Removing the Stand and Mounting the Monitor

Refer to the table below for the standard dimensions for mounting kits.
NOTE: For use only with a UL certified mounting kit/bracket. To obtain a wall
mounting kit or height adjustment base, contact ViewSonic® or your
local dealer.
Maximum Hole pattern
Loading
14 kg 100 x 100 mm
NOTE:
Mounting kits are sold separately.
1. Turn off the monitor and disconnect all cables.
2. Place the monitor on a flat, stable surface with the screen facing down.
3. Remove the stand.
Interface Pad
(W x H) (W x H x D)
Pad Hole
N/A Ø 5 mm
Front
Screw Screw
Specification Quantity
M4 x 10 mm 4 screws
