- Page 1 OPERATING INSTRUCTIONS Alfea Extensa M Air/water heat pump Monobloc system U0767338_2490_EN_1 For users. 13/11/2023 To be kept by the user for future reference.
- Page 2 Safety instructions Please comply with the following instructions in order to avoid any risk of injury or inappropriate use of the appliance. Commissioning Do not switch the appliance ON until every fi lling operation has been performed Do not attempt to install this appliance yourself. This heat pump must be installed by qualifi...
- Page 3 respect the installation clearances (see your installation engineer). Do not climb on the outdoor unit. Caution: copper pipes that carry refrigerating fl uid may be hot and cause burns. The room in which the unit is operating must be correctly ventilated in order to avoid any shortage of oxygen in the event of a refrigerant gas leak.
-
Page 5: Table Of Contents
Contents Safety instructions My installation Outdoor unit ......6 Underfl oor heating system ....6 Indoor unit . -
Page 6: My Installation
My installation ► Outdoor unit The outdoor unit extracts heat from the outside air. It has been installed by my installer in a position that allows it to work at its best. Nothing should obstruct the air circulation through the outdoor unit. The water contained in the ambient air may condense and fl... -
Page 7: Radiators
► Radiators Classic radiators ▼ In order to ensure operation of the control system, the room containing the thermostat must not also contain a thermostatic valve. If this is the case, it must be opened as far as possible. Fan coils / dynamic radiators with an integrated control system ▼... -
Page 8: Control Interface
Control Interface ► Menu structure Menu — Active Functions — Hot Water — Away Mode — Energy Monitoring — Consumed energy — Produced energy — Settings — Language — Date / Time — Circuit names — Wi-Fi — Software version... -
Page 9: User Interface
► User Interface Menu access button Navigation knob: Rotation: Menu navigation Press: Validation Operation indicator: Fixed white : Normal operation Flashing orange : Error Back button... -
Page 10: Display Description
► Display Description 09:24 24° 55° 43° 40° Connectivity Attenuation mode Planned absence Emergency mode Outdoor temperature Installer Menu Normal operation Warning Error... - Page 11 Pressure indicator 55°C DHW setpoint DHW on 55° Remaining hot water Heating in progress 55° 55° 55° (Grey) Off / Frost protection 43°C Flow temperature setpoint Operation Product by : (Orange) Heating Heat pump (Blue) Cooling Electric backup Heat pump + Electric (Grey) Off...
-
Page 12: Control Menu
Control menu ► I set my operating menus Active Functions The Active Services page tells me which services are Active functions running and lets me change their status. - Hot Water : Hot Water On / Off - Circuit 1 / 2 : Circuit 1 On / Off... -
Page 13: I Control My Hot Water
► I control my hot water Hot water I choose the hot water operating mode and temperature. Hot Water - Heating mode : Heating mode Comfort: for maximum comfort by ensuring a large quantity Comfort hot water at all times. Temperature Eco: for maximum savings, while ensuring 55°C... -
Page 14: I Go Away
► I go away Absence I set the start and end dates and times of my absence. Absence Start January 03 : 00 January 00 : 00 When an absence is in progress, the symbol is displayed on the home screen. ►... -
Page 15: Setting Up My Device
► Setting up my device Settings In the settings menu : Settings I can ajust : • Language Language • Date and time Date / Time • Circuits name Circuits name I access : Wi-Fi • WiFi network informations Software Version •... -
Page 16: Maintenance
Maintenance In order to ensure that your appliance operates correctly for many years, the maintenance operations described below are required periodically. They are generally carried out as part of a maintenance contract. ► Regular checks I check the water pressure in the heating circuit regularly (refer to my installer’s recommended pressure - between 1 and 2 bar) If a fi... -
Page 17: Error Messages
► Error messages 09:24 24° Error Error If a fault occurs, the error number appears on the welcome screen. To obtain the error’s designation,I select it using the knob. In the event of an error, I note down the number and 55°... - Page 19 This unit is identifi ed by this symbol. It means that all electrical and electronic products must not be included in household waste. A specifi c recycling system for this type of product has been set up in European Union countries (*), Norway, Iceland and Liechtenstein.
- Page 20 Date of installation : www.atlantic.fr Société Industrielle de Chauffage SATC - BP 64 - 59660 MERVILLE - FRANCE Contact of your heating technician or your after-sales service.
