SONOMA CLAREMONT C-SPRING CHAIR CHAT SET ASSEMBLY INSTRUCTIONS
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
PART LIST
A
B
C
D
E
F
G
H
I
J
FOR MISSING OR INCORRECT PARTS/HARDWARE, CONTACT THE MANUFACTURER'S CUSTOMER SERVICE DIRECTLY AT
REFER TO LAST PAGE FOR ADDITIONAL CUSTOMER SERVICE DETAILS.
SAVE THESE INSTRUCTIONS
FIGURE
QUANTITY
8 PCS + 1 PC
2 PCS + 1 PC
2 PCS + 1 PC
1-866-905-4107 OR WWW.YOTRIOINT.COM
1 PC
1 PC
1 PC
1 PC
REAR LEG CONNECTOR
FLAT WASHER + SHORT BOLT
FLAT WASHER + LONG BOLT
1 PC
1 PC
1 PC
DESCRIPTION
RIGHT ARM
LEFT ARM
CHAIR FRAME
(M6*20MM)
(M6*30MM)
LEG LEVELER
ALLEN WRENCH
BACK CUSHION
SEAT CUSHION
Page 1/6
