Greenfire
Gas Fireplace
www.regency-fire.com.au
WARNING:
If the information in these instructions are not followed exactly,
a fire or explosion may result causing property damage,
personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use petrol or other flammable vapors and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
919-670f
GF1500LST
®
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
MODELS: GF1500LST-NG
GF1500LST-LP
GF1500LST-ULPG
LISTINGS AND CODE APPROVALS
These gas appliances have been tested
in accordance with AS 5263.0 & AS/NZS
5263.1.3 and have been certified by IAPMO
R&T Oceana for installation and operation as
described in these Installation and Operating
Instructions.
Must be installed as per AS/NZS 5601
Your unit should be serviced annually by
an authorised service person.
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance.
Do not touch any electrical switch.
Do not use any phone in your
building.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the fire department.
October 12, 2021
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Regency Fireplace Products Greenfire GF1500LST
Summary of Contents for Regency Fireplace Products Greenfire GF1500LST
- Page 1 Greenfire GF1500LST ® Owners & Installation Manual Gas Fireplace MODELS: GF1500LST-NG GF1500LST-LP GF1500LST-ULPG LISTINGS AND CODE APPROVALS These gas appliances have been tested in accordance with AS 5263.0 & AS/NZS 5263.1.3 and have been certified by IAPMO R&T Oceana for installation and operation as described in these Installation and Operating Instructions. Must be installed as per AS/NZS 5601 Your unit should be serviced annually by an authorised service person. www.regency-fire.com.au WARNING: FOR YOUR SAFETY If the information in these instructions are not followed exactly, What to do if you smell gas: a fire or explosion may result causing property damage,...
- Page 2 To the New Owner: Congratulations! PAIRING YOUR REMOTE CONTROL You are the owner of a state-of-the-art Gas Fireplace by REGENCY . The GF1500LST has been designed to provide you with ® all the warmth and charm of a wood fireplace at the flick of a switch. The model GF1500LST has been approved by IAPMO R&T Oceana for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. Please take a moment now to acquaint yourself with these instructions and The control box will only learn the Remote ID codes during the first 30 seconds after power is applied the many features of your Regency Fireplace. ® and will ignore this special command from the Remote after the first 30 seconds. To match the control box to the remote, follow the steps below : 1.
- Page 3 WARNING DO NOT turn your fireplace on via any means or allow to be turned on unless you have conducted a thourough inspection of the area sur- rounding the fireplace immediately prior to its use, and you have satisfied yourself that there are no materials or other items in proximity to the fireplace which could present a fire risk. DO NOT turn your fireplace on via any means or allow to be turned on if there are any unsupervised children, infirm or pets in the area sur- rounding the fireplace. DO NOT use this fireplace, unless you have read this Manual, and strictly adhere to the user requirements and warnings set out in this Manual. RELEASE Without limiting any other acknowledgement, release or indemnity given by you, or limitation of liability, in favour of Fireplace Products Pty Ltd (''Company''), you irrevocably and unconditionally acknowledge and agree that failure to comply with, or strictly adhere to, the requirements and warnings set out in this Manual (''User Requirements'') may result in: 1. damage to the fireplace; 2. damage to property; 3. a house fire; 4. severe burns or other personal injury; and/or 5. death. Subject to any remedy, guarantee, term, condition, warranty, undertaking, inducement or representation, implied or imposed by any legisla- tion which cannot lawfully be excluded or limited, and to the maximum extent permitted by law: 1. the Company will not be liable for any damage, personal injury or death arising out of or in connection with your failure to comply with any User Requirement; and 2. you release the Company from all claims, actions, proceedings, liabilities, losses and damages in relation to death, any personal injury or property damage arising out of or in connection with your failure to comply with any User Requirement. Regency GF1500LST Gas Fireplace...
-
Page 4: Table Of Contents
table of contents Installation Aeration Adjustment ............31 Pairing the Remote Handset and Control Box ID Code . 2 Conversion Kit from NG to LP/ULPG......32 Copy of Data Badge ............5 Optional Fan Ducting Kit Installation ......34 Unit Dimensions ............6 Log Set Installation ............37 Important Message ............7 Front Trim Removal / Installation .........39 General Safety Information ..........7 End Panel Removal / Installation .........39 Installation Checklist ............8 Faceplate and Deflector Installation ......40 Locating Your Gas Fireplace ..........8 Screen & Inner Door Frame Installation ......41 Clearances ..............9 Optional Finishing Trim Installation ......42 Mantel Clearances ............10 Operating Instructions Mantel Leg Clearances . -
Page 5: Copy Of Data Badge
safety decal This is a copy of the data badge that accompanies each GF1500LST Direct Vent Gas Fireplace. We have printed a copy of the contents here for your review. NOTE: Regency ® units are constantly being improved. Check the badge on the unit and if there is a difference, the badge on the unit is the correct one. COPY OF DATA BADGE Regency Gas Fireplace Distributed by: Model Western Australia: Air Group Australia ULPG Gas Type 28 Division St GF1500LST-NG GF1500LST-LP GF1500LST-ULPG Welshpool, WA 6106 Model Eastern Australia Gas Consumption High 50 MJ/h 49 MJ/h 44 MJ/h Fireplace Products... -
Page 6: Unit Dimensions
DIMENSIONS dimensions UNIT DIMENSIONS 325mm SIDE B 1267mm SIDE A 1532mm 1439mm 39mm 39mm 1152mm SIDE B SIDE A SIDE A Dimension drawings shown without fascias NOTE: DUE TO NATURE AND DESIGN OF THE GF1500LST DOUBLE SIDED UNIT, SIDE A PROJECTS MORE HEAT THAN SIDE B ON THE UNIT. -
Page 7: Important Message
installation 11. Under no circumstances should this IMPORTANT MESSAGE YOUNG CHILDREN SHOULD BE appliance be modified. Parts that have to be SAVE THESE INSTRUCTIONS CAREFULLY SUPERVISED WHEN removed for servicing should be replaced prior to operating this appliance. THEY ARE IN THE SAME AREA The GF1500LST™ Direct Vent Fireplace must be AS THE APPLIANCE. -
Page 8: Installation Checklist
installation This includes: INSTALLATION CHECKLIST 3. The GF1500LST Direct Vent Gas Fireplace can be installed as follows: 1. Clocking the appliance to ensure the correct 1. Locate appliance firing rate (rate noted on label) after burning a) Room location (Refer to "Locating Your appliance for 15 minutes. Gas fireplace" section) b) Clearances to Combustibles (Refer to 114mm 2. If required, adjusting the primary air to ensure 914mm "Clearances" section) that the flame does not carbon. First allow c) Mantle Clearances (Refer to "Mantel the unit to burn for 15-20 min. to stabilize. Glass Clearances" section) d) Framing & Finishing Requirements CAUTION: Any alteration to the product that (Refer to "Framing & Finishing" section) causes sooting or carboning that results... -
Page 9: Clearances
installation CLEARANCES The clearances listed below are minimum distances unless otherwise stated: A major cause of chimney related fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this fireplace and flue system be installed only in accordance with these instructions. Caution Requirements WARNING The sides of the fireplace are defined by standoffs. The... -
Page 10: Mantel Clearances
installation MANTEL CLEARANCES Combustible Material Due to the extreme heat this fireplace emits, the mantel clearances 330mm 25mm 25mm 330mm are critical. Combustible mantel clearances from top of front facing are shown in the diagram on the right. 305mm 305mm Note: Ensure the paint that is used on the mantel and the facing is "high quality" or the paint may discolour. Combustible Stud (On Edge) -
Page 11: Unit Assembly Prior To Installation
installation UNIT ASSEMBLY PRIOR TO INSTALLATION The nailing strips must be correctly positioned and attached before unit is slid into position. NAILING STRIPS The nailing strips come attached to the unit. The top and side nailing strips are secured to the framing. IMPORTANT NOTE Framing depth measurement is noted with the nailing strips set as far forward on the firebox as possible. The nailing strips can be adjusted back up to 38mm to allow for varying thicknesses in non-combustible material & wall finishes. Nailing Strips (DO NOT REMOVE NAILING STRIPS) tooltip INSTALLATION ACCESS PANEL The unit is equipped with a removable access panel for pre-finish installa- tion of optional components. This panel is located on the lower front face of Side B only. -
Page 12: Framing Dimensions
installation FRAMING DIMENSIONS GF1500LST Framing Dimensions Framing Depth * 516mm **minus the combined material thickness of both sides Framing Height 1011mm Framing Width 1545mm Gas Connection Height 87mm Gas Connection Inset 124mm Gas Connection Opening 89mm Width Gas Connection Opening 67mm Height Minimum height to 1600mm combustible (enclosure) * Framing depth measurement is noted with nailing strips (top & sides) set as far forward on the firebox as possible. The nailing strips can be adjusted back up to 38mm (on both sides) to allow for varying thicknesses in non- combustible material and wall finishes. **Finished material thickness includes: non combustible material, tile slate, etc. A minimum thickness of 12mm non-combustible facing board compliant with AS1530-1 and AS1530-3 is required. -
Page 13: Optional Framing Kit
GF1500LST installation OPTIONAL FRAMING KIT OPTIONAL FRAMING KIT 2 Install the 2 long horizontal studs, secure with 2 screws on each end. An optional framing kit is available for the GF1500LST. Note: There are diff erent confi gurations for horizontal exit venting vs vertical exit venting and options in the framing width to accommodate various thick- nesses of fi... - Page 14 installation GF1500LST 4. Set unit in place, center within framing from each side and also back to 6. Completed framing kit. front–install 2 (two) wide studs above and below the unit as shown with 2 (two) screws on each side - repeat on opposite side. Wide Studs 5.
-
Page 15: Non Combustible Facing Installation
installation NON COMBUSTIBLE FACING INSTALLATION IMPORTANT IMPORTANT NOTE: Prior to installation of non-combustible materials by others, Regency Fireplace Products are designed, produced, tested, and certified to the highest industry standards. The finishing of the walls surrounding check and inspect carefully for any hairline cracks and or Regency is as critical as the installation itself. The temperatures around damage to board. The non combustible board must be a mini- linear gas fireplaces are typically higher than would be acceptable for the mum of 12mm thick and comply with AS1530-1 and AS1530-3. -
Page 16: Framing & Finishing
installation FRAMING & FINISHING 1. Frame in the enclosure for the unit with framing material. Note: It is beneficial to install the unit, gas connection and flue to the unit prior to the wall facing being installed. 2. For exterior walls, insulate the enclosure to the same degree as the rest of the house, apply vapour barrier and plasterboard, as per local installation codes. (Do not insulate the fireplace itself.) WARNING: Failure to insulate and add vapor barriers to the inside of the exterior wall will result in operational and per- formance problems including, but not limited to: excessive condensation on glass doors, poor flame package, carbon,... -
Page 17: Combustible Requirements
installation FRAMING & FINISHING Finished Nailing Strip Material Position 12mm 25mm Nailing Strip 25mm Forward Unit 25mm 12mm Nailing Strip 12mm Forward Note: Unit The siding nailing strips are factory set at 12 mm. The top nailing strip is fixed during transit to the rear of the appliance. 38mm 0mm (flush) Note: Nailing Strip Depending on the material used for finishing, the nailing Flush w/unit strips must be set accordingly so that the finished material Factory Set is always at the 38 mm edge of the flange. -
Page 18: Exterior Flue Termination Locations
installation EXTERIOR FLUE TERMINATION LOCATIONS FIGURE 6.2 (in part): LOCATION OF FLUE TERMINALS OF BALANCED FLUE AS/NZ 5601, ROOM-SEALED, FAN ASSISTED, OR OUTDOOR APPLIANCE Regency GF1500LST Gas Fireplace... -
Page 19: Clearances
installation CLEARANCES Minimum clearances (mm) Ref. Item Natural Fan Draught Assisted Below eaves, balconies and other projections: Appliances up to 50 MJ/h input Appliances over 50 MJ/h input From the ground, above a balcony or other surface* From a return wall or external corner* From a gas meter (M) (see Note 5) (see Clause 5.11, 5.9 for vent terminal location of regulator) 1000 1000 (see Table 6.7 for New Zealand requirements) † From an electricity meter or fuse box (P) (see Note 5) From a drain or soil pipe Horizontally from any building structure* or obstruction facing a terminal From any other flue terminal, cowl, or combustion air intake Horizontally from an openable window, door, non-mechanical air inlet, or any other opening into a building with the exception of sub-floor ventilation: Appliances up to 150MJ/h input*... -
Page 20: Flue Restrictor Settings
installation FLUE RESTRICTOR SETTINGS Screw Positions Flue restriction is required for certain flueing installations, see the diagrams in the "Flueing Arrangements" section to determine if they are required for your installation. The Flue Restrictor plate is located on the inside top of the firebox. To set the flue restriction as indicated in the flueing arrangements diagrams, refer to the following instructions; Set 0 Fully open (Factory set) 1. R emove one glass door and end panels - see instructions in this manual. -
Page 21: Flueing Arrangements
installation FLUEING ARRANGEMENTS HORIZONTAL TERMINATION (FLEX) Regency Direct Vent System ® These flueing systems, in combination with GF1500LST, have been tested and listed as a Direct Vent system by IAPMO R&T Oceana. The location of the termination cap must conform to the requirements in the Flue Terminal Locations diagram from the "Exterior Flue Termination Locations" section. Regency Direct Vent (Flex) System Termination Kits includes all the parts needed to install the GF1500LST using a flexible vent. ® FPI Kit # Length Contains: #946-615 1.2 m 1) 203mm flexible outer liner (Kit length) 2) 127mm flexible inner liner (Kit length) -
Page 22: Rigid Pipe Flueing Systems
installation RIGID PIPE FLUEING SYSTEMS BASIC HORIZONTAL & VERTICAL TERMINATIONS Rigid Pipe Flue Systems offer a complete line of component parts for installation of both horizontal VerticalTerminal and vertical installations. Many items are offered in decorative black, as well as galvanized finish. The minimum components required for a basic Horizontal Termination are: Flashing -Not Supplied AstroCap XL Termination Cap 90 degree Elbow Rigid Pipe Adaptor (Dura Vent Only) Wall Thimble PipeLength Flue Guard - Optional Length of rigid pipe to suit wall thickness (Part#946-506/P) Part 946-604/P The minimum components required for a basic AstroCap XL Vertical Termination are:... -
Page 23: Flueing Introduction
installation FLUEING INTRODUCTION The GF1500LST uses the "balanced flue" technology Co-Axial system. The inner liner vents products of combustion to the outside while the outer liner draws outside combustion air into the combustion chamber thereby eliminating the need to use heated room air for combustion and losing warm room air up the flue. Note: These flue pipes must not be connected to any other appliance. The gas appliance and flue system must be vented directly to the outside of the building, and never be attached to a flue system serving a separate solid fuel or gas burning appliance. Each direct vent gas appliance must use it's own separate flue system. Common flue systems are prohibited. FLUEING ARRANGEMENT FOR HORIZONTAL TERMINATIONS The diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 90 (two 45 elbows equal one 90 elbow). Note: Must use optional rigid pipe adapter (Part# 770-994) when using Simpson DuraVent Only. Restrictor Set #1 50mm-Open Restrictor Set #0... -
Page 24: Horizontal Venting With Two (2) 90 Elbows
installation Horizontal Venting with Two (2) 90 Elbows One 90 elbow = Two 45 elbows. Option H + H1 With these options, maximum 0.6m min. 0.6m max. total pipe length is 4.5m with minimum of 1.5m of vertical. 0.9m min. 1.2m max. 1.2m min. 1.8m max. Please note min. 0.3m between 90 elbows is 1.5m min. 3.0m max. required. Lengths do not include Restrictor Set 0 elbow indicated. -
Page 25: Installation Instructions Gf1500Lst
installation FLO-MET DIRECT FLUE TOP EXIT VERTICAL FLUE KIT INSTALLATION INSTRUCTIONS GF1500LST This flue kit has been manufactured for use with GF1500LST and to be installed in accordance with AS/NZS 5601. To ensure safety and correct unit operation this flue kit must be installed as outlined in these instructions. Heater and flue clearances from combustible materials must be in accordance with these instructions and AS/ NZS 5601. 1. L ocate the heater in its proposed position and mark the point for penetration Gas Cowl Flomet Cap directly above the centre of the heater flue outlet. Check the heater location 58DVA-VCH allows the outer flue to clear all structural timber and combustible surfaces by 51mm minimum. Last Length of Outer Note: Duravent 2. I f the enclosure consists of a ceiling – cut a 305mm square hole (minimum) for... -
Page 26: Venting Arrangements
installation VENTING ARRANGEMENTS ALLOWABLE VERTICAL TERMINATIONS The shaded area in the diagram shows all allowable combinations of straight vertical and offset to vertical Horizontal (Metres) elbows, with Rigid Pipe Venting terminations, using two 90 Systems. Two 45 elbows equal to one 90 elbow. Maximum 1 1 . . 5 5 of four 45 elbows allowed. 7 7 . -
Page 27: Unit Installation With Horizontal Termination
installation UNIT INSTALLATION WITH HORI- 7. Ensure that the pipe clearances to com- bustible materials are maintained (Diagram ZONTAL TERMINATION 3). Install the termination cap. (Rigid Flue Systems) The four wood screws provided should be re- A top clearance of 76mm and side & bottom placed with appropriate fasteners for stucco, clearance of 51mm must be maintained; except brick, concrete, or other types of sidings. when passing through a wall, ceiling, or at the termination where the use of a wall thimble reduces the required clearance to 38mm. -
Page 28: Unit Installation With Vertical Termination
installation Note: For best results and optimum UNIT INSTALLATION WITH Roof Pitch Minimum Flue Height performance with each approved VERTICAL TERMINATION flueing system, “Mill-Pac” sealant to Meters (Rigid Systems) every inner pipe connection. Failure flat to 7/12 0.61 to do so may result in drafting or Note: A clearance of 51mm must be performance issues not covered maintained. -
Page 29: Unit Installation
installation 8) Do the same with the 203mm liner. UNIT INSTALLATION NOTE: Horizontal sections must be sup- ported at intervals not exceeding (With Horizontal Termination Flex 9) Apply a bead of silicone between the thimble 0.9 meter. (Flame picture and per- System) and termination and around the outer edge formance will be affected by sags in of the terminal at the wall in order to keep the liner). Note: A top clearance of 76mm and the water out. -
Page 30: High Elevation
installation PILOT ADJUSTMENT NOTE: Do not screw in nut too far. If no pressure GF1500LST-NG SYSTEM DATA increases after two full terms, place manometer Min. Supply Pressure 1.13 kPa on inlet test point on gas valve and check flow- Periodically check the pilot flames. Correct flame ing inlet pressure. -
Page 31: Wiring Diagram
installation WIRING DIAGRAM DISCONNECT POWER SUPPLY TO UNIT PRIOR TO WORKING ON ELECTRICAL COMPONENTS. ORANGE BLUE MODULATING VALVE GREEN ORANGE COIL BROWN SIGMA 845 BROWN BROWN BROWN (NO) BROWN BROWN (NO) BROWN BROWN SPARKER PRESSURE SWITCH FAN 1 BROWN PRESSURE SWITCH FAN 2 MODULE - SPARK PILOT FLAME MODULE - FLAME SENSOR SIT 201 IGNITION MODULE MODULE - GROUND... -
Page 32: Conversion Kit From Ng To Lp/Ulpg
GF1500LST installation CONVERSION KIT FROM NG TO LP/ULPG CONVERSION KIT FROM NG TO ULPG FOR GF1500LST USING SIT 845 NOVA GAS VALVE FOR GF1500LST USING SIT 845 NOVA GAS VALVE THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! 5. - Page 33 GF1500LST installation 9. Reinstall new burner orifi ce LP/ULPG and tighten. NOTE: Do not screw in nut too far. If no pressure increases after two full turns, Place manometer on inlet test point on gas 10. Replace the yellow "NG" label with the red "LP or ULPG" label. valve and check fl...
-
Page 34: Optional Fan Ducting Kit Installation
installation GF1500 OPTIONAL FAN DUCTING KIT INSTALLATION OPTIONAL FAN DUCTING KIT INSTALLATION LISTINGS AND CODE GENERAL INFORMATION Maximum Duct Run: 9.0m Kit Contains 4.5m APPROVALS The Fan Kit increases the eff ectiveness of your fi replace by dispersing warm air from the fi replace If you require more than 4.5m please purchase Fan This Fan Kit has been approved for use with to remote locations in the same room or other... - Page 35 installation GF1500 OPTIONAL FAN KIT INSTALLATION 9. On the top of the unit, bend the 3 tabs up. Insert the NOTE: Installation of Fan Kit should be done prior Duct collar. Secure the collar to the 3 tabs with screws. Air Duct to installation of the wall.
- Page 36 OPTIONAL FAN KIT INSTALLATION installation FAN DUCT EXTENSION KIT In order to use the fan extension duct kit, you must have fan kit. This kit allows you to extend the fan duct to 9m. 2. Attach the 4.5m duct within this kit to the connecting collar on the opposite 1.
-
Page 37: Log Set Installation
GF1500LST installation LOG SET INSTALLATION LOG SET INSTALLATION Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs may create carbon build-up and can alter the unit's performance which is not covered under warranty. Log kit # 696-930 contains the following pieces: Side B Description... - Page 38 GF1500LST installation 5. Place Log 5 in the landing spot in the burner, located on the far right 8. Place Log 8 in the landing spot in the burner, located on the left side of side of Log 1 as shown in Diagram 5. Place embers on burner - loca- Log 1 as shown in Diagram 9.
-
Page 39: Front Trim Removal / Installation
installation FRONT TRIM REMOVAL / INSTALLATION 1. Remove faceplate, inner door frame, and glass door if already installed - see instructions in this manual. 2. Lift out 2 side panels and remove two (2) screws in locations shown below to remove front trim piece. 3. Reverse steps to reinstall. Remove - 2 screws Front Trim Piece Diagram 1 - Front Trim Screw Locations END PANEL REMOVAL / INSTALLATION 1. Remove front trim piece - see instructions above. 2. Remove two (2) screws in locations shown below to release panel clips. Panel Clip 3. Remove panels by sliding out. Panel Clip Screw Locations 4. Reverse steps to reinstall. -
Page 40: Faceplate And Deflector Installation
GF1500 installation FACEPLATE AND DEFLECTOR INSTALLATION FACEPLATE AND DEFLECTOR INSTALLATION 1. Install the fascia to the unit by hooking the left and right side 5 screws mounting brackets into the mounting slots at the side of the firebox as shown below. Diagram 4 Diagram 4 3 Mounting Slots... -
Page 41: Screen & Inner Door Frame Installation
installation SCREEN & INNER DOOR FRAME INSTALLATION 1. Hang Screen Mesh over Inner Door Frame as shown in Diagram 1. 3. Install Screen and Inner Door Frame to unit but hanging over glass door frame as shown in Diagram 3. Lower gently once in position over glass door frame. Diagram 1 2. Bend Tab on Screen Mesh to 90º as shown in Diagram 2. Secure to Diagram 3 Inner Door Frame with one (1) screw as shown in Diagram 2a. 4. Repeat on opposite side. Diagram 2 Diagram 2a Regency GF1500LST Gas Fireplace... -
Page 42: Optional Finishing Trim Installation
installation OPTIONAL FINISHING TRIM INSTALLATION 1. I nstall the optional finishing trim by lining up trim with the outside of the fascia. Press trim inward firmly to seat onto the unit. Finishing Trim Installed 2. P ull trim outward–away from the unit to remove. Regency GF1500LST Gas Fireplace... -
Page 43: Operating Instructions Operating Instructions
operating instructions OPERATING SUMMARY OF FIRST FIRE INSTRUCTIONS CONTROLS The FIRST FIRE in your heater is part of the Before operating this appliance, proceed through On/Off Button paint curing process. To ensure that the paint is the following check list. If the unit is switched off, pressing and releasing properly cured, it is recommended that you burn this button once will switch the unit ON. If the unit your fireplace for at least four (4) hours the first 1. R ead and understand these Instructions before will start at maximum flame height and maximum time you use it. operating this appliance. fan speed and after about 20 seconds, resume it's previous flame and fan settings. When first operated, the unit will release an 2. C heck to see that all wiring is correct and enclosed odour caused by the curing of the paint and the to prevent possible shock. -
Page 44: Copy Of Lighting Plate Instructions
operating instructions RESETTING THE UNIT NORMAL OPERATING SOUNDS OF COPY OF LIGHTING PLATE GAS APPLIANCES INSTRUCTIONS If the appliance detects a fault and goes into 'lockout', the control system will need to be rest It is possible that you will hear some sounds from by depressing the reset button. your gas appliance. This is perfectly normal due to FOR YOUR SAFETY READ BEFORE LIGHTING the fact that there are various gauges and types of The black reset button is located near the bottom steel used within your appliance. Listed below are right hand corner of the glass on Side A of the unit. some examples. All are normal operating sounds This appliance must be installed in accordance with the current AS/NZS 5601 and should not be considered as defects in your... -
Page 45: Maintenance
maintenance FAN SERVICE NOTE: THIS UNIT HAS 2 FANS PRIOR TO SERVICING THE FAN, ENSURE THAT UNIT HAS COOLED 7. Remove 2 screws to release fan bracket. TO ROOM TEMPERATURE, ALL POWER IS DISCONNECTED AND tooltip GAS SUPPLY IS TURNED OFF. 1. R emove faceplate, inner frame, glass door, front trim piece and end panels on one side- see instructions in this manual. 2. Remove logs. 3. Remove burner side panels by lifting out as shown in Diagram 1. tooltip 8. Lift fan out. -
Page 46: Glass Door Installation
maintenance GLASS DOOR INSTALLATION WARNING: Do not operate the appliance with the glass panels removed, cracked or broken. Replacement of the glass panels should be done by a licensed or qualified service person. Glass should be cool, if cleaning is necessary. There are 2 glass doors on the GF1500LST, one side is removed with a latch tool and the opposite side is removed by removing the screws securing the door. -
Page 47: Valve Tray Replacement
maintenance VALVE TRAY REPLACEMENT 6. Remove 12 screws securing valve tray. PRIOR TO SERVICING THE FAN, ENSURE THAT UNIT HAS COOLED TO ROOM TEMPERATURE, ALL POWER IS DISCONNECTED AND GAS SUPPLY IS TURNED OFF. 1. R emove faceplate, inner frame, glass door, front trim piece and end panels on one side- see instructions in this manual. 2. Remove logs. 3. Remove burner side panels by lifting out as shown in Diagram 1. tooltip 7. Lift out valve tray to remove. Diagram 1 - Burner Side Panels tooltip 4. Remove burner by removing 2 screws in locations shown below. -
Page 48: Maintenance Instructions
maintenance MAINTENANCE INSTRUCTIONS GLASS GASKET GENERAL FLUE MAINTENANCE If the glass gasket requires replacement use a Conduct an inspection of the flueing system semi- 1. Always turn off the gas valve before cleaning. tadpole glass gasket (Part # 936-157). annually. Recommended areas to inspect as For relighting, refer to lighting instructions. Keep follows: the burner and control compartment clean by brushing and vacuuming at least once a year. 1. Check the Flueing System for corrosion in areas that are exposed to the elements. These will 2. Clean appliance and door with a damp cloth GLASS DOOR appear as rust spots or streaks, and in extreme (never when unit is hot). Never use an abrasive... -
Page 49: Troubleshooting Guide
maintenance Troubleshooting Guide________________ TROUBLESHOOTING GUIDE ALL WORK MUST BE CARRIED OUT BY A LICENSED/QUALIFIED TECHNICIAN It is critical that this appliance is earthed and that Active and Neutral are not crossed Pilot light models only SYMPTOM CAUSE SOLUTION Unit does not operate No power supply (240V) to Check 240V power supply (No ignition &... - Page 50 maintenance Troubleshooting Guide________________ TROUBLESHOOTING GUIDE Unit ignites, main burner becomes Incorrect burner pressure Adjust burner pressure to correct unstable, flame lifts off burner, unit settings setting (See Data plate) goes into lockout Flue blocked, Incorrect flue Clear blocked flue, install flue installation or flue joints not correctly and seal all flue joints sealed...
-
Page 51: Gas Maintenance
Gas Maintenance maintenance GAS MAINTENANCE - RECOMMENDED ANNUAL ROUTINE Recommended Annual Routine Maintenance for Gas Fireplaces, Stoves and Inserts In order for your Regency appliance to continue to provide comfort to your home periodic maintenance must be performed to ensure it is operating at peak efficiency. The items in the list should be checked by a licensed gas service technician during the annual service check. Your unit may require more frequent maintenance checks if you notice any changes in how it operates. Operational changes to look for can include, but are not limited to, extended start up time, increased fan noise, residue/carbon build up, white build up on the glass/firebox, increased operating noise etc. Should any of these or other conditions arise, discontinue use and schedule a service check with your local licensed gas technician. The list below shows items your licensed service technician will need to check and service at least annually. Clean Inspect Check • Glass • Pilot assembly • Voltage on thermocouple/thermopile (mil- • Interior bricks / panels • Burner livolt models) • Burner ports & burner air shutter •... -
Page 52: Electronic Components
parts list PARTS LIST ELECTRONIC COMPONENTS PARTS LIST Note: Depending on the model, the diagram shown below may not depict the actual parts - for reference purposes only. 910-936 910-082 911-146 911-224 (NG) 911-225 (LP) 910-089 910-088 910-912 910-084 911-101 910-526 910-080 911-227 910-514 911-183 910-083 910-521, 910-522, 910-523 911-121 FG38 FG39 PG33 PG36 / PG121/ GFI300L IG34 GF900L/C GF1500LST PG36D PG131... -
Page 53: Main Assembly
parts list PARTS LIST MAIN ASSEMBLY Part # Description 696-045 Front Deflector 696-574/P Valve Assembly - NG 696-004 Left Ceramic Insulation Filler 696-576/P Valve Assembly - LP Part # Description 910-080 845 Sigma Valve Only - NG 696-052 Right Ceramic Insulation Filler 910-081 845 Sigma Valve Only - LP 696-044 Clip Brick Panel (Each) 911-224 Pilot Assembly NG 3 Flame 696-066 Valve Assembly Gasket 911-225 Pilot Assembly LP 3 Flame 696-019F Valve Access Plate 904-777 Burner Orifice #29 - NG 696-069 Valve Access Plate Gasket 904-434 Burner Orifice #47 - LPG 696-005 Fan Access Plate 904-431... - Page 54 parts list PARTS LIST MAIN ASSEMBLY SIDE A SIDE B Regency GF1500LST Gas Fireplace...
-
Page 55: Accessories
parts list PARTS LIST ACCESSORIES Part # Description 32 606-922 Inner door frame - Black w/ Screen 606-932 Inner door frame - Stainless w/ Screen 33 606-544 Door Frame Overlay - Black 34 606-938 Fascia and Door Frame Black w/Screen 606-936 Fascia and Door Frame Stainless Steel w/Screen * 606-951 Fascia Black Glass (not shown) Regency GF1500LST Gas Fireplace... -
Page 56: Warranty
WARRANTY warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (“the manufacturer”) through its wholly owned subsidiary, Fireplace Products Australia Pty Ltd (for Australia and New Zealand customers) and sold under the Regency® brand of fireplace products (collectively referred to herein as “FPI”), extends this Limited Lifetime Warranty to the original purchaser of this appliance provided the product remains in the original place of installation. - Page 57 WARRANTY warranty Any part(s) found to be defective during the warranty period as outlined above will be repaired or replaced at FPI’s option through an accredited distributor, dealer or pre-approved and assigned agent provided that the defective part is returned to the distributor, dealer or agent for inspection if requested by FPI. Alternatively, FPI may at its own discretion fully discharge all of its obligations under the warranty by refunding the verified purchase price of the product to the original purchaser.
- Page 58 WARRANTY warranty earthquakes, floods, lightning strikes/bolts or acts of terrorism or war, which result in malfunction of the appliance are not covered under the terms of this Limited Lifetime Warranty. FPI has no obligation to enhance or modify any unit once manufactured (i.e. as products evolve, field modifications or upgrades will not be performed on existing appliances).
- Page 59 WARRANTY warranty Limitations of Liability: 1. Exclusion of implied terms The customer may have the benefit of consumer guarantees under the Australian Consumer Law. To the maximum extent permitted by law, all terms, conditions or warranties that would be implied into this Warranty or in connection with the supply of any goods or services by the supplier under law or statute or custom or international conventions are excluded.
- Page 60 WARRANTY warranty How to Obtain Warranty Service: Customers should contact the authorised selling dealer to obtain warranty service. In the event the authorised selling dealer is unable to provide warranty service, please contact FPI by mail at the address listed below. Please include your name, address, purchase date, selling dealer, serial #, type of unit, a brief description of the problem, email and telephone contact information, and a copy of your original tax invoice.
- Page 61 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 64 IMPORTANT: A certificate of compliance or equivalent by an authorised installer must be obtained on commissioning of appliance to obtain warranty. Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial #: ____________________________________________________________ Regency is a registered trademarks of FPI Fireplace Products International Ltd. © Copyright 2021, FPI Fireplace Products International Ltd. All rights reserved.
