Sonoma CLAREMONT Assembly Instructions

Glider

Table of Contents

Download this manual

SONOMA CLAREMONT GLIDER ASSEMBLY INSTRUCTIONS

ASSEMBLE ON A FLAT, PROTECTED SURFACE.

PART LIST

FIGURE

SAVE THESE INSTRUCTIONS

QUANTITY

1 PC

2 PCS

6 PCS + 1 PC

2 PCS + 1 PC

8 PCS + 1 PC

DESCRIPTION

RIGHT ARM

LEFT ARM

BACK

SEAT

BASE

GLIDER

FLAT WASHER + MEDIUM BOLT

(M6*20)

FLAT WASHER + LONG BOLT

(M6*40)

SHORT BOLT (M6*18)

PLASTIC WASHER

Page 1/5

Table of Contents

Do you have a question about the CLAREMONT and is the answer not in the manual?

Page 1 SAVE THESE INSTRUCTIONS SONOMA CLAREMONT GLIDER ASSEMBLY INSTRUCTIONS ASSEMBLE ON A FLAT, PROTECTED SURFACE. PART LIST FIGURE QUANTITY DESCRIPTION 1 PC RIGHT ARM 1 PC LEFT ARM 1 PC BACK 1 PC SEAT 1 PC BASE 2 PCS GLIDER FLAT WASHER + MEDIUM BOLT...
Page 2 ASSEMBLY INSTRUCTIONS (CONTINUED) SONOMA CLAREMONT GLIDER ASSEMBLY INSTRUCTIONS PART LIST FIGURE QUANTITY DESCRIPTION 8 PCS + 1 PC FLAT WASHER 1 PC ALLEN WRENCH 1 PC SEAT CUSHION 2 PCS BACK CUSHION FOR MISSING OR INCORRECT PARTS/HARDWARE, CONTACT THE MANUFACTURER'S CUSTOMER SERVICE DIRECTLY AT 1-866-905-4107 OR WWW.YOTRIOINT.COM...
Page 3 ASSEMBLY INSTRUCTIONS (CONTINUED) SONOMA CLAREMONT GLIDER ASSEMBLY INSTRUCTIONS STEP 1 A. PLACE RIGHT ARM (A) UPSIDE DOWN ON A FLAT, PROTECTED SURFACE. B. ATTACH SEAT (D) TO RIGHT ARM (A) WITH FLAT WASHERS AND MEDIUM BOLTS (G) USING ALLEN WRENCH (L). DO NOT TIGHTEN COMPLETELY.
Page 4 ASSEMBLY INSTRUCTIONS (CONTINUED) SONOMA CLAREMONT GLIDER ASSEMBLY INSTRUCTIONS STEP 3 A. CAREFULLY ROTATE THE ASSEMBLED UNIT ONTO ITS FRONT. B. ATTACH LONG ARM OF GLIDER (F) TO BOTTOM OF RIGHT ARM (A) WITH PLASTIC WASHERS (J), FLAT WASHERS (K), AND SHORT BOLTS (I) USING ALLEN WRENCH (L).
Page 5 ASSEMBLY INSTRUCTIONS (CONTINUED) SONOMA CLAREMONT GLIDER ASSEMBLY INSTRUCTIONS STEP 5 A. TURN GLIDER TO ITS UPRIGHT POSITION SO THAT IT STANDS STABLE ON THE FLOOR. B. PLACE SEAT CUSHION (M) ON SEAT (D) AND ATTACH TIES TO BACK CROSSBAR THEN PLACE BACK CUSHIONS (N).
