Elite Screens Light-On StarBright CLR 16 User Manual

Thank you for choosing the Lights-On Portable Series® projection screen!
StarBright CLR® 16, which is an optical lens front projection material precisely formulated for environments with
minimal control over room lighting. It was designed to filter and absorb overhead light while reflecting projector light
from standard throw projectors. It is best for family rooms, educational facilities, conference rooms or any applications
in which incident light is a factor.
Please read through this user guide before utilizing the screen. Correct usage and maintenance will ensure a long
product life.
Storage and Cleaning Instructions
Storage Conditions
StarBright CLR® 16 is primarily composed of optical-grade PET (Polyethylene Terephthalate) combined with UV-
molded resin, and it exhibits hygroscopic properties. Environmental factors such as humidity and temperature can
affect its structural integrity and optical properties. Therefore, please adhere to the following conditions during both
installation and storage:
➢ Temperature Variations: Keep temperature fluctuations within a range of no more than 41°F (5°C) per day to
avoid undue stress on the material.
➢ Avoid Excessive Relative
product's quality and performance.
➢ Limited Storage Duration: Do not store the roll material for more than 1 year to maintain its optimal
characteristics.
➢ Recommended Temperature and Humidity Levels:
Please refer to the table below for recommended temperature and humidity ranges.
Surface Cleaning
Extended exposure of this product to the atmosphere may lead to localized accumulation of dust or impurities, which
can affect the viewing experience. To maintain optimal surface cleanliness, you can employ the following methods:
➢ Use a Soft Cleaning Brush: Gently brush the surface with a soft cleaning brush to remove any surface-adhered
dust or impurities.
➢ Damp Cloth Cleaning: Dampen a clean, soft cloth with water and wipe the surface. Afterward, use an air gun
or dust blower to ensure thorough drying.
➢ Adhesive Dust Removers: Utilize adhesive dust removers or traceless adhesive tape to pick up and remove any
dust or impurities adhering to the surface.
By following these cleaning methods, you can ensure that the product remains free from surface contaminants and
maintains its optimal viewing quality, even after extended exposure to environmental conditions.
Notes: Elite Screens is not responsible for damages due to negligence resulting from misuse or
mishandling of the product and will void your warranty.
▪ Don't touch the screen material with your bare hands to avoid leaving oil residue from fingertips.
Use gloves when handling the material.
▪ Don't point to the screen material with a fingertip or other sharp objects to prevent damage to the material.
▪ Don't use acetone, benzene, alcohol and any other organic solvents to clean the screen material.
Using such chemicals will permanently damage the screen.
▪
After using the screen, disassemble it and store it in the carrying bag provided.
▪
To avoid damage and injury, the screen should only be operated by adults.
Rev.05202024JA
Portable Indoor Ceiling Ambient Light Rejecting Screen
Visit
Humidity: Prevent exposure to high relative humidity levels to preserve the
Item
Temperature
Relative Humidity
wwww.elitescreens.com
Lights-On
Folding-frame model: LPS123H-SBCLR16
User's Guide – M type V1.0
www.elitescreens.com
The screen material included is our
Storage conditions
50° - 95°F (10°-35 C)
25 - 80%
Portable Series®
for latest updated version.
U00274 1
