Change for life
User's Manual
Window type Air Conditioner
Model No. : GWF07CV GWF09CV
GWF12CV GWF18CV
GWF24CV
Thank you for choosing our product.
Please read this User's Manual carefully before operation and
e r
a t
n i
t i
o f
r r
f e
erence.
If you lost the User's Manual, please contact the Tool Box
or visit www.gilman-group.com
the electronic version.
r o
e s
n
d
a
n
email to Tool Box for
Advertisement
Table of Contents
Related Manuals for Gree GWF07CV
Summary of Contents for Gree GWF07CV
- Page 1 Change for life User's Manual Window type Air Conditioner Model No. : GWF07CV GWF09CV GWF12CV GWF18CV GWF24CV Thank you for choosing our product. Please read this User's Manual carefully before operation and erence. If you lost the User's Manual, please contact the Tool Box or visit www.gilman-group.com...
-
Page 3: Table Of Contents
CONTENTS Thank you for choosing Gree Air Conditioner, Our product is designed for the room comfortables. Please read the operating manual carefully before operating the unit and keep it for reference. Structure mechanism and Installation Precautions Function Operating condition power requirement... - Page 4 Explanation of Symbols Indicates a hazardous situation that, if not avoided, will DANGER result in death or serious injury. Indicates a hazardous situation that, if not avoided, could WARNING result in death or serious injury. Indicates a hazardous situation that, if not avoided, may CAUTION result in minor or moderate injury.
-
Page 5: Precautions
Precautions Warning Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. The air conditioner should be installed in accordance with local regulations. Air Conditioner should be properly grounded. Incorrect grounding may cause electric shock. -
Page 6: Function
Function Introduction Autumn Window type room air conditioners can regulate the room Spring Summer Winter Room temperature and dry the room. It can be widely used in residence , temp. office and designated purpose. Wind direction Dehumidifying in rainy or Cooling in summer humid season Without reducing the room temp., air conditioner can... -
Page 7: Operating Condition
Operating Condition Please operate air conditioner in the correct conditions as following. DRY mode operation COOL mode operation Outdoor temperature should be in range of 18 Outdoor temperature should be in range of 18 to 43 to 43 , otherwise it is possible for air conditioner otherwise it is possible for air conditioner to malfunction and breakdown. -
Page 8: Installation
Installation Installation precaution: Improper installation of air conditioner will cause serious damage！ Please associate the profes- sional technician to install the unit and don’t install it by yourself. Otherwise, we are not responsible for the damage due to inappropriate handling Location: The condensation water must be drained away appropirately Avoid other heat sources or direct sun light. - Page 9 Installation procedure: Remove the sticker from the front panel. Put the unit into the installation hole. n i l , t i Wall down to the back to avoid the enlargement of Sunshade board noise or vibration. (Slant between 6-10mm.) Shown at right figure.) The installation place should be strong enoug h Rubber plate...
- Page 10 Drain water for Option 1: To maximize the cooling efficiency, the air conditioner is designed to splash the condensate on the condenser coil. If the splashing sound annoys you, you can install an outside drain by using the following procedure, which may however cause a small loss of performance.
-
Page 11: Notes For Installation
Notes for installation Remove Before removing air conditioner to the other place, you should contact local service center or qualified personnel firstly. Then it must be done under the direction of the professional technician. In addition, the charge of this must be paid. Noise Install in a location where is firm enough to avoid the enlargement of noise and vibration. -
Page 12: Part Identification
Part identification Panel outlook picture, just for reference, please take the real unit as standard. Cabinet Air filter (behind the front intake Air inlet grille) louver Front intake Front grille grille Remote control panel Air direction adjustment Adjust air direction up and down The vertical airflow direction is controlled by the vane,It is used for discharging the airflow upwards,downwards or straight out... -
Page 13: Remote Control Operation Procedure
Remote control operation procedure Note: This ia a general purpose remote controller, it could be used for various air conditioner features.For those features that the model doesn't have, the unit will remain the original running status when pressing the corresponding button on the remote controller On/Off button Mode button + / - button... - Page 14 ● Dry: Under this mode, the unit runs in low fan speed for dehumidification and the corresponding indicator is on; under dry mode, the fan speed cannot be adjusted. ● Fan Only:air conditioner will not made cool or heat, only blow out the wind. Fan indicator will on and fan speed can be adjusted when you press "Fan Speed".
- Page 15 Timer button Under ON status, press this button to set timer OFF; Under OFF status, press this button to set timer ON. Press this button once and the characters of HOUR ON (OFF) will flash to be displayed. Meanwhile, press “+” button or “-” button to adjust timer setting (time will change quickly if holding “+”...
- Page 16 Replacement of batteries in remote controller 1. Press the back side of remote controller marked signal sender battery the cover of battery box along the arrow direction. reinstall 2. Replace two 7# (AAA 1.5V) dry batteries, and make sure the position of "+" polar and "-" polar remove are correct.
-
Page 17: Remote Control Panel
Remote control panel Note: If wireless remote controller is lost, you can use the remote control panel and operate manually. ON/OFF BUTTON Operation starts when pressing this button, and stops when pressing this button again. SWING BUTTON Activate the automatic air swing function. FAN SPEED BUTTON Select the fan speed LOW,MID, HIGH and AUTO in sequence. - Page 18 FILTER BUTTON This feature is a reminder to clean the Air Filter (See Care and Cleaning) for more efficient operation and cooling. The LED (light) will illuminate after 250 hours of operation. To reset after cleaning the filter, press the "Check Filter" button and the light will go off.
-
Page 19: Operation Tips
Operation Tips Operation for comfort and economy Do not overcool the room Keep blind or curtains closed . Keep the unified room temperature. Adjust the temperature. This is not good Do not let sunshine enter the vertical and horizontal for health and cause electricity room directly when the air con- airflow direction to ensure wastage... -
Page 20: Caution
Caution Operations for safety and health 1) The plug must be accessible after the appliance is positioned. 2) Do not use this appliance in the laundry. 3) If the power cord is damaged, it must be replaced by the local service center and qualified personnel in avoid of hazard. Do not pull out the power cord. -
Page 21: Care And Maintenance
Care and maintenance Always turn off the air conditioner and main power supply before cleaning to ensure safety. Cleaning unit Cut power off before cleaning. Air filter The air filter behind the intake grille should be washed at Plug out only after least once every two weeks or as often as it needs cleaning. -
Page 22: Troubleshooting Guide
Troubleshooting guide Please check the following items before asking for repair,it saves your time and money. Fault phenomenon Trouble-shooting Is there a power failure? Is the plug out? Air conditioner does not Is power fuse or switch off ? operate at all. Whether the voltage is too high or too low? Is air inlet or outlet locking? Is there any other heat source in room? -
Page 23: After Service
Malfunction code Solution Please contact professional person to deal with it. Please contact professional person to deal with it. Please contact professional person to deal with it. Please contact professional person to deal with it. Please contact professional person to deal with it. Please contact professional person to deal with it. - Page 24 Please record the following product information ● Model ● Serial No. ● Name of the franchiser ● Date of purchase The continuous improvement of products , such as function is changed, without prior notice, if there are any questions, please contact customer service ,Sorry for the inconvenience please forgiveness ToolBox Customer Service Centre：...
