Portable Large TV Tripod
Instruction Manual
SKU: STAND-TV75T/W
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-tv75t
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the STAND-TV75T/W and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo STAND-TV75T/W

  • Page 1 Portable Large TV Tripod Instruction Manual SKU: STAND-TV75T/W Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv75t GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
  • Page 2: Package Contents

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3: Assembly Steps

    ASSEMBLY STEPS STEP 1 Unfold Tripod Base (A) and tighten the lower knob. STEP 2 Loosen the upper knob on the pole of Tripod Base (A), adjust the pole to the desired height, insert the retainer pin, then tighten the upper knob. WARNING: Do not use the bottom hole when installing a TV over 70”...
  • Page 4 STEP 3 Install Mounting Bracket (E) using M6x50mm Carriage Bolts (S-A), Metal Washers (S-D) and M6 Lock Nuts (S-B). The arrow on Mounting Bracket (E) must be pointing up. Tighten with Wrench (T-A). STEP 4 Assemble VESA Plate (B) to Mounting Bracket (E) using M6x14mm Screws (S-E), Metal Washers (S-D), Plastic Washers (S-C) and M6 Lock Nuts (S-B).
  • Page 5 STEP 5 Mount VESA Brackets (C, D) to the back of the TV with Screws (M-A through M-D) and M8 Washers (M-E). Spacers (M-F, M-G) may be required. Tighten with a Phillips screwdriver.
  • Page 6 STEP 6 Hang the TV with VESA Brackets (C, D) over the VESA Plate (B) and secure with the pre-installed bolts underneath using a Phillips screwdriver.
  • Page 7 Adjust as Desired...
  • Page 8 AVG. RESPONSE TIME help@vivo-us.com (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
