SONOMA CORONADO GLIDER ASSEMBLY INSTRUCTIONS
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
FIGURE
PART LIST
A
B
C
D
E
F
G
H
I
J
SAVE THESE INSTRUCTIONS
QUANTITY
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
2 PCS
2 PCS
8 PCS + 1 PC
6 PCS + 1 PC
DESCRIPTION
RIGHT ARM
LEFT ARM
BACK
SEAT
RIGHT LEG
LEFT LEG
LEG SUPPORT
GLIDER
SHORT BOLT
(M6*15MM)
MEDIUM BOLT
(M6*30MM)
Page 1/5
Advertisement
Table of Contents
Related Manuals for Sonoma Coronado
Summary of Contents for Sonoma Coronado
- Page 1 SAVE THESE INSTRUCTIONS SONOMA CORONADO GLIDER ASSEMBLY INSTRUCTIONS ASSEMBLE ON A FLAT, PROTECTED SURFACE. FIGURE DESCRIPTION PART LIST QUANTITY 1 PC RIGHT ARM 1 PC LEFT ARM 1 PC BACK 1 PC SEAT 1 PC RIGHT LEG LEFT LEG 1 PC...
- Page 2 LONG BOLT 2 PCS + 1 PC (M6*40MM) BOLT 8 PCS + 1 PC (M6*18MM) 8 PCS + 1 PC PLASTIC WASHER 8 PCS + 1 PC WASHER 1 PC ALLEN WRENCH FOR MISSING OR INCORRECT PARTS/HARDWARE, CONTACT THE MANUFACTURER'S CUSTOMER SERVICE DIRECTLY AT 1-866-905-4107 OR WWW.YOTRIOINT.COM REFER TO LAST PAGE FOR ADDITIONAL CUSTOMER SERVICE DETAILS.
- Page 3 ASSEMBLY INSTRUCTIONS (CONTINUED) SONOMA CORONADO GLIDER ASSEMBLY INSTRUCTIONS STEP 1 A. PLACE SEAT (D) UPSIDE DOWN ON A FLAT, PROTECTED SURFACE. B. PLACE LEFT ARM (B) UPSIDE DOWN. ATTACH FRONT OF LEFT ARM (B) TO THE FRONT LEFT SIDE OF THE SEAT (D) USING MEDIUM BOLTS (J) AND ALLEN WRENCH (O).
- Page 4 ASSEMBLY INSTRUCTIONS (CONTINUED) SONOMA CORONADO GLIDER ASSEMBLY INSTRUCTIONS STEP 4 A. PLACE THE CHAIR LEGS ON A FLAT, PROTECTED SURFACE. B. ATTACH THE RIGHT LEGS (E) AND LEFT LEGS (F) TO THE LEG SURPORTS (G) BY LINING UP THE BOLT HOLES ON THE LEGS WITH CORRESPONDING BOLT HOLES ON THE LEG SUPPORTS (G).
- Page 5 ASSEMBLY INSTRUCTIONS (CONTINUED) SONOMA CORONADO GLIDER ASSEMBLY INSTRUCTIONS STEP 7 A. ROTATE GLIDER TO UPRIGHT POSITION. B. ASSEMBLY IS COMPLETE. ** WE RECOMMEND THAT YOU SAVE THE ALLEN WRENCH AND PERIODICALLY TIGHTEN ALL BOLTS. WEIGHT LIMIT 500 LBS CARE AND CLEANING FRAME: WIPE CLEAN WITH A MILD SOAP AND WATER SOLUTION, RINSE WITH CLEAN WATER, AND DRY THROUGHLY.
