Contents
1
1.1
System Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2
Performance Controller Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3
Sound Generator Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
3
4
II
5
6
7
7.1
Bank Select (00H,20H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.2
Modulation wheel or lever (01H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.3
Portamento Time (05H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.4
Data Entry (06H,26H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.5
Channel Volume (07H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.6
Pan (0AH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.7
Expression Controller (0BH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.8
Damper pedal (sustain) (40H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.9
Portamento On/Off (41H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.10
Sostenuto (42H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.11
Soft Pedal (43H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.12
Filter Resonance (47H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7.13
Release Time (48H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7.14
Attack Time (49H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7.15
Filter Cutoff Frequency (4AH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7.16
Portamento Control (54H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7.17
Reverb Send Level (5BH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7.18
RPN (64H,65H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
CT-S1
MIDI Implementation
CASIO COMPUTER CO., LTD.
1
3
3
3
3
3
5
5
5
6
6
6
6
6
7
7
7
7
8
8
8
9
9
9
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Casio CT-S1BK
Summary of Contents for Casio CT-S1BK
-
Page 1: Table Of Contents
CT-S1 MIDI Implementation CASIO COMPUTER CO., LTD. Contents Overview Product Configuration as a MIDI Device System Section ......... . - Page 2 12.3 CASIO General System Exclusive ....... 18 Setting Values and Send/ Receive Values Setting Value Tables 13.1...
-
Page 3: I Overview
Part I Overview Product Configuration as a MIDI Device As a MIDI device, this Instrument consists of the System Section, Sound Generator Section, and Per- formance Controller Section described below. Each of these sections can send and receive specific MIDI Messages in accordance with its function. - Page 4 Port Part number MIDI Receive Ch MIDI Transmit ch Assigned Function Details 1-16 Upper1 1-16 Upper2 Metronome Port Part number MIDI Receive Ch MIDI Transmit Ch Assigned Function Details Recorder System Track Upper1 Recorder System Track Upper2 Notification Tone Upper1 Selected Tone Upper2 Selected Tone...
-
Page 5: Timbre Type Specific Operation
Port Part number MIDI Receive Ch MIDI Transmit Ch Assigned Function Details MIDI/Auto Play MIDI/Auto Play MIDI/Auto Play MIDI/Auto Play MIDI/Auto Play MIDI/Auto Play MIDI/Auto Play MIDI/Auto Play MIDI/Auto Play MIDI/Auto Play MIDI/Auto Play MIDI/Auto Play MIDI/Auto Play MIDI/Auto Play MIDI/Auto Play MIDI/Auto Play Timbre Type Specific Operation... -
Page 6: Channel Message
Part II Channel Message Note Off Format Message Format: 8nH kkH vvH 9nH kkH 00H(receive only) MIDI Channel Number Key Number velocity Transmit Sent when something is played on the keyboard. The key number changes in accordance with on the Transpose function and Octave Shift function. Receive Receipt stops a note being sounded by a note on message. -
Page 7: Modulation Wheel Or Lever (01H)
Note1: For details about the relationship between the MSB value and the tone, see the Tone List that comes with the Instrument. Transmit Sent when a tone setup number is selected. Receive Receipt causes a change in the tone bank number stored in Instrument memory, but the tone is not actually changed until a Program Change message is received. -
Page 8: Pan (0Ah)
Pan (0AH) Message Format: BnH 0AH vvH MIDI Channel Number Value(Note1) Note1: For information about the relationship between setting values and send/receive values, see “13.5 Pan Setting Value Table” in “IV Setting Values and Send/Receive Values”. Receive Receipt changes the pan of the corresponding part. Expression Controller (0BH) Message Format: BnH 0BH vvH... -
Page 9: Portamento On/Off (41H)
– Piano note decay rate – Resonance characteristics and decay rate of Damper Resonance effect resonance note see “13.3 Sustain Pedal Setting Value Table” in “IV Setting Values and Send/Receive Values.” • Timbre Type: Drum The received message does not affect sound source operation. Portamento On/Off... -
Page 10: Filter Resonance (47H)
7.12 Filter Resonance (47H) Message Format: BnH 47H vvH MIDI Channel Number Value Receive Receipt changes the filter resonance intensity. 7.13 Release Time (48H) Message Format: BnH 48H vvH MIDI Channel Number Value (Note1) Note1: For information about the relationship between setting values and send/receive values, see the “13.4 –64 - 0 - +63 Setting Value Table”... -
Page 11: Portamento Control (54H)
7.16 Portamento Control (54H) Message Format: BnH 54H vvH MIDI Channel Number Source Key Number Receive Receipt of this message first stores the Source Note Number for the next note. When the next Note On is received, the portamento effect is applied to the note using this Source Note Number as the pitch start point and the Note On event key number as the end point. -
Page 12: All Sound Off (78H)
Message Format: BnH 64H 01H BnH 65H 00H BnH 06H mmH BnH 26H llH MIDI Channel Number MSB Value LSB Value Receive Receipt changes the fine tune of the corresponding part. 7.18.3 Channel Coarse Tune Message Format: BnH 64H 02H BnH 65H 00H BnH 06H mmH BnH 26H llH... -
Page 13: All Notes Off (7Bh)
Receive Receipt initializes each performance controller. 7.21 All Notes Off (7BH) Message Format: BnH 7BH 00H MIDI Channel Number Receive Receipt releases (key release) all voices that are sounding. 7.22 Omni Mode Off (All Notes Off ) (7CH) Message Format: BnH 7CH 00H MIDI Channel Number Receive Receipt performs the same operation as when All Notes Off... -
Page 14: Channel Pressure (Aftertouch)
Note1: For details about the relationship between the program number and the tone, see the Tone List that comes with the Instrument. Transmit Sent when a tone number is selected. Sent when the Program number send function is used. Receive Receipt changes the tone of the corresponding part. The selected tone is determined by the program value of this message and the Bank Select message value received prior to this message. - Page 15 Receive Receipt changes the pitch of the currently sounding note. The range of the pitch change depends on the bend range value setting.
-
Page 16: System Message
Instrument-specific formats. ID Number The ID numbers handed by this Instrument are shown below. ID Number ID Name Casio Computer Co. Ltd Non Real Time System Exclusive Message Real Time System Exclusive Message 12.1 Universal Real Time System Exclusive Message Message Format: F0H 7FH 7FH..F7H... -
Page 17: Universal Non Real Time System Exclusive Message
Transmit Sent when the tuning setting is changed. Receive Receipt changes the tuning setting. 12.1.3 Master Coarse Tuning Message Format: F0H 7FH 7FH 04H 04H llH mmH F7H LSB Value(Transmit:00H,Receive:Ignored) MSB Value(28H - 58H) Receive Receipt changes the Master Coarse Tuning parameter. 12.1.4 Reverb Type Message Format:... -
Page 18: Casio General System Exclusive
“1.3.2 Instrument Part Block” of this document. Note2: For information about the relationship between setting values and send/receive values, see “13.8 Reverb Type (CASIO General System Exclusive) Setting Value Table” in “IV Setting Values and Send/Receive Values” of this document. -
Page 19: Setting Values And Send/ Receive Values
Part IV Setting Values and Send/ Receive Values Setting Value Tables 13.1 0 - 127 Setting Value Table Receive Value DSP Parameter Value Parameter 00H - 00H 7FH - 7FH 13.2 Off/On Setting Value Table Transmit Value Receive Value Parameter 00H - 3FH 40H - 7FH 13.3... -
Page 20: Fine Tuning Setting Value Table
(30H, 7FH) (30H, 7FH) - (7FH, 7FH) 465.9 Hz 13.7 Reverb Type Setting Value Table Transmit Value Receive Value Parameter Small Room Medium Room Large Room Medium Hall Large Hall Plate 13.8 Reverb Type (CASIO General System Exclusive) Setting Value Table... - Page 21 Transmit Value Receive Value Parameter Room1 Room2 Room3 Hall1 Hall2 Plate1 Delay Pan Delay Plate2 Large Room1 Large Room2 Stadium1 Stadium2 Long Delay1 Long Delay2 Room4 Room5 Church Hall3 Hall4 Hall5 Hall6 Cathedral Stadium3 Tone...
-
Page 22: Midi Implementation Notation
Part V MIDI Implementation Notation Value Notation 14.1 Hexadecimal Notation MIDI implementation sometimes requires that data be expressed in hexadecimal format. Hexadecimal values are indicated by the letter “H” after the value. The hexadecimal equivalents of decimal values 10 through 15 are expressed as the letters A through F. The table below shows the hexadecimal equivalents for decimal values 0 through 127, which are often used in MIDI messages. - Page 23 Decimal Hexadecimal Binary 00000000B 00000001B 00000010B 00000011B 00000100B 00000101B 00000110B 00000111B 00001000B 00001001B 00001010B 00001011B 00001100B 00001101B 00001110B 00001111B 00010000B 01111101B 01111110B 01111111B...
