DPT-OA-PLATE-01
Parts List
x6
M8 x 25mm
610825
x1
Radar Plate
6x 610825
6x 60085
6x 60080
6x 60857
x6
M8 Nyloc nut
60080
x6
M8 Nut Cap
60857
30-10-17 Issue 1
x6
M8 washer
60085
Installation Instructions
Dual PowerTower®
Tools Required
8-10mm Flat Screwdriver
13mm Spanner
Radar Plate
®
Advertisement
Related Manuals for Scanstrut DPT-OA-PLATE-01
Summary of Contents for Scanstrut DPT-OA-PLATE-01
- Page 1 Installation Instructions 30-10-17 Issue 1 DPT-OA-PLATE-01 Dual PowerTower® Tools Required Parts List M8 x 25mm M8 Nyloc nut M8 washer 8-10mm Flat Screwdriver 13mm Spanner 610825 60080 60085 Radar Plate M8 Nut Cap 60857 6x 610825 Radar Plate 6x 60085...
- Page 2 IMPORTANT PowerTowers are only compatible with marine electronics devices as stated in the latest Scanstrut Product Guide – subject to change without prior notice. Use of the Power Towers with unapproved products, or overloading, invalidates any product warranty. Scanstrut does not supply fastenings to fix this product to the chosen surface. Please choose suitable fastenings for this purpose.
