Summary of Contents for SEFAM S.Box
- Page 2 Minimum pressure if the APAP (Auto- Tap the touch key CPAP) mode was selected. You can decrease or increase the displayed value by tapping repeatedly the Possible settings: from 4 cm H O to the maximum Pressure. Information and settings Sefam S.Box...
- Page 3 Possible settings: from 4 cm H O to the maximum pressure adjusted in APAP mode (Auto- CPAP). from 4 cm H O to the prescribed pressure in CPAP mode. Sefam S.Box Information and settings...
- Page 4 15 (tube 15 mm in diameter) 22 (tube 22 mm in diameter) CS (Circuit Select). If you select Circuit Select CS, the touch key is displayed on the screen. Tap it to run the specific calibration. Information and settings Sefam S.Box...
- Page 5 Possible settings: LOCK and UNLOCK. Choosing the format of time display Tap the touch key The time display is set to 24 hours by default. You can select another format by tapping the key Possible Settings: 24H and 12H. Sefam S.Box Information and settings...
- Page 6 The offset value of the pressure sensor is Tap the touch key displayed approximately two seconds later. Unchangeable value: from 1500 to 2500 (default value 2000). If a offset problem occurs on the pressure sensor, the value is no longer displayed : Information and settings Sefam S.Box...
- Page 7 YES to go back to the factory configuration NO if you wish to keep all data and the pairing of accessories. Total machine hour counter Tap the touch key This counter calculates the operating time of the device. Sefam S.Box Information and settings...
- Page 8 Displayed parameter: Adjusted by Available displays: Heating power of the heated OFF, 01 to 05 and AUTO (if tube (when S.Box heated humidifier installed) in standby or tube with ATC installed) operating mode Humidification level...
-
Page 9: Cleaning And Maintenance
Make sure that the patient follows carefully the instructions given in this chapter. The patient should refer to the user guide for instructions on maintenance for the mask, the breathing tube, the S.Box heated tube with ATC and the communicating accessory. WARNING: Unplug the device from the power supply. - Page 10 Do not use spray detergent. Harmful residues could enter and remain in the air outlet, the air inlet filter or inside of the device, which could cause air way irritation. Never use concentrated bleach higher than 0.1%. For example: pour 200 ml of bleach to 2.6% in 5 liters of cold water. Sefam S.Box Cleaning and maintenance...
-
Page 11: Spare Parts
M-316450-01 Internal frame ASSY S.Box (Ext) M-316490-03 Flow sensor S.Box (Ext) M-315940-01 Inlet air filters (50 pcs) M-316400-02 Air inlet filter grid S.Box (Ext) M-316400-01 Rear cover S.Box (Ext) M-316430-01 Bottom cover S.Box (Ext) M-316440-01 Top cover S.Box (Ext) M-216430-09 S.Box USB cable... -
Page 12: Using The Sd Card
Service card A SD card can be configured as a "service card" using the SEFAM Analyze software, in order to set up a collection of devices with the same default parameters. This allows adjusting only the parameters software. - Page 13 Manufacturer: Manufacturing plant: SEFAM SEFAM 144 AV CHARLES DE GAULLE 10 ALLÉE PELLETIER DOISY 92200 NEUILLY SUR SEINE 54600 VILLERS-LES-NANCY FRANCE FRANCE : M-164MAT00-10-Version 1 2018-01...
