 1 PCI slot and 2 PCI Express slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.
  • Page 19 760GM-HDV 2.5 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper...
  • Page 20 2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header Connect the power (9-pin PANEL1) switch, reset switch and...

  • Page 21: Usb 2.0 Header (Usb6_7)

    760GM-HDV Chassis Intrusion and Please connect the SPEAKER DUMMY Speaker Header chassis intrusion and the DUMMY (7-pin SPK_CI1) chassis speaker to this (see p.1, No. 15) header. SIGNAL DUMMY Serial ATA2 Connectors These four SATA2 (SATAII_1 (PORT1): connectors support SATA see p.1, No.
  • Page 22 1. High Definition Audio supports Jack Sensing, but the panel wire on the chassis must support HDA to function correctly. Please follow the instructions in our manual and chassis manual to install your system. 2. If you use an AC’97 audio panel, please install it to the front panel audio header by the steps below: A.
  • Page 23 760GM-HDV ATX 12V Power This motherboard pro- Connector vides an 8-pin ATX 12V (8-pin ATX12V1) power connector. To use a (see p.1, No. 1) 4-pin ATX power supply, please plug it along Pin 1 and Pin 5.
  • Page 24 Technische Daten • Micro-ATX-Formfaktor Plattform • Feststoffkondensator-Design • Unterstützt Prozessoren mit AM3+-Sockel Prozessor • Unterstützt Prozessoren mit AM3-Sockel: AMD Phenom X6 / X4 / X3 / X2 (außer 920 / 940) / Athlon II X4 / X3 / X2 / Sempron • Unterstützt 8-Kern-CPU • Unterstützt AMD OverDrive...
  • Page 25 760GM-HDV • Unterstützt DVI-D mit maximaler Auflösung von 1920 x 1200 bei 75Hz • Unterstützt D-Sub mit maximaler Auflösung von 2048 × 1536 bei 60 Hz • Unterstützt HDCP mit DVI-D- und HDMI-Ports • Unterstützt Blu-ray- (BD) / HD-DVD Wiedergabe (Full HD/1080p) mit DVI-D-Port • 7.1-Kanal-HD-Audio (Realtek ALC887-Audiocodec)
  • Page 26 • 1 x Gehäuseeingriff- und Lautsprecher-Stiftleiste Anschluss • 1 x CPU-Lüfteranschluss (4-polig) • 2 x Gehäuselüfteranschlüsse (4-polig) • 1 x 24-poliger ATX-Netzanschluss • 1 x 8-poliger 12-V-Netzanschluss • 1 x Audioanschluss an Frontblende • 2 x USB 2.0-Stiftleisten (unterstützt 4 USB 2.0-Ports) (unterstützt Schutz gegen elektrostatische Entladung) • AMI Legal BIOS BIOS-...
  • Page 27 760GM-HDV Spécifications • Facteur de forme Micro ATX Plateforme • Conception à condensateurs solides • Prend en charge les processeurs à socket AM3+ Processeur • Prend en charge les processeurs à socket AM3 : Processeurs AMD Phenom II X6 / X4 / X3 / X2 (sauf 920 / 940) / Athlon II X4 / X3 / X2 / Sempron • Prend en charge les CPU 8 cœurs...
  • Page 28 • Prend en charge le mode DVI-D avec une résolution maximale de 1920x1200 @ 75Hz • Prend en charge le mode D-Sub avec une résolution maximale de 2048x1536 @ 60 Hz • Prend en charge HDCP via ports DVI-D et HDMI • Prend en charge la lecture Blu-ray (BD) / HD-DVD Full HD 1080p via port DVI-D • Audio 7.1 CH HD (Codec audio Realtek ALC887)
  • Page 29 760GM-HDV • 1 x prise DEL d’alimentation et emplacement sur châssis Connecteur • 1 x connecteur pour ventilateur de CPU (4 broches) • 2 x connecteurs pour ventilateur de châssis (4 broches) • 1 x connecteur d’alimentation ATX 24 broches • 1 x connecteur d’alimentation 12 V 8 broches...
  • Page 30 Specifiche • Fattore di forma Micro ATX Piattaforma • Design condensatore solido • Supporta processori con socket AM3+ • Supporta processori con socket AM3+: Processori AMD Phenom II X6 / X4 / X3 / X2 (tranne 920 / 940) / Athlon II X4 / X3 / X2 / Sempron • Supporta CPU 8-Core • Supporta AMD OverDrive...
  • Page 31 760GM-HDV • Supporta DVI-D con una risoluzione max. fino a 1920 x 1200 a 75Hz • Supporta D-Sub con una risoluzione max. fino a 2048x1536 a 60 Hz • Supporto di HDCP con le porte DVI-D e HDMI • Supporta Blu-ray (BD) / HD-DVD Full HD 1080p, riproduzione con porte DVI-D • Audio HD 7.1 CH (codec audio Realtek ALC887)
  • Page 32 • 1 x collegamento altoparlante e intrusione telaio Connettore • 1 x connettore ventola CPU (4-pin) • 2 x connettori ventola chassis (4-pin) • 1 x connettore alimentazione ATX 24-pin • 1 x connettore alimentazione 12 V 8-pin • 1 x connettore audio pannello frontale • 2 x connettori USB 2.0 (supporto di 4 porte USB 2.0) (supporta protezione da scariche elettrostatiche) • BIOS AMI Legal...
  • Page 33 760GM-HDV Especificaciones • Factor de forma Micro ATX Plataforma • Diseño de condensador sólido • Admite procesadores Socket AM3+ • Admite procesadores Socket AM3: Procesadores AMD Phenom II X6 / X4 / X3 / X2 (excepto 920 / 940) / Athlon II X4 / X3 / X2 / Sempron • Admite CPU de 8 núcleos...
  • Page 34 • Compatible con DVI-D con máxima resolución hasta 1920x1200 @ 75Hz • Admite D-Sub con una resolución máxima de 2048x1536 @ 60 Hz • Compatible con función HDCP con puertos DVI-D y HDMI • Compatible con reproducción Full HD 1080p Blu-ray (BD) / HD-DVD con puerto DVI-D • 7.1 Audio CH HD (Códec de audio Realtek ALC887) Audio...
  • Page 35 760GM-HDV • 1 x cabezal de intrusión de chasis y de altavoces Conector • 1 x conector para ventilador de la CPU (4 contactos) • 2 x conectores de ventilador del chasis (de 4 contactos) • 1 x conector de alimentación ATX de 24 contactos • 1 x conector de alimentación de 12V de 8 contactos...
  • Page 36 Технические характеристики • Форм-фактор Micro ATX Платформа • Схема на основе твердотельных конденсаторов • Поддержка процессоров с разъемом AM3+ ЦП • Поддержка процессоров с разъемом AM3: Процессоры AMD Phenom II X6 / X4 / X3 / X2 (кроме 920 / 940) / Athlon II X4 / X3 / X2 / Sempron • Поддержка...
  • Page 37 760GM-HDV • Макс. разрешение на выходе DVI-D: 1920x1200 при частоте обновления 75 Гц • Макс. разрешение на выходе D-Sub: 2048x1536 при частоте обновления 60 Гц • Поддержка функции HDCP через порты DVI-D и HDMI • Поддержка воспроизведения Full HD 1080p Blu-ray (BD) / HD-DVD через...
  • Page 38 • 1 колодка с разъемами датчика вскрытия корпуса и Разъемы динамика • 1 разъем для вентилятора охлаждения ЦП, 4-контактный • 2 разъема для вентилятора корпуса, 4-контактные • 1 разъем питания АТХ, 24-контактный • 1 разъем питания 12 В, 8-контактный • 1 аудиоразъем для передней панели • 2 колодки...
  • Page 39 760GM-HDV Especificações • Micro ATX Form Factor Plataforma • Design de condensador sólido • Suporte para soquete de processadores AM3+ • Suporte para soquete de processadores AM3: Processadores AMD Phenom II X6 / X4 / X3 / X2 (exceto 920 / 940) / Athlon II X4 / X3 / X2 / Sempron • Suporta CPU 8-Core...
  • Page 40 • Suporta DVI-D com resolução máxima de até 1920x1200 @ 75Hz • Suporta D-Sub com resolução máxima de até 2048x1536 @ 60Hz • Suporta HDCP com Portas DVI-D e HDMI • Suporta reprodução Full HD 1080p Blu-ray (BD) / HD-DVD com Porta DVI-D • Áudio 7.1 CH HD com proteção de conteúdo (Codec de áudio Áudio...
  • Page 41 760GM-HDV • 1 x Intrusão do Chassi e Cabeçote de Autofalante Conector • 1 x Conector da ventoinha da CPU (4 pinos) • 2 x Conectores da ventoinha do Gabinete (4 pinos) • 1 x Conector alimentação ATX 24 pinos • 1 x Conector alimentação 12V 8 pinos...
  • Page 42 Specyfikacje • Współczynnik kształtu Micro ATX Platforma • Konstrukcja kondensatorami stałymi • Obsługa procesorów Socket AM3+ • Obsługa procesorów Socket AM3: procesory AMD Phenom II X6 / X4 / X3 / X2 (za wyjątkiem 920 / 940) / Athlon II X4 / X3 / X2 / Sempron • Obsługa procesorów 8.
  • Page 43 760GM-HDV • Obsługa DVI-D z maks. rozdzielczością do 1920x1200 przy 75Hz • Obsługa D-Sub z maks. rozdzielczością do 2048x1536 przy 60Hz • Obsługa HDCP z portami DVI-D i HDMI • Obsługa odtwarzania Blu-ray (BD) Full HD 1080p/HD- DVD z portem DVI-D • Dźwięk HD 7.1 CH (kodek audio Realtek ALC887)
  • Page 44 • 1 x złącze główkowe naruszenia obudowy i głośnika Złącze • 1 x złącze wentylatora CPU (4-pinowe) • 2 x złącze wentylatora obudowy (4-pinowe) • 1 x 24 pinowe złącze zasilania ATX • 1 x 8 pinowe złącze zasilania 12 V • 1 x złącze audio na panelu przednim • 2 x złącza główkowe USB 2.0 (Obsługa 4 portów USB 2.0) (Obsługa zabezpieczenia ESD)
  • Page 45 760GM-HDV 규격 • Micro ATX 폼 팩터 플랫폼 • 솔리드 콘덴서 구조 • 소켓 AM3+ 프로세서 지원 • 소켓 AM3 프로세서 지원 AMD Phenom II X6 / X4 / X3 / X2 (except 920 / 940) / Athlon II X4 / X3 / X2 / Sempron 프로세서...
  • Page 46 • DVI-D 지원 ( 최대 해상도 1920x1200 @ 75Hz) • D-Sub 지원 ( 최대 해상도 2048x1536 @ 60Hz) • DVI-D 및 HDMI 포트를 이용한 HDCP 지원 • DVI-D 포트를 이용한 Full HD 1080p Blu-ray (BD) / HD-DVD 재생 지원 • 7.1 CH HD 오디오 (Realtek ALC887 오디오 코덱 ) 오디오...
  • Page 47 760GM-HDV • 섀시 침입 및 스피커 헤더 1 개 커넥터 • CPU 팬 커넥터 (4 핀 ) 1 개 • 섀시 팬 커넥터 2 개 (4 핀 ) • 24 핀 ATX 전원 커넥터 1 개 • 8 핀 12V 전원 커넥터 1 개...
  • Page 48 仕様 • マイクロ ATX フォームファクター プラッ ト • 固体コンデンサ設計 フォーム • ソケッ ト AM3+ プロセッサーに対応 • ソケッ ト AM3 プロセッサーに対応 : AMD Phenom II X6 / X4 / X3 / X2 (920 / 940 を除く) / Athlon II X4 / X3 / X2 / Sempron プロセッサー...
  • Page 49 760GM-HDV • DVI-D に対応、 最大解像度 1920x1200 @75Hz • D-Sub をサポート。 最大解像度 2048x1536 @60Hz • DVI-D ポート と HDMI ポートで HDCP に対応 • DVI-D ポートで Full HD 1080p Blu-ray (BD) / HD-DVD 再生 に対応 • 7.1 CH HD オーディオ (Realtek ALC887 Audio Codec) オーディオ...
  • Page 50 • 1 x シャーシイントルージョンとスピーカーヘッダー コネクタ • 1 x CPU ファンコネクタ （4 ピン） • 2 x シャーシファンコネクタ （4 ピン） • 1 x 24 ピン ATX 電源コネクタ • 1 x 8 ピン 12V 電源コネクタ • 1 x 前面パネルオーディオコネクタ • 2 x USB 2.0 ヘッダー （4 つの USB 2.0 ポートに対応） （ 静電気 放電...
  • Page 51 760GM-HDV 规格 • Micro ATX 规格尺寸 平台 • 稳固的电容器设计 • 支持 Socket AM3+ 处理器 • 支持 Socket AM3 处理器 : AMD Phenom II X6 / X4 / X3 / X2 ( 不包括 920 / 940) / Athlon II X4 / X3 / X2 / Sempron 处理器...
  • Page 52 • 支持 DVI-D，75Hz 时最大分辨率达 1920x1200 • 支持 D-Sub，60Hz 时最大分辨率达 2048x1536 • 通过 DVI-D 和 HDMI 端口支持 HDCP • 通过 DVI-D 端口支持全高清 1080p Blu-ray (BD) / HD-DVD 播放。 • 7.1 CH 高清音频 (Realtek ALC887 音频编解码器 ) 音频 * 要配置 7.1 CH 高清音频，需要使用高清前面板模块和通过音 频驱动程序启用多通道音频功能。...
  • Page 53 760GM-HDV • 1 x 机箱侵入和扬声器接脚 接口 • 1 x CPU 风扇接口 (4 针 ) • 2 x 机箱风扇接口 (4 针 ) • 1 x 24 针 ATX 电源接口 • 1 x 8 针 12V 电源接口 • 1 x 前面板音频接口 • 2 x USB 2.0 接脚（支持 4 个 USB 2.0 端口 , 支持 ESD 保护）...
  • Page 54 电子信息产品污染控制标示 依据中国发布的「电子信息产品污染控制管理办法」及 SJ/T 11364-2006「电子 信息产品污染控制标示要求」，电子信息产品应进行标示，藉以向消费者揭露 产品中含有的有毒有害物质或元素不致发生外泄或突变从而对环境造成污染或 对人身、财产造成严重损害的期限。依上述规定，您可于本产品之印刷电路板 上看见图一之标示。图一中之数字为产品之环保使用期限。由此可知此主板之 环保使用期限为 10 年。 图一 有毒有害物质或元素的名称及含量说明 若您欲了解此产品的有毒有害物质或元素的名称及含量说明，请参照以下表格 及说明。 有害物质或元素 部件名称 铅 (Pb) 镉 (Cd) 汞 (Hg) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 印刷电路板 及电子组件 外部信号连 接头及线材 O: 表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 标准规定 的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T 11363-2006 标准 规定的限量要求，然该部件仍符合欧盟指令...
  • Page 55 760GM-HDV 規格 • Micro ATX 尺寸 平台 • 固態電容設計 • 支援 Socket AM3+ 處理器 • 支援 Socket AM3 處理器： AMD Phenom II X6 / X4 / X3 / X2 (920 / 940 除外 ) / Athlon II X4 / X3 / X2 / Sempron 處理器...
  • Page 56 • 支援最高達 1920x1200 @ 75Hz 解析度的 DVI-D • 最高支援 2048x1536 @ 60Hz 解析度的 D-Sub • 支援含 DVI-D 及 HDMI 連接埠的 HDCP • 支援透過 DVI-D 連接埠的 Full HD 1080p 藍光 (BD) / HD- DVD 播放 • 7.1 CH HD 音訊 (Realtek ALC887 音訊轉碼器 ) 音訊...
  • Page 57 760GM-HDV • 1 x 機殼防護及喇叭排針 接頭 • 1 x CPU 風扇接頭 (4-pin) • 2 x 機殼風扇接頭 (4-pin) • 1 x 24 pin ATX 電源接頭 • 1 x 8 pin 12V 電源接頭 • 1 x 前面板音訊接頭 • 2 x USB 2.0 排針（支援 4 個 USB 2.0 連接埠）（支援靜電保...
  • Page 58 Spesifikasi • Bentuk dan Ukuran Micro ATX Platform • Desain Kapasitor Solid • Mendukung prosesor Soket AM3+ • Mendukung prosesor Soket AM3: Prosesor AMD Phenom X6 / X4 / X3 / X2 (kecuali 920 / 940) / Athlon II X4 / X3 / X2 / Sempron • Mendukung CPU 8-Core • Mendukung AMD OverDrive...
  • Page 59 760GM-HDV • Mendukung DVI-D dengan resolusi maksimum hingga 1920x1200 @ 75Hz • Mendukung D-Sub dengan resolusi maksimum hingga 2048x1536 @ 60Hz • Mendukung HDCP dengan port DVI-D dan HDMI • Mendukung pemutaran Blu-ray (BD) / HD-DVD 1080p Full HD dengan Port DVI-D • Audio HD 7.1 CH (Realtek ALC887 Audio Codec)
  • Page 60 • 1 x Intrusi Chassis dan Header Speaker Konektor • 1 x Konektor Kipas CPU (4-pin) • 2 x Konektor Kipas Chassis (4-pin) • 1 x Konektor Daya ATX 24 pin • 1 x Konektor Daya 12V 8 pin • 1 x Konektor Audio Panel Depan • 2 x Header USB 2.0 (Mendukung 4 port USB 2.0) (Mendukung Perlindungan dari ESD) • AMI Legal BIOS...
  • Page 61 Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrock.com/tsd.asp...
  • Page 62 DECLARATION OF CONFORMITY Per FCC Part 2 Section 2.1077(a) ASRock Incorporation Responsible Party Name: 13848 Magnolia Ave, Chino, CA91710 Address: Phone/Fax No: +1-909-590-8308/+1-909-590-1026 hereby declares that the product Product Name : Motherboard 760GM-HDV Model Number : Conforms to the following specifications:...
  • Page 63 EU Declaration of Conformity For the following equipment: Motherboard (Product Name) 760GM-HDV / ASRock (Model Designation / Trade Name) ASRock Incorporation (Manufacturer Name) 2F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District, Taipei City 112, Taiwan (R.O.C.) (Manufacturer Address) EMC —Directive 2014/30/EU (from April 20th, 2016) ☐...
