B173-8601
For safe and correct use of this machine, please be sure to read the Safety
Information in this Guide before you use it.
AC104/AC017/DSm516pf
Aficio FX16/DSm516pf/
AC016/IS 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aficio FX16 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ricoh Aficio FX16

  • Page 1 AC104/AC017/DSm516pf Aficio FX16/DSm516pf/ AC016/IS 2016 For safe and correct use of this machine, please be sure to read the Safety Information in this Guide before you use it. B173-8601...
  • Page 2: Table Of Contents

    Safety Information ..........ii Safety During Operation ........ii Positions of Labels and Hallmarks for WARNING and CAUTION Labels ........ v Control Panel Functions ........... 1 Changing the Display Language ........ 2 About the Software ..........3 System Requirements ..........4 Installing Software in Windows .........
  • Page 3: Safety Information

    Safety Information When using this machine, the following safety precautions should always be followed. Safety During Operation In this manual, the following important symbols are used: WARNING: Indicates a potentially hazardous situation which, if instructions are not followed, could result in death or serious injury. CAUTION: Indicates a potentially hazardous situation which, if instructions are not followed, may result in minor or moderate injury or damage to property.
  • Page 4 CAUTION: • Protect the machine from dampness or wet weather, such as rain and snow. • Unplug the power cord from the wall outlet before you move the machine. While moving the machine, you should take care that the power cord will not be damaged under the machine.
  • Page 5 In the event of problems, please contact your service representative in the first instance. DSm516pf/AC016/Aficio FX16 : The CE declaration of Comformity is available on the Internet at URL : http://www.ricoh.co.jp/fax/ce_doc IS 2016 : The CE declaration of Comformity is available on the Internet at URL :...
  • Page 6: Positions Of Labels And Hallmarks For Warning And Caution Labels

    Positions of Labels and Hallmarks for WARNING and CAUTION Labels This machine has labels for WARNING and CAUTION at the positions shown below. For safety, please follow the instructions and handle the machine as indicated. In accordance with IEC 60417, this machine uses the following symbols for the main power switch: means POWER ON.
  • Page 7 NOTICE Note to users in the United States of America Notice: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 8: Control Panel Functions

    Control Panel Functions Allows you to enter fax number, and shows memory status and fax reception mode. Adjusts the resolution of the documents for the current fax job. Allows you to send a fax to multiple destinations. • Allows you to store frequently-dialed fax numbers using a one or two-digit speed dial or group number for automatic dialling and edit the stored numbers.
  • Page 9: Changing The Display Language

    Scrolls through the options available for the selected menu item. Confirms the selection on the display. Enters Menu Mode and scrolls through the menus available. Sends you back to the upper menu level. Redials the last number in Standby Mode or inserts a pause into a fax number in edit mode.
  • Page 10: About The Software

    About the Software You must install software using the supplied CD-ROM after you have set up your machine and connected it to your computer. The CD-ROM includes: • Type 101 Software • Operating Instructions • Adobe Acrobat Reader The CD-ROM provides you with the following software: Type 101 Driver To use your machine as a printer and scanner in Windows, you must install the Type 101 driver.
  • Page 11: System Requirements

    System Requirements Before you begin, ensure that your system meets the minimum requirements. Supported Operating System • Windows 95 OSR2 • Windows 98/Windows 98 SE • Windows Me • Windows NT 4 Workstation or Server with Service Pack 3 • Windows 2000 Professional or Advanced Server •...
  • Page 12: Installing Software In Windows

    Installing Software in Windows OTES • Cancel the “New Hardware Found” window when your computer boots up. • Make sure that your machine is plugged in and connected to your computer’s parallel port or USB port before installing software. Windows 95 and Windows NT 4.0 do not support the USB connection.
  • Page 13 Choose the installation type. •Typical: Installs the common software for your printer, such as printer driver, Twain driver, Remote Control Panel. This is recommeded for most users. •Custom: Allows you to choose the language of the software and the components you want to install. After selecting the language and the component(s), click Next.
  • Page 14: Removing Software

    Removing Software Uninstall is required if you are upgrading the software or if your installation fails. You can uninstall all software of this machine, using the CD-ROM or uninstall the desired item using the Windows unInstallShield. You can select Start → Programs → Type 101 → Maintenance.
  • Page 15: Viewing The Operating Instructions

    Viewing the Operating Instructions The following Operating Instructions, which is in Adobe Acrobat PDF format, come with your machine in the supplied CD-ROM. Place the CD-ROM in the CD-ROM drive. : If your machine is not connected to the computer, the following window will appear.
