INSTALLTION DRAWINGS
1.
Connect the power cord correctly as shown.
2.
Press the POWER switch of your LCD V to switch on the LCD TV. The power indicator on the front panel lights up
in Green
To ensure good picture and sound, TV antenna system needs to be installed. The antenna system as Shown above
can be sourced from TV equipment shops, which will provide service for correct installation and connection. After
installation, insert the 75-ohmantenna plug into the antenna jack as shown above.
VHF ANTENNA
OUTDOOR
ANTENNA
AMPLIFIER
INDOOR
ANTENNA
AMPLIFIER
POWER PLUG
OF ANTENNA
AMPLIFIER
Power Cord Connection
Antennas Connection
VHF ANTENNA
7
PC
YPb Pr/S- Video
RF
AUDI O
Au dio
75 OHM
ANTENNA
PLUG
