PROGRAMMAZIONE FILARE - WIRE PROGRAMMING
DRAHTGEBUNDENE PROGRAMMIERUNG
PROGRAMMATION FILAIRE - PROGRAMACIÓN DESDE EL PULSADOR
specific for Pergola-Awnings
speziell zu Senkrechtmarkisen
ISTRUZIONI - INSTRUCTIONS - EINSTELLANLEITUNGEN
WAVE RX V25
VARIANTE 25:
specifico per tende
ad aggancio automatico
VERSION 25:
with automatic coupling
MODELL 25:
mit Einhak-System
VARIANTE 25:
spécifique pour stores
à accrochage automatique
VARIANTE 25:
específico para toldos
con enganche automático
INSTRUCTIONS - INSTRUCCIONES
I
GB
D
F
E
Advertisement
Table of Contents
Related Manuals for CHERUBINI WAVE RX V25
Summary of Contents for CHERUBINI WAVE RX V25
- Page 1 WAVE RX V25 PROGRAMMAZIONE FILARE - WIRE PROGRAMMING DRAHTGEBUNDENE PROGRAMMIERUNG PROGRAMMATION FILAIRE - PROGRAMACIÓN DESDE EL PULSADOR VARIANTE 25: specifico per tende ad aggancio automatico VERSION 25: specific for Pergola-Awnings with automatic coupling MODELL 25: speziell zu Senkrechtmarkisen mit Einhak-System VARIANTE 25: spécifique pour stores...
-
Page 3: Table Of Contents
TRANSLATION OF THE ORIGINAL INSTRUCTIONS Table of contents Safety instructions / Warnings for user ..............p. 18 Warnings for installer ..................... p. 19 How to prepare the motor ..................p. 20 Electrical connections ..................... p. 21 Choice of the programming modes ................ p. 22 Activation/deactivation of the remote control function .......... -
Page 4: Safety Instructions / Warnings For User
- The supply cord of this motor can be replaced only by the same type of cable supplied by Cherubini S.p.A. - The acoustic emission level of Cherubini S.p.A. motors is lower than 70dBA: LpA < 70dB(A). - The choice of the motor, based on its application requirements, shall be compatible with the data written on the motor label. -
Page 5: Warnings For Installer
- If the motor is used to move sun awnings, keep a safety horizontal distance of at least 40 cm between the fully opened awning and any permanent object. - If the supply cord is damaged, it must be replaced by Cherubini Service in order to prevent any risk. -
Page 6: How To Prepare The Motor
HOW TO PREPARE THE MOTOR STOP RING NUT ADAPTOR DRIVING PULLEY STOP RING NUT 1. Insert the adaptor in the stop ring nut mating the groove with the reference notch and push till they touch. 2. Fix the driving pulley on the motor pin until the stop pin clicks. -
Page 7: Electrical Connections
ELECTRICAL CONNECTIONS - In order to prevent dangerous situations or malfunctioning, the electrical command elements wired to the motor must be sized according to the motor’s electrical features. - Means for disconnection must be incorporated in the fixed wiring in accordance with the national installation standards. -
Page 8: Choice Of The Programming Modes
CHOICE OF THE PROGRAMMING MODES: RADIO - WHITE WIRE - WHITE WIRE with the radio function active he Wave RX motor may be programmed using 3 modes: - RADIO PROGRAMMING: Once the programming has been completed the motor enables use either by white-wire, by radio, or using both modes (radio/wire). - WHITE WIRE PROGRAMMING: ·... -
Page 9: Key To Symbols
KEY TO SYMBOLS Press the UP- Press the button DOWN-button DOWN down DOWN DOWN short motor rotation in one direction Press the buttons quickly according to the sequence indicated long motor rotation in DOWN DOWN other direction Press the buttons quickly according to the sequence indicated. The motor will carry out a movement to confirm your settings. -
Page 10: Motor Programming From The White Wire
MOTOR PROGRAMMING FROM THE WHITE WIRE PLEASE NOTE. If the motor is programmed from the white wire without first having memorised at least one remote control, the remote function will be deactivated automatically (to reactivate it, see page 22 - ACTIVATION/DEACTIVATION OF THE REMOTE CONTROL MOTOR FUNCTION). -
Page 11: Setting The Opening Limit Switch
Bring the awning to the closing position using the UP or DOWN button. Follow the command sequence given in order to save the closing position. At the end of the sequence, the motor carries out a short “down” movement which confirms that the settings have been saved. -
Page 12: Deleting The Limit Switch Positions
DELETING THE LIMIT SWITCH POSITIONS DELETING THE CLOSING LIMIT SWITCH From the CLOSING position From the OPENING position After deleting the closing limit switch, it is possible to proceed to a new adjustment and memorization of the closing position. The motor is now running in “Dead Man” mode. To memorise a new closing position refer to the procedure “SETTING THE CLOSING LIMIT SWITCH”... -
Page 13: Total Deleting Of The Limit Switches
TOTAL DELETING OF THE LIMIT SWITCHES From the CLOSING position From the OPENING position After deletion of the limit switches the radio function automatically resets. -
Page 14: Setting/Deleting A Middle Position
SETTING/DELETING A MIDDLE POSITION SETTING THE MIDDLE POSITION From the CLOSING position From the OPENING position After the sequence the motor will go into “Dead Man” mode so as to enable the exact adjustment of the middle position desired. To memorise the position chosen, confirm with this sequence: MOVEMENT TO MIDDLE POSITION To bring the awning to the middle... -
Page 15: Adjustment Of The Coupling / Super-Sensitivity Force
70 % The Wave RX V25 motor is set in the factory with a coupling force of 20% of the nominal torque (e.g., 20% of 50 Nm = 10 Nm). Using the button switch this level can be switched... -
Page 16: Super-Sensitivity Obstacle Detection Management During Downwards Movement -Only For Motors Up To 25 Nm
SUPER-SENSITIVITY OBSTACLE DETECTION MANAGEMENT DURING DOWNWARDS MOVEMENT - only for motors up to 25 Nm- ACTIVATING THE SUPER-SENSITIVITY FUNCTION From the CLOSING position From the OPENING position DEACTIVATING THE SUPER-SENSITIVITY FUNCTION From the CLOSING position From the OPENING position The activating and deactivating sequences are the same but the motor feedback is different. -
Page 17: Eu Declaration Of Conformity
Il testo completo della dichiarazione di conformità UE è disponibile facendone richiesta sul sito: www.cherubini.it. EU DECLARATION OF CONFORMITY CHERUBINI S.p.A. declares that the product is in conformity with the relevant Union harmonisation legislation: Directive 2014/53/EU, Directive 2011/65/EU. The full text of the EU declaration of conformity is available upon request at the following website: www.cherubini.it. - Page 18 Note - Bem - Notes - Notas:...
- Page 20 CHERUBINI S.p.A. Via Adige 55 25081 Bedizzole (BS) - Italy Tel. +39 030 6872.039 | Fax +39 030 6872.040 info@cherubini.it | www.cherubini.it CHERUBINI Iberia S.L. Avda. Unión Europea 11-H Apdo. 283 - P. I. El Castillo 03630 Sax Alicante - Spain Tel.
