Portable Large TV Tripod
SKU: STAND-TV75T
Instruction Manual
Assembly Video & Product Info
www.vivo-us.com/products/stand-tv75t

Advertisement

loading
Need help?

Need help?

Do you have a question about the STAND-TV75T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vivo STAND-TV75T

  • Page 1 Portable Large TV Tripod SKU: STAND-TV75T Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/stand-tv75t...
  • Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3 Package Contents A (x1) B (x1) C (x1) Tripod Base VESA Plate Left VESA Bracket D (x1) E (x1) Right VESA Bracket Mounting Bracket Included Hardware & Tools S-A (x2) S-B (x6) S-C (x4) S-D (x10) M6x50mm Carriage Bolt M6 Lock Nut Plastic Washer Metal Washer S-E (x4)
  • Page 4: Assembly Steps

    ASSEMBLY STEPS STEP 1 Unfold Tripod Base (A) and tighten the Lower Knob. STEP 2 Loosen the Upper Knob on the pole of Tripod Base (A), adjust the pole to the desired height, insert the Retainer Pin, then tighten the Upper Knob. TIPOVER WARNING DO NOT use the Bottom Hole when installing a TV over 70”...
  • Page 5 STEP 3 Install Mounting Bracket (E) using M6x50mm Carriage Bolts (S-A), Metal Washers (S-D) and M6 Lock Nuts (S-B). The arrow on Mounting Bracket (E) must be pointing up. Tighten with Wrench (T-A). Make sure that the arrow on the Mounting Bracket faces upward STEP 4 Assemble VESA Plate (B) to Mounting Bracket (E) using M6x14mm Screws (S-E), Metal...
  • Page 6 STEP 5 Mount VESA Brackets (C, D) to the back of the TV with Screws (M-A through M-D) and M8 Washers (M-E). Spacers (M-F, M-G) may be required. Tighten with a Phillips screwdriver. Too Long Too Short...
  • Page 7 STEP 6 Hang the TV with VESA Brackets (C, D) over the VESA Plate (B) and secure with the pre- installed bolts underneath using a Phillips screwdriver. STEP 7 Adjust as desired. 0° -8°...
  • Page 8 LAST UPDATED: 6/28/24 REV3 v1.2 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
