Summary of Contents for SWEEX TV024
-
Page 1: Table Of Contents
SCART Connection INSTALLTION YPbPr Connection DRAWINGS S-Video Connection VGA(PC) Connection HDMI Connection Remote control instructions in TV mode Remote control instructions in TELETEXT mode REMOTE CONTROL Remote control instructions in DVD mode Remote control setup First Time Installation TV Information... - Page 2 Basic operation MP3/JPEG Playback Function Settings DVD Function General setup DVD OPERATION System Setup Language Setup Audio Setup Digital Setup TROUBLESHOOTING AND ADVICE SPECIFICATIONS...
-
Page 3: Preface
1 PREFACE Thank you for buying this TV ! Please read this manual thoroughly before operating the TV. Make sure the TV was not damaged in transit. Should the TV is damaged, do no install it and contact your dealer. Check that you have all the accessories according to the model. - Page 4 TV. Only clean the TV with a soft and dry cloth. In case of troubleshooting, do not use spare parts other than those suggested by the manufacturer. Using inadequate spare parts can lead to electric shocks, short-circuits fire or other incidents.
-
Page 5: In The Carton
3 IN THE CARTON -/-- LCD TV SET Remote Control 2 " LCD 2 " LCD with with Combo Combo 1.5V Model : L2301A USER'S MANUAL Read this manual carefully and retain for future reference User Manual AAA Batteries... -
Page 6: Front&Back
7. Press "POWER" button to turn standby mode on or off; POWER INDICATOR :show blue in standby mode, light off when your TV is switch on or power is cut off. . REMOTE SENSOR: infrared sensor for the remote control. -
Page 7: Connections
5 INSTALLTION DRAWINGS Power Cord Connection 1. Connect the power cord correctly as shown. 2. Press the POWER switch of your LCD V to switch on the LCD TV. The power indicator on the front panel lights up in Blue Antennas... -
Page 8: Ypbpr Connection
DVD or VCR to the Audio input jacks on the set using the RCA cable. Match the jacks colors Y is green Pb is blue Pr is red Audio left is white and Audio right in red Select YPbPr input source with using the SOURCE button. -
Page 9: S-Video Connection
VCR to the video input. Connect the Audio output of the DVD or VCR to the Audio input jacks on the set using the RCA cable. Select S-VIDEO input source with using the SOURCE button . -
Page 10: Hdmi Connection
HDMI Connection HDMI Cable TV Back DVD or VCR Back DVD or VCR Connect HDMI output of the DVD to the HDMI input jack on the set. Select the HDMI input source with SOURCE button. -
Page 11: Remote Control
Remote control instructions in TV mode POWER Turn the LCD TV ON or OFF. MUTE Press to mute the sound. Press again or press V+ to un-mute the TV. SOURCE Press to cycle through the input source in following: SCART... -
Page 12: Remote Control Instructions In Teletext Mode
To display subtitle. HOLD Freeze the current page. SIZE Change the picture size REVEAL Reveal or hide the hidden words. TV and TXT pictures are mixed together in transparent background. INDEX Request index page when index link is valid. SUBPAGE TELETEXT Subpage. -
Page 13: Remote Control Instructions In Dvd Mode
PROGRAM Program a disc playing in a desired sequence. GOTO It is possible to get access to any point on the directly using the "GOTO" menu. Press GOTO to access the "GOTO" menu. THUMBSTICK( ▲/ ▼/◄ / ►/ OK ENTER ) Allows you to navigate the on-screen menus and adjust the system settings to your preference. -
Page 14: Remote Control Setup
Remote control setup 1. Open the cover; 2. AAA size batteries, When inserting the batteries, make sure correct polarities as per”+“and ”-“ marks on the batteries and within the battery compartment; 3. Replace the battery cover. To prevent battery leakage which may result in bodily injury or damage to the remote: 1. -
Page 15: Tv Operation
7.TV Operation In this manual, the OSD ( On Screen Display) may be different from your TV’s, because this is just an example for the TV operation. First Time Installation Other If this is the first time you open the TV and there is no... -
Page 16: Tv Information
SETUP menu). 6. The NICAM mode of current program. If the icon of NICAM mode is red, it means the current program supplies multi NICAM signals, and you can select it by pressing NICAM button. The NICAM modes and relative icons:... -
Page 17: Video Menu Options
NOTE: This option is invalid in PC mode, and it will be shown in gray. Tint Press ▼ / ▲ button and then use ◄ / ► to adjust the tone of colour when your system is in NTSC. Sharpness Press ◄... -
Page 18: Audio Menu Options
Select Sound Mode in SOUND menu. (Available sound mode: Peraonal, Voice, Music, Theatre.) If you change the value of Bass and Treble on the Sound menu, the sound mode will be changed to "Personal" automatically. You may select the sound mode directly by pressing SMODE button . - Page 19 1. Press the ◄ / ► button to select SETUP in the main menu. 2. Press the ▼ / ▲ button to select your option what you want to adjust in the SETUP menu. 3. Press the ◄ / ► button to adjust.
- Page 20 AFT (Auto Fine Tune) Due to weak signals or a wrong antenna configuration, some of the channels may not be tuned to the best reception condition. AFT function allows you to fine tune channel selected(the frequency of channel is around the value in Manual Search option.
- Page 21 SETUP menu of VGA input (for setting the PC picture position): SETUP menu of HDMI input (for setting the HDMI picture position): SETUP menu of YPbPr input (for setting the YPbPr picture position):...
-
Page 22: Timer Menu Options
EXIT button to exit the main menu. Sleep Timer Select the sleep time to put automatically the TV in standby mode. Timer can be selected as 0min, 15min, 30min,45min, 60min,75min,90min,105min,120min. Also you can select the sleep time by pressing SLEEP button repeatedly. - Page 23 PIN Code: PIN Code: Delete 0~9 Input ENTER Enter You need to enter the PIN code if the Child lock is set “on”, and the default PIN code is empty, you can press ENTER button directly to enter. TIPS:The superuser’s(administrator’s)password is 8329.
-
Page 24: Basic Operation
MP3 and JPEG playback function. - Using the navigation buttons enables you to check you favorite folder and playback the first file or move to the your favorite folders. NOTE: - Press ◄ ► buttons to move the highlighted files to folders, documents or mode selection. -
Page 25: Function Settings
DVD SETUP button to exit the OSD menu. System Setup TV SYSTEM - Press ► button to enter the TV SYSTEM, and then press ▲ / ▼ to select one from below: TV SYSTEM AUTO SCREEN SAVER TV TYPE NTSC... -
Page 26: Screen Saver
SCREEN SAVER If the screen saver option is on, when your DVD player is in Stop, Open, or No Disc state, or there is a frame frozen for more than 60sec, the screen saver will be displayed. This feature can protect the screen from damage. -
Page 27: Default Setting
RATING You can select the rating setting according to your preference. Rating restriction is divided into eight different category from KID SAFE to ADULT. NOTE: Only editable when password is unlocked. 1 KID SAFE TV SYSTEM SCREEN SAVER 3 PG... -
Page 28: Language Setup
Use navigation buttons to select the SUBTITLE LANG setup icon, press ENTER button to confirm. There are 6 languages for your selection Press ▲ & ▼ buttons to toggle between different languages. Press button to confirm. ENTER OSD LANGUAGE ENGLISH... -
Page 29: Audio Setup
L a n g u a g e s . Press ENTER button to confirm. DUTCH POLISH Audio Setup AUDIO setup The audio setup options are illustrated below: - Use the Up and Down arrow button to move the scroll and adjust the KEY. -
Page 30: Digital Setup
Digital Setup DYNAMIC RANGE FULL DYNAMIC RANGE - Switch the compress mode to “Audio output” to adjust the DUAL MONO compress ratio for different effects. When selected FULL, the peak signal value is smallest. When selected OFF, the peak signal value is largest.
