SWEEX TV023 - QUICK_START_GUIDE Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Contents
1
2
3
FRONT&BACK
4
5
6
7
Remote control instructions in TV mode
1
3
3
5
6
7
7
8
8
9
9
10
10
11
12
13
14
15
15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TV023 - QUICK_START_GUIDE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SWEEX TV023 - QUICK_START_GUIDE

Summary of Contents for SWEEX TV023 - QUICK_START_GUIDE

  • Page 1: Table Of Contents

    INSTALLTION S-Video Connection DRAWINGS VGA Connection HDMI Connection DVD&CI CARD Connection Remote control instructions in TV mode Remote control instructions in TELETEXT mode REMOTE CONTROL Remote control instructions in DTV mode Remote control instructions in DVD mode Remote control setup...
  • Page 2 Function menu options Program List Channel List options DTV OPERATION Favorite List options Channel Search options EPG MENU Basic operation MP3/JPEG Playback DVD Function General setup System Setup DVD OPERATION Language Setup Audio Setup Video Setup Dolby Digital Setup TROUBLESHOOTING AND ADVICE...

  • Page 3: Preface

    Thank you for buying this TV! Please read this manual thoroughly before operating the TV. Make sure the TV was not damaged in transit. Should the TV is damaged, do no install it and contact your dealer. Check that you have all the accessories according to the model.
  • Page 4 Keep the TV away from heat sources. Cleaning and maintenance Unplug the TV before cleaning it. Do not use solvent or liquid to clean the TV. Only clean the TV with a soft and dry cloth. In case of troubleshooting, do not use spare parts other than those suggested by the manufacturer.

  • Page 5: In The Carton

    IN THE CARTON -/-- LCD TV SET Remote Control GB Manual IT Manuale d’istruzioni NL Gebruikershandleiding FR Manuel d’utilisation EC Declaration of Conformity User Manual AAA Batteries...

  • Page 6: Connections Of Lcd

    FRONT&BACK CONNECTIONS OF LCD Front View Press “V+” or “V-” to increase or decrease the sound level; Press “P+” or “P-” to scan through channels; Press “MENU” to bring up the main menu to the screen; Press “SOURCE” to select the input source;...

  • Page 7: Installtion Drawings

    INSTALLTION DRAWINGS Power Cord Connection Connect the power cord correctly as shown. Press the POWER switch of your LCD V to switch on the LCD TV. The power indicator on the front panel lights up in Green Antennas Connection To ensure good picture and sound, TV antenna system needs to be installed. The antenna system as Shown above can be sourced from TV equipment shops, which will provide service for correct installation and connection.

  • Page 8: Scart Connection

    RCA cable. Match the jack colors :Y is green, Pb is blue, and Pr is red, Audio left is white and Audio right is red. Select YPbPr input source with using the SOURCE button on the remote control.

  • Page 9: S-Video Connection

    VGA Connection Connect the RGB output of the PC to the VGA jack on the set. Connect the AUDIO output of the PC to the PC AUDIO jack on the set .Select the VGA input source with using the SOURCE button on the remote control.

  • Page 10: Hdmi Connection

    HDMI Connection Connect HDMI output of the DVD to the HDMI input jack on the set. Select the HDMI Input source with SOURCE button on the remote control. HDMI Cable TV Back DVD or VCR Back DVD or VCR DVD&CI CARD Connection...

  • Page 11: Remote Control

    Remote control instructions in TV mode POWER Turn the LCD TV ON or OFF. MUTE Press to mute the sound. Press again or press V+ to un- mute the TV. SOURCE Press to cycle through the input source in following:...

  • Page 12: Remote Control Instructions In Teletext Mode

    HOLD Freeze the current page. SIZE Change the picture size. REVEAL Reveal or hide the hidden words. LANGUAGE TV and TXT pictures are mixed together in transparent background. INDEX Request index page when index link is valid. SUBPAGE TELETEXT Subpage.

  • Page 13: Remote Control Instructions In Dtv Mode

    Brings up the main DTV menu to the screen. DISPLAY Press to display the source and channel’s information. THUMBSTICK (▲/▼/◄/► / OK ENTER) Allows you to navigate the on-screen menus and adjust the system settings to your preference. P+/P- When watching a channel, changes the channel.

  • Page 14: Remote Control Instructions In Dvd Mode

    Numerical buttons for various data. PROGRAM Program a disc playing in a desired sequence. GOTO It is possible to get access to any point on the directly using the „GOTO“ menu. Press GOTO to access the „GOTO“ menu. THUMBSTICK (▲/▼/◄/►/OK ENTER) Allows you to navigate the on-screen menus and adjust the system settings to your preference.

  • Page 15: Accessories

    Remote control setup Open the cover; AAA size batteries, When inserting the batteries, make sure correct polarities as per “+”and “-” marks on the batteries and within the battery compartment; Replace the battery cover. To prevent battery leakage which may result in bodily injury or damage to the remote: Install all batteries correctly as marked on the remote control.

  • Page 16: First Time Installation

    After setting the items, select OK to fi nish the fi rst time installation, or select Cancel to exit this menu. If you cancelled the fi rst time installation, it will remind you whether to set the fi rst time installation next time.

  • Page 17: Tv Information

    The sound system of current program, could be selected in Manual Tuning menu (an option of SETUP menu). The NICAM mode of current program. If the icon of NICAM mode is red, it means the current program supplies multi NICAM signals, and you can select it by pressing NICAM button.

  • Page 18: Video Menu Options

    Select Picture Mode in PICTURE menu. (Available picture mode: Standard, Personal, Movie, Sport, Mild, Game.) If you change the value of Contrast, Brightness, Colour, Tint, Sharpness or Colour temperature on the picture menu, the picture mode will be changed to “Personal” automatically. You may select the picture mode directly by pressing PMODE button.

  • Page 19: Audio Menu Options

    Select Sound Mode in SOUND menu. (Available sound mode: Peraonal, Voice, Music, Theatre.) If you change the value of Bass and Treble on the Sound menu, the sound mode will be changed to “Personal” automatically. You may select the sound mode directly by pressing SMODE button.
  • Page 20 Press the ▼ / ▲ button to select your option what you want to adjust in the SETUP menu. Press the ◄ / ► button to adjust. When you are satisfi ed with your adjustment, press the TV MENU button to return to the previous menu or press the EXIT button to exit the main menu.
  • Page 21 AFT (Auto Fine Tune) Due to weak signals or a wrong antenna confi guration, some of the channels may not be tuned to the best reception condition. AFT function allows you to fi ne tune channel selected (the frequency of channel is around the value in Manual Search option.
  • Page 22 SETUP menu of VGA input (for setting the PC picture position): SETUP menu of HDMI input (for setting the HDMI picture position): SETUP menu of YPbPr input (for setting the YPbPr picture position):...

  • Page 23: Timer Menu Options

    Press the ▼/▲ button to select your option what you want to adjust in the FUNCTION menu. Press the ◄/► button to adjust. When you are satisfi ed with your adjustment, press the TV MENU button to return to the previous menu or press the EXIT button to exit the main menu.
  • Page 24 PIN Code: Delete 0~9 Input ENTER Enter You need to enter the PIN code if the Child lock is set “on”, and the default PIN code is empty, you can press ENTER button directly to enter. TIPS: The superuser’s (administrator’s) password 8329.
  • Page 25 Press 0~9 buttons to enter the new PIN code you want Change PIN Code Press 0~9 buttons to enter the PIN code you entered in the New PIN Code menu again to confi rm the new PIN code. First Time Installation Press ►...

  • Page 26: Program List

    Program List Channel List options Press ENTER button to open the Channel List, then Press ▼/▲ to select the channel you want to watch. Favourite List options Press FAV button to open the Favourite List, then Press ▼/▲ to select the channel you want to watch.

  • Page 27: Channel Search Options

    Press the ▼/▲ button to select your option what you want to adjust in the SETUP menu. Press the ◄/► button to adjust. When you are satisfi ed with your adjustment, press the TV MENU button to return to the previous menu or press the EXIT button to exit the main menu.

  • Page 28: Epg Menu

    This function allows you to edit the DTV programs according to your preferences, as following: Common Interface If you have inserted the CI card to the TV, you can see the information of the it. EPG Menu Press EPG button on the remote control to display the EPG menu directly as below:...

  • Page 29: Basic Operation

    Turn on the TV and press the SOURCE button and then the ▲/▼ to select DVD. Press OK to confi rm. Playing discs. Insert the disc with the label facing AWAY from you. The disc will either automatically start to play, or will display a menu. Use the navigation buttons to select the item you require and press OK.

  • Page 30: Dvd Function General Setup

    Press ▲/▼ buttons to move and highlight between different sub-menus. Press ◄/► ENTER button to enter the highlighted sub-menu. Press the DVD SETUP button to exit the OSD menu, or move the highlight to EXIT DVD SETUP then press ENTER button to exit.
  • Page 31 SCREEN SAVER If the screen saver option is on, when your DVD player is in Stop, Open, or No Disc state, or there is a frame frozen for more than 60sec, the screen saver will be displayed. This feature can protect the screen from damage.
  • Page 32 Select “ON” and the disc will resume paying from where it was stopped. Select “OFF” the disc will start playing from the start. DEFAULT SETTING Press ENTER button to restore factory default. NOTE: This can only be set if the password is locked. It will not reset the Password or Rating settings.

  • Page 33: Language Setup

    AUDIO LANGUAGE Use navigation buttons to select the AUDIO LANG setup icon, press ENTER button to confi rm. There are 7 languages for your selection. Press ▲ & ▼ buttons to toggle between different languages. Press ENTER button to confi rm.

  • Page 34: Audio Setup

    ▲ & ▼ buttons to toggle between different Languages. Press ENGLISH ENTER button to confi rm. SPANISH FRENCH ITALIAN RUSSIAN DUTCH POLISH Audio Setup AUDIO setup The audio setup options are illustrated below: Use the Up and Down arrow button to move the scroll and adjust the KEY.

  • Page 35: Dolby Digital Setup

    Audio compression setup DYNAMIC RANGE Switch the compress mode to “Audio output” to adjust the compress ratio for different effects. When selected FULL, the peak signal value is smallest. When selected OFF, the peak signal value is largest. DUAL MONO You can select four different audio output, STEREO, MONO L, MONO R, MIX MONO.

  • Page 36: Troubleshooting And Advice

    “Zip” made noise on Even if the display image is correct, the noise may come from an unsteady fi xation of the panel. TV cover No sound Make sure that you have not press the MUTE button of the panel or of the remote control.
