REVERSE OSMOSIS FILTER AND CARBON FILTER CARTRIDGE REPLACEMENT
1. Ensure the water faucet is turned off and the indicator light reflects
standby mode (not on or blinking).
2. Grip the handle and rotate the filter cartridge counter clockwise.
3. Pull cartridge out of the unit.
NOTE: Due to the pressure relief you may see a few drops of water
when removing the cartridge. To minimize water drops, keep the
filter upright and handle end down.
4. Insert the new filter replacement into the filtration unit with the fitting
end first. (see Figure 1)
5. Rotate the cartridge clockwise while applying slight pressure until
the cartridge locks into place.
NOTE: Cartridge must be rotated to the horizontal position.
6. Repeat 2 through 5 for other filter.
7. Press and hold the CF filter life indicator for 5 seconds. Once
complete, the indicator light will turn blue and there will be 1 beep.
Immediately press and hold the RO filter life indicator for 5 seconds.
Once complete, the indicator light will turn blue and there will be 1
beep. An automated flush will begin, lasting approximately 5 min-
utes.
8. Turn on the faucet and perform a system flush for 30 minutes after
the new carbon filter and reverse osmosis cartridges are installed.
9. Your water is ready to use!
Figure 1
1
2
2
1
05/08/2024
115897
X00115897
SCAN TO ACCESS THE
PERFORMANCE DATA SHEET
CLARIFI: CARBON FILTER, REVERSE OSMOSIS
FILTER & PRE-FILTER FOR TANKLESS REVERSE
OSMOSIS SYSTEM
Carbon Filter (CF) Model Number: DWQ300202
Reverse Osmosis (RO) Filter Model Number: DWQ300102
Pre-Filter Model Number: DWQ300350
Only for use with Delta Clarifi Tankless Reverse Osmosis System:
DWQ1001012
Operating Temperature: 41°F to 100°F (5 °C to 38 °C)
Operating Pressure: 20 to 87 PSI (0.14 MPa to 0.6 MPa)
VOC Carbon Filter
Filter Life: 2 years or
1,320 gallons
Pre-Filter
Filter Life: 6 years
or 13,208 gallons
Reverse Osmosis Filter (RO)
Filter Life: 2 years or 1,320 gallons
1
X
X
115897 Rev. B
