CHERUBINI MODO RX Instructions Manual

Tubular motor with electronic limit switch for rolling shutters
Hide thumbs Also See for MODO RX:
Table of Contents

Advertisement

Quick Links

Download this manual
MODO RX
MOTORE TUBOLARE PER AVVOLGIBILI CON
IT
FINECORSA ELETTRONICO
TUBULAR MOTOR WITH ELECTRONIC LIMIT SWITCH
EN
FOR ROLLING SHUTTERS
ROHRMOTOR FÜR ROLLLADEN MIT
DE
ELEKTRONISCHER ENDLAGENEINSTELLUNG
MOTEUR TUBULAIRE POUR VOLET ROULANT
FR
AVEC FINS DE COURSE ÉLECTRONIQUES
MOTOR TUBULAR PARA PERSIANA CON
ES
FIN DE CARRERA ELECTRÓNICO
ISTRUZIONI - INSTRUCTIONS - EINSTELLANLEITUNGEN
INSTRUCTIONS - INSTRUCCIONES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MODO RX and is the answer not in the manual?

Questions and answers

Related Manuals for CHERUBINI MODO RX

Summary of Contents for CHERUBINI MODO RX

  • Page 1 MODO RX MOTORE TUBOLARE PER AVVOLGIBILI CON FINECORSA ELETTRONICO TUBULAR MOTOR WITH ELECTRONIC LIMIT SWITCH FOR ROLLING SHUTTERS ROHRMOTOR FÜR ROLLLADEN MIT ELEKTRONISCHER ENDLAGENEINSTELLUNG MOTEUR TUBULAIRE POUR VOLET ROULANT AVEC FINS DE COURSE ÉLECTRONIQUES MOTOR TUBULAR PARA PERSIANA CON FIN DE CARRERA ELECTRÓNICO...

  • Page 3: Table Of Contents

    Command management from white wire UP-STOP-DOWN-STOP / UP-DOWN / UP-DOWN “Dead Man” ........p. 38 EU DECLARATION OF CONFORMITY CHERUBINI S.p.A. declares that the product is in conformity with the relevant Union harmonisation legislation: Directive 2014/53/EU, Directive 2011/65/EU. The full text of the EU declaration of conformity is available upon request at the...

  • Page 4: How To Prepare The Motor

    HOW TO PREPARE THE MOTOR STOP RING NUT ADAPTOR DRIVING PULLEY STOP RING NUT 1. Insert the adaptor in the nut mating the groove with the reference notch and push till they touch. 2. Fix the driving pulley on the motor pin until the stop pin clicks.

  • Page 5: Electrical Connections

    ELECTRICAL CONNECTIONS - In order to prevent dangerous situations or malfunctioning, the electrical command elements wired to the motor must be sized according to the motor’s electrical features. - Means for disconnection must be incorporated in the fixed wiring in accordance with the national installation standards.

  • Page 6: Compatible Remote Controls / Key To Symbols

    COMPATIBLE REMOTE CONTROLS GIRO GIRO Wall stop DOWN down STOP GIRO Lux GIRO P-Lux DISPLAY GIRO Plus DISPLAY Activating the Change channel DISPLAY Change Sun sensor channel Wind sensor Wind sensor is “ON” is “ON” Sun sensor is “ON” Sun sensor is “ON” Change Activating/ Deactivating the Sun sensor Deactivating the Sun sensor...

  • Page 7: Command Sequences Example

    KEY TO SYMBOLS short motor rotation in one direction Press button A long motor rotation down in other direction double short rotation Press buttons A and B at the same time COMMAND SEQUENCES EXAMPLE Most of the command sequences have three distinct steps, at the end of which the motor indicates if the step has been concluded positively or not, by turning in different ways.
  • Page 8 FUNCTION OPEN/CLOSE PROGRAMMING REMOTE CONTROL SKIPPER PLUS - SKIPPER LUX - SKIPPER P-LUX REMOTE CONTROL POP PLUS - POP LUX - POP P-LUX To prevent accidental changes to the programming of the motor during the daily use of the remote control, the possibility of programming is disabled automatically 8 hours after sending the last sequence (A+B or B+C).

  • Page 9: Function Open/Close Programming Remote Control

    FUNCTION OPEN/CLOSE PROGRAMMING REMOTE CONTROL SKIPPER - SERIES GIRO - REMOTE CONTROL POP To prevent accidental changes to the programming of the motor during the daily use of the remote control, the possibility of programming is disabled automatically 8 hours after sending the last sequence (A+B or B+C).

  • Page 10: Setting The First Remote Control

    SETTING THE FIRST REMOTE CONTROL This operation can only be performed when the motor is new, or after a total delete of the memory. During this step, power up only one motor at time! T1: First remote control to be set T1 (2 sec) AUTOMATIC DISABLING OF THE FIRST REMOTE CONTROL SETTING FUNCTION...

  • Page 11: Example 1: Setting First The Opening Position

    EXAMPLE 1: Setting first the opening position SETTING THE OPENING POSITION If the rolling shutter is completely open, you have first to drive it down by around 20 cm. Hold the button A or C pressed and drive the rolling shutter to the opening position. With physical stops: press button A or C until the motor stops automatically.

  • Page 12: Example 2: Setting First The Closing Position

    EXAMPLE 2: Setting first the closing position SETTING THE CLOSING POSITION If the rolling shutter is completely closed, you have first to drive it up by around 20 cm. Hold the button A or C pressed and drive the rolling shutter to the closing position. With lockdown hangers: press buttons A or C until the motor stops automatically.

  • Page 13: Setting A Middle Position

    SETTING A MIDDLE POSITION This function allows the rolling shutter to be set at a favourite middle position. When this middle position is memorized, you just press the stop button for 2 seconds and automatically the motor will move the shutter to this position. To memorize the middle position, move the rolling shutter to the desired position and then hold the STOP button down (for about 2 sec) until the motor gives confirmation.

  • Page 14: Closing Force Adjustment

    CLOSING FORCE ADJUSTMENT 40 % 20 % This system is the only one of its kind and it guarantees that rolling shutters (which are equipped with lockdown hangers) remain perfectly closed without any danger of the slats suffering 10 % excessive pressure.

  • Page 15: Deleting The Limit Switch Positions

    DELETING THE LIMIT SWITCH POSITIONS DELETING THE OPENING LIMIT SWITCH To delete only the opening limit switch perform the following steps and proceed with “SETTING THE OPENING POSITION”. Tn: Already programmed remote control Tn (2 sec) DELETING THE CLOSING LIMIT SWITCH To delete only the closing limit switch perform the following steps and proceed with “SETTING THE CLOSING POSITION”.

  • Page 16: Setting Of Additional Remote Controls

    SETTING OF ADDITIONAL REMOTE CONTROLS Up to 15 remote controls can be set. Tn: Already programmed remote control Tx: Additional remote control Tx (2 sec) REMOTE CONTROL MEMORY CLEARING It is possible to delete singly all the memorized remote controls. When the last one is deleted the motor initial condition is restored.

  • Page 17: Remote Control Memory Clearing

    FULL MEMORY CLEARING This full memory clearing does not delete the setting of the limit switch. The full memory clearing can be performed in two ways: 1) WITH THE REMOTE CONTROL Tn: Already programmed remote control Tn (4 sec) 2) WITH THE WHITE WIRE Do this operation only in case of emergency, if all remote controls are no longer operating.

  • Page 18: Short-Term Setting Of A Remote Control

    SHORT-TERM SETTING OF A REMOTE CONTROL This function makes it possible to store a remote control temporarily, for example, with the purpose of setting the limit switches during assembly in the factory. A later final saving of the remote control will be possible using the appropriate command sequence (see: “SETTING THE FIRST REMOTE CONTROL”).

  • Page 19: Electric Wiring To Motor Command With 2 Independent Buttons

    ELECTRIC WIRING TO MOTOR COMMAND FOR UP-DOWN MODE (2 independent UP-DOWN buttons) To connect the switch, use only kind of switches with mechanical or electrical interlock, to prevent to press both buttons at same time. The motor automatically recognizes the switch-type (with 1 or 2 buttons) and sets the proper operational mode.

  • Page 20: Command Management From White Wire Up-Stop-Down-Stop / Up-Down / Up-Down "Dead Man

    COMMAND MANAGEMENT FROM WHITE WIRE UP-STOP-DOWN-STOP / UP-DOWN / UP-DOWN “DEAD MAN” NB: The default function provided in the motors leaving the factory is UP-STOP-DOWN- STOP for singular UP/DOWN button switch. (Not for the switch with two independent UP-DOWN buttons!) PROCEDURE TO CHANGE THE CONTROL MODE: Tn: Already programmed remote control Tn (2 sec)
  • Page 22 CHERUBINI S.p.A. Via Adige 55 25081 Bedizzole (BS) - Italy Tel. +39 030 6872.039 | Fax +39 030 6872.040 info@cherubini.it | www.cherubini.it CHERUBINI Iberia S.L. Avda. Unión Europea 11-H Apdo. 283 - P. I. El Castillo 03630 Sax Alicante - Spain Tel.
