1. ADD COFFEE BEANS
1.1 Unlock and remove the upper protection cover.
1.2 Remove the coffee bean hopper lid.
1.3 Pour the beans into the hopper.
For better results, we recommend using fresh,
non-oily coffee beans, from light to medium roast.
1.4 Put the coffee bean hopper lid back in place.
1.1
2. TEST WATER
2.1 Pour water from the machine's water source into a container.
2.2 Immerse the test strip in the water. Wait 1 second.
2.3 Remove the test strip and see how many squares appeared on it.
2.4 Consult the table to know the hardness of the water.
2.2
Installation Guide
1.2
2.3
1.3
2.4
QR Code to User Manual
1.4
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for EVOCA Saeco MAGIC
Summary of Contents for EVOCA Saeco MAGIC
- Page 1 Installation Guide QR Code to User Manual 1. ADD COFFEE BEANS 1.1 Unlock and remove the upper protection cover. 1.2 Remove the coffee bean hopper lid. 1.3 Pour the beans into the hopper. For better results, we recommend using fresh, non-oily coffee beans, from light to medium roast.
-
Page 2: Connect The Machine
4.4 Set the value measured at step 2.3 into the dropdown menu, click Ok, then Save at the top right corner. 4.5 Close the right panel and replace the drip tray. The Saeco Magic M2+ can either be installed using the internal water tank... - Page 3 Installation Guide INTERNAL WATER TANK SET-UP If you want to connect your machine to the water mains, follow instructions on page 5. 5.1 INSTALL WATER FILTER (NOT INCLUDED) WATER FILTER NOT INCLUDED For optimal machine performance, we recommend using a water filter. Water filter model: Intenza+ Part number: 21002661 5.1.1 Remove the lid from the water tank.
-
Page 4: Add Water
Installation Guide INTERNAL WATER TANK SET-UP If you want to connect your machine to the water mains, follow instructions on page 5. 5.2 ADD WATER 5.2.1 Thoroughly rinse and fill with fresh water. DO NOT exceed the level (MAX) indicated at the back of the tank. 5.2.2 Put the water tank back in place. -
Page 5: Connect Water
Installation Guide WATER MAINS SET-UP If you want to connect your machine to the water mains, follow instructions on page 3. 5.1 CONNECT WATER 5.1.1 Remove the cap from the coupling on the appliance rear part. 5.1.2 Connect the water supply hose to the main water supply’s 3/4 threaded coupling. 5.1.3 Open the water supply. - Page 6 Installation Guide WATER MAINS SET-UP If you want to connect your machine to the water mains, follow instructions on page 3. 5.3 ADD WATER 5.3.1 Using the handles, lift the tank out of the machine. 5.3.2 Thoroughly rinse the tank, then pour in 2 liters of water. 5.3.3 Put the water tank back in place.
- Page 7 Installation Guide WATER MAINS SET-UP If you want to connect your machine to the water mains, follow instructions on page 3. 5.5 ENABLE WATER MAIN 5.5.1 Access the programming menu again. 5.5.2 Enter the password of the technical profile, if needed, then go into the menu 3.7 - Other Settings. 5.5.3 Choose Water mains from the dropdown menu, then click Ok.
-
Page 8: Test The Unit
Saeco is a trademark licensed by Koninklijke Philips N.V. Evoca North America Evoca Group Headquarters 2355, avenue Dalton, Québec (Québec) G1P 3S3, Canada Via Roma, 24, 24030 Valbrembo BG Italy Saeco Magic Installation Guide T: 800-561-6162 - F:800-463-2739 T: +39035606111 - F: +39095606560 www.evocagroupna.com www.evocagroup.com...
