English RAIS/ - User manual for Q-BE Q-BE Revision : Date 12-04-2023 INTRODUCTION ................................56 WARRANTY ..................................57 SPECIFICATIONS ................................58 DISTANCES ..................................58 INSTALLATION INSTRUCTIONS..........................59 CONVECTION..................................60 CHIMNEY ....................................60 INSTALLATION ...................................61 INSTALLATION OF STOVE WITH SWIVEL BASE ....................62 INSTALLATION DISTANCE ............................63 NORMAL SET-UP (CORNER SETTING) - COMBUSTIBLE WALL..............64 NORMAL SET-UP (CORNER SETTING) - NON-COMBUSTIBLE AND COMBUSTIBLE WALL ...65... -
Page 7: Introduction
English RAIS/ - User manual for Q-BE Introduction attika Thank you for purchasing a RAIS/ wood burning stove. attika A RAIS/ wood burning stove is more than just a heat source. It also shows that you care about design and quality in your home. -
Page 8: Warranty
English RAIS/ - User manual for Q-BE WARRANTY attika RAIS/ – wood-burning stoves are tested repeatedly in terms of safety, as well as material and manufacturing quality. We grant warranty on all models, starting with the date of installation. -
Page 9: Specifications
English RAIS/ - User manual for Q-BE Specifications Q-BE DTI Ref.: 300-ELAB-2080-EN / 300-ELAB-2080-AEA Nominal output (kW): Min./Max. output (kW): 4 - 8 Heating area (m 60 - 120 Stove’s width/depth/height (mm): 373-373-1370 Combustion chamber’s width/depth/height (mm): 239-239-505 Recommended amount of wood when fuelling (kg). -
Page 10: Installation Instructions
English RAIS/ - User manual for Q-BE Installation instructions The following pages give instructions for the safe and proper installation of this heat- ing appliance in the UK. These instructions cover the basic principles of installation, although detail may need slight modification to suit particular local site conditions. In... -
Page 11: Convection
English RAIS/ - User manual for Q-BE Convection attika RAIS/ stoves are convection stoves. This means that the stove’s back and side panels are not over-heated. Convection means that there is a circulation of air, which ensures that the heat is distributed more evenly throughout the entire room. -
Page 12: Installation
RAIS recommends to consult a building expert. When you choose where to set up your RAIS/attika wood burning stove, you should consider the heat distribution to the other rooms. This will enable you to get the best use out of your stove. -
Page 13: Installation Of Stove With Swivel Base
English RAIS/ - User manual for Q-BE Installation of stove with swivel base Swivel base for 90° turning. Open the backplate of the base. Remove the 2 wing screws (lock screws). Check that the stove can rotate. Swivel base for 360° turning. -
Page 14: Installation Distance
English RAIS/ - User manual for Q-BE Installation distance To determine whether the wall next to where the stove is going to be installed is flam- mable, you should contact your building contractor or the local building authorities. The hearth should be able to accommodate the weight of the stove. The chimney must be independently supported by wall brackets or a ceiling support plate. -
Page 15: Normal Set-Up (Corner Setting) - Combustible Wall
English RAIS/ - User manual for Q-BE Normal set-up (corner setting) - combustible wall Uninsulated flue A. Distance to furniture (min.) 750 mm Distance to flammable materials (min.) B. in front (floor) if distances are not shown, nation- al/local regulations are followed C. -
Page 16: Normal Set-Up (Corner Setting) - Non-Combustible And Combustible Wall
English RAIS/ - User manual for Q-BE Normal set-up (corner setting) - non-combustible and combustible wall Uninsulated flue Distance (min.) to Distance (min.) to non-flammable materials (X) flammable materials (Y) 50 mm 325 mm 100 mm 250 mm For example: at distance 50mm (X) to the non-combustible wall, the distance infront of the stove to the combustible wall must be 325 mm (Y). -
Page 17: Corner Setting 45°- Combustible Wall
English RAIS/ - User manual for Q-BE Corner setting 45°- combustible wall Uninsulated flue A. Distance to furniture (min.) 750 mm Distance to flammable materials (min.) B. in front (floor) if distances are not shown, national/ local regulations are followed C. -
Page 18: Corner Setting 45°- Non-Combustible Side Wall With Combustible Wall
English RAIS/ - User manual for Q-BE Corner setting 45°- non-combustible side wall with combustible wall Uninsulated flue Distance (min.) to Distance (min.) to non-flammable materials (X) flammable materials (Y) 50 mm 650 mm 100 mm 600 mm 150 mm... -
Page 19: Installation Distance - Combustible Ceiling
English RAIS/ - User manual for Q-BE Installation distance - combustible ceiling Uninsulated flue Distance to flammable materials (min.) H. to the ceiling 500 mm... -
Page 20: 360° Swivel Base
English RAIS/ - User manual for Q-BE 360° swivel base Uninsulated flue A. Distance to furniture (min.) 750 mm Distance to flammable materials (min.) B. in front (floor) if distances are not shown, national/ local regulations are followed C. to the side (floor) -
Page 21: Installation Distance In Case Of Non-Combustible Wall
English RAIS/ - User manual for Q-BE Installation distance in case of non-combustible wall We recommend a minimum distance to non-combustible material of 50 mm (F) for cleaning considerations. It should always be possible to access the access door. -
Page 22: For The Installer
English RAIS/ - User manual for Q-BE For the Installer Finally before firing the stove for the first time a check should be made to ensure that the assembly and stove installation has been satisfactory and that there are no leaks in any seals in the appliance and appliance connections to the chimney. -
Page 23: Drying And Storage
English RAIS/ - User manual for Q-BE ONLY USE RECOMMENDED FUELS The following table shows the calorific value of different types of wood, which have been stored for 2 years, and which have a residual moisture of 15-17%. Wood Kg dry wood pr. -
Page 24: Room Ventilation
English RAIS/ - User manual for Q-BE Tertiary air at the back of the burning chamber at the top (2 rows of holes) ensures the combustion of the final gas residues. The pilot nozzles are placed in the back plate and front of the combustion chamber. They ensure that the bed of glowing embers is fed with air and therefore holds a high temper- ature. -
Page 25: Lighting And Fuelling
English RAIS/ - User manual for Q-BE IMPORTANT - Warning Note! Properly installed, operated and maintained this appliance will not emit fumes into the dwelling. Occasional fumes from de-ashing and re-fuelling may occur. However, persis- tent fume emission is potentially dangerous and must not be tolerated. If fume emission does persist, the following immediate actions should be taken: Open doors and windows to ventilate room. -
Page 26: Control
English RAIS/ - User manual for Q-BE NOTE!! If the fire has burned down too low (too small an ember), it may take longer time to get the fire going again. When firing the smoke out of the chimney should be almost invisible; just a ’flicker’ in the air is opserved. - Page 27 “Specifications”. EXAMPLE OF DETERMINING THE RECOMMEN- DED VOLUME OF WOOD By reading the CE marking plate on the Q-Be (or finding the nominal output on our website), you will see that the stove has a nominal output of 5.9 kW. See an example of a CE marking plate on the next page.
- Page 28 English RAIS/ - User manual for Q-BE king plate and our website. Do not overfire Do not overfire the stove. The maximum volume of wood that may be burned in your stove can be www.rais.com found in the table below. If you stoke more wood than the volume specified in the table, you will overfire your stove.
- Page 29 English RAIS/ - User manual for Q-BE Warning!! If the firewood is only burning slowly without flames or is smoking, and too little air is added, unburned exhaust gasses are developed. Exhaust gasses can be ignited and explode, leading to damage to material and possibly personal injury.
-
Page 30: Cleaning And Care
English RAIS/ - User manual for Q-BE Cleaning and care Glass Most woodstoves use a ceramic glass product which is resistant to heat but requires cleaning to keep its appearance. Soot or opaque marks can easily cleaned if the marks are fresh, however If you leave... -
Page 31: Cleaning The Combustion Chamber
English RAIS/ - User manual for Q-BE Cleaning the combustion chamber Scrape/shovel the ash out and store it in a non-flammable container until it has cooled down. You can dispose of ash with your normal household waste. REMEMBER!! Never remove all the ashes from the combustion chamber - the wood will burn at its best with a layer of ashes of approx. -
Page 32: Interruption Of Operation
English RAIS/ - User manual for Q-BE Lift off the smoke barrier, pull forward, lower and remove. Remove dirt and dust, and mount the parts in reverse order. NOTE!! Be careful when replacing the smoke converter plate and smoke chikane... - Page 33 English RAIS/ - User manual for Q-BE Stove is burning too weakly could be caused by: • too small amount firewood • too little air supply for room ventilation • unclean smoke channels • leaky chimney • leakage between chimney and flue...
-
Page 34: Accessories Q-Be
English RAIS/ - User manual for Q-BE Accessories Q-BE 1617001 - Heat accumulation stone 8142390 - Swivel base connection PARTS LIST ITEM PART NUMBER TITLE Thk x L x W 1617001 Heat storage D M Y Corrections: Air kit 5 (wall) - Page 35 CHAUFFEZ EN RESPECTANT L’ENVIRONNEMENT! 3 conseils pour une combustion raisonnable et respectueuse - une question de bon sens aussi bien pour l’environnement que pour votre porte-monnaie 1. Allumage efficace. Utilisez de petits morceaux de bois (de sapin) et une briquette d’allumage appropriée, par exem- ple de la laine ou sciure de bois paraffine.
