CT - S1-76/CT - S1
Quick Start Guide
After reading this document, keep it in a safe place along with the warranty
certificate. Be sure to read the "Safety Precautions" in the separate "READ THIS!"
sheet, and use the product correctly.
Included Accessories
● AC adaptor
● Power cord (CT-S1-76 only)
● Leaflets
x AD-A12150LW (CT-S1-76)
● Music Stand
x READ THIS! Sheet
x AD-E95100L (CT-S1)
● Strap Lock (CT-S1 only)
x Other (Warranty, etc.)
Items included as accessories are subject to change without notice.
Separately Available Accessories
You can get information about accessories that are separately available for this product from your retailer
or from the CASIO website.
Preparation
Computer, smartphone, etc. (commercially available)
Preparing a Power Supply
• Connect using a USB cable that is no more than
two meters long.
„ Using the AC Adaptor
1
Connect the AC adaptor as shown in the right illustration.
● Make sure that you use only the AC adaptor specified
for this Digital Keyboard.
„ Using Batteries
Bottom of console
1
Open
2
Insert AA-size batteries into the battery case (CT-S1-76:
8 batteries/CT-S1: 6 batteries).
Tabs
3
Close
Back
4
Specify the battery type.
See "Specifying the Battery Type" on the reverse side of
this sheet.
● The illustration shows the CT-S1. The CT-S1 has 61 keys; the CT-S1-76 has 76 keys.
Basic Operation
P(Power) button
VOLUME knob
SURROUND button
Press to turn on power.
Rotate to adjust overall
Press for a more
Long-press to turn off
volume.
expanded sound.
power.
(Disabled while
headphones are
connected.)
Touch Response
Auto Power Off
Automatically turns off power after 20 minutes * of non-
Pressing a key harder produces louder sound, while a
softer key press produces softer sound.
use. (On, Off switchable)
* 30 minutes for the CT-S1
Useful Functions
For details about operations, refer to the User's Guide on the CASIO Website.
„ My Setup
Save the current setup (tone, etc.) for later recall.
„ Reverb
Output sounds using room, hall, and other acoustic effects.
„ Octave Shift
Raise or lower the pitch of the keyboard in octave units.
Please refer to the website below for more detailed operating instructions
and product information, including the USERʼS GUIDE, Dedicated App
(CASIO MUSIC SPACE) download, Operating Precautions, etc.
CT-S1-76
https://support.casio.com/global/en/emi/manual/CT-S1-76/
https://support.casio.com/global/en/emi/manual/CT-S1/
* For the CT-S1-76, connect the power cord to the AC adaptor.
Headphones (sold separately)
AC adaptor *
Portable audio player, etc. (commercially available)
Wireless MIDI & audio adaptor
(sold separately: WU-BT10)
METRONOME
Main tone buttons
button
Press a button to select
its tone.
Press to sound the
metronome.
Pedal
Sustains notes played while the pedal is depressed.
Even if the keys played are released, notes are
sustained as if the keys remain pressed, until the pedal
is released.
„ Transpose
Raise or lower the overall pitch in semitone steps.
„ Scale Tuning (Temperament)
You can set the scale tuning of the keyboard for music that uses a scale tuning other than
equal temperament.
EN
Practicing with the Metronome
1
CT-S1
2
Specify a beat value.
E1
While holding down...
3
Specify the tempo.
Pedal (sold separately)
E1
While holding down...
To install the music stand
Insert the stand into the holes on
the back of the console.
Example: To set a tempo of 80, press 8 (D5) and then 0 (C4), and then release METRONOME.
Selecting a Tone
To use the main tones to select an instrument
1
To select a tone using the keyboard keys
TONE VARIATION
button
Press to change to a
different variation of the
currently selected tone.
E1
While holding down...
Registering the Current Main Tone Setup to a Button (Tone Memory)
While holding down...
CT-S1-76
CT-S1
C2
C3
C4
CT-S1-76
CT-S1
0
1
2
3
4
5
6
C2
C3
C4 D4 E4 F4
G4 A4 B4
2
Select a variation.
Press to cycle through
available variations.
CT-S1-76
CT-S1
PIANO
E.PIANO
ORGAN
KEYBOARD
C2
C3
C4
Press the button of the tone you want to register.
− +
C5
C6
C7
G7
off, 1 - 16
7
8
9
C5
D5 E5
C6
C7
G7
20 - 255
See the procedure below for information
about using Tone Memory.
SYNTH/OTHERS
CASIO CLASSIC TONES
C5
C6
C7
G7
