Step 3: Close the payment box
• Switch on the main circuit breaker (MCB).
• Verify that the payment terminal powers up.
• Close the service door, using the master key.
7. ELECTRICAL SCHEMATIC
The figure on the right presents the wiring scheme of the
payment box.
Attention: In some cases, e.g. for the Payter Apollo
terminal, adapter cables are required. If a payment box
terminal is changed with a payment terminal of another
model, consult your distributor to verify if adapter cables are
required.
