- Page 1 Installer guide Easee One...
-
Page 2: Warnings And Cautions
Introduction Read the Important product information guide in the product packaging or at support.easee.com before installing the product. Installation of this product requires a mobile device with NFC or Bluetooth support. WARNINGS AND CAUTIONS A Warning indicates a condition, hazard or unsafe practice that can result in serious personal injury or death. -
Page 3: Product Overview
Product overview Front cover Chargeberry Backplate Protects the electronics from Contains the electronics For attaching and connecting to external influences. for charging the vehicle. the charging infrastructure. Installation kit Strain relief Blind plug Sealing plug Strain relief and Wall screws Front cover tool front cover (T25) -
Page 4: Technical Specifications
Load balancing of up to 3 units per circuit Built-in energy meter (±2 %) Connectivity Built-in eSIM (LTE Cat M1/ 2G /GPRS) WiFi 2.4 GHz b/g/n connection Easee Link RF Control charging via Easee App RFID/NFC reader OCPP 1.6J via our API Bluetooth BLE 4.2... - Page 5 Protection Integrated protection for open / break fault condition in supply PEN conductor according to BS 7671:2018/A1:2020 Built-in RCD for ground fault protection (30 mA AC/ 6 mA DC) Degree of protection IP54 (the backplate is IP22 without cover) Impact resistance IK10 Insulation class Overvoltage category...
-
Page 6: Planning The Installation
Installer App. Example for 230 V TT / TN-S, deviating values for other — Easee One is specifically designed to comply with grid types. clause 722.411.4.1 of BS 7671:2018 A1 (British Standard). It includes a protection mechanism to completely... - Page 7 The integrated RCD has no influence on the function of external protective devices. — An external RCD is required when at least one of the below conditions are identified: • The installation, including cable, junction boxes etc., includes components with only basic insulation (Class I).
-
Page 8: Installation Instructions
Installation Charging Robot Opening instructions Bend down the lower part of the rubber cover and WARNING insert the two ends of the front cover tool into the Always work with the power off and in two openings at the bottom of the front cover. accordance with local regulations. - Page 9 Use suitable a good seal. wall plugs for mounting and observe the local Insert the cable through one of the 4 cable entries regulations for recommended installation height. and secure it to the backplate with the strain relief provided.
- Page 10 Backplate TT / TN-S network Wiring Strip each wire, exposing 12 mm of copper on each. If the cable has flexible conductors, then you must use ferrules on stranded wires to make the connection. Use the correct tools to press them. Tighten the screw terminals with a torque of 5 Nm.
- Page 11 Update existing site: If this site already has one or more Backplate Charging Robots installed or if it has been created by Configuring an operator (Easee Charge), select "Update existing site" and search for the site address. On "Site overview", select the circuit that you want the backplate to be part of and select "Add another backplate".
- Page 12 Turn on the power. The terminals of the backplates Chargeberry are now electrically live. Attaching Remove the PIN code sticker and attach it to the inside of the fuse cabinet, or another safe location for storage. Position the Chargeberry to fit into the slots on the WARNING backplate located in the center of the installation.
- Page 13 Hang the front cover at the top of the backplate and Front cover let it fall into place. Closing Press the bottom of the front cover until you hear a click. Bend the lower part of the rubber cover down. Screw in the front cover screw at the bottom of the Before closing the front cover, it is possible to lock charger to secure the front cover.
- Page 14 Easee Keys. Type 2 socket: The Type 2 socket is completely universal and allows you to charge any type of electric vehicle using the appropriate charging cable.
- Page 15 Contact customer support. General error. Unplug the charging cable and replug it to the Red – constant light Charging Robot. If the red light persists, check the Easee App or our knowledge base for further information.
- Page 16 White – flashing light, only at the bottom the status of the master unit. For further information, please check our knowledge base Yellow – flashing light, only at the bottom The Charging Robot is waiting to be configured. Easee public knowledge base can be found at support.easee.com.
- Page 17 Easee or its subsidiaries in writing. Any permitted use shall always be done in accordance with good practice and ensure that no harm may be caused to Easee or by misleading the consumer. Easee and Easee products, product names, trademarks and slogans, whether registered or not, are Easee’s intellectual...
