Port Status and Activity LED not lit for a port that has
a connection. Check that you are using a 'straight-through'
cable which is properly connected at both ends, and is not
damaged. Refer to "Twisted Pair (TP) Cables" on page 11.
Also check that the equipment connected to the Switch is
powered on, operating correctly and contains the correct
type of connection. Refer to Figure 5 below to compare the
wiring of a straight-through and a crossover cable.
Figure 5
Straight-through Cable/Crossover Cable
