- Page 1 HORNET RecoverXLT2-AP Oil-Less Universal Refrigerant Recovery System Operation and Maintenance Manual for 95764 and 95765 UP TO 25% FASTER RECOVERY RATES* * For serial numbers 22180065 and higher—PN 95764 and serial numbers 22170044 and higher—PN 95765 7/24/2024...
-
Page 2: Table Of Contents
2) Use the correct hoses. Use only hoses designed for handling of refrigerants. The hose should be 9) The HORNET RecoverXLT2-AP should not the minimum length required for each job and be used near open containers of gasoline or any equipped with a shut-off device (such as the other flammable liquid. -
Page 3: Direct Liquid Recovery
HORNET RecoverXLT2-AP Operating Guide Direct Liquid/Vapor Recovery The HORNET RecoverXLT2-AP is used to pull 4) Connect the Utility port of your manifold to the liquid or vapor refrigerant out of the system and 1/4” SUCTION port of the HORNET transfer it into a recovery cylinder. -
Page 4: Vapor Recovery
HORNET RecoverXLT2-AP to vapor port as shown in diagram on page 4. using the momentary switch. 11) The HORNET RecoverXLT2-AP will Connect the Utility port of your manifold to the recover the vapor refrigerant. When the suction 1/4” SUCTION port of the HORNET... -
Page 5: System Purge Instructions
EPA standards. This The HORNET RecoverXLT2-AP “pulls” process requires: vapor from the recovery cylinder and produces 1) An extra hose for the push-pull recovery. -
Page 6: Recovering R-410A High Pressure Gas
CYLINDERS APPROVED FOR R-410A. Purge the machine (see page 5 for more Overfilling the tank may cause it to rupture! details). The HORNET RecoverXLT2-AP will recover Technical Support: Call 800-769-8370 for R-410A provided the following instructions are additional information. followed:... -
Page 7: Suction Filter
This connector to the hose going to the Suction is critical to avoid contamination and know Port of the HORNET RecoverXLT2-AP . how much refrigerant will be recovered. The first job of the day usually means a fresh,... -
Page 8: Troubleshooting Guide
Troubleshooting Guide Condition Possible Problem Possible Solution Compressor under unequalled See restart procedure Compressor will not conditions start Compressor thermal overload is Thermal overload will reset in approx. 15 tripped -30 minutes Unit is shut down on Recovery Low pressure switch resets at atmospheric Complete. -
Page 9: Technical Data
Technical Data Compressor: 1.25 HP 2 Cylinder Oil-less Reciprocating, Air Cooled Power Source: 110-230V 1ph 50/60Hz Amperage: 12.0 amps Motor Type: Variable Speed Brushless DC, 1200-3000 RPM Size: Height: 12.50” Width: 19.25” Depth: 12.50” Weight: 26.7 lbs. / 12.1 kg Calculated Recovery Ratings Kg./minute Kg./hour... -
Page 10: Important Notice To Purchaser
If at any time after the warranty period you ® have problems with your YELLOW JACKET The following exceptions will not be covered recovery unit, call our technical service depart- under this warranty: Recovery products that have ment for help in selecting the correct replace- been altered, misused, or improperly maintained.
