- Page 1 Linea LC (b) Loudspeakers for highest speech intelligibility. User Manual LC-20 (b) LC-60 (b) LC-100 (b) LC-150 (b) LC-220 (b) Please read this manual carefully before operating the equipment and keep it for the future reference.
-
Page 2: Table Of Contents
Content 1. Important safety information ......................3 1.1 Connections and cabling ....................... 4 2. Introduction ............................5 2.1 Intended readers of this manual ....................5 2.2 Scope of supply ..........................5 2.3 Unpacking the product ........................5 3. Setup and operation ..........................6 3.1 Installation and mounting ...................... -
Page 3: Important Safety Information
• Only use the recommended Fohhn accessories with this product, or other components that have been explicitly specified in this manual. •... -
Page 4: Connections And Cabling
To avoid injury, this product must be taken out of operation, appropriately marked and secured against unauthorised use if • it shows any visible signs of damage. • there is any indication of loose parts. • it does not work properly. •... -
Page 5: Introduction
2.2 Scope of supply All Fohhn products are developed by qualified engineers. During the build process, current safety regulations are always kept in mind. Each product is thoroughly tested before leaving the factory. Please examine your new product carefully for any signs of damage that may have occurred during transportation and, if necessary, inform your dealer and the transport company immediately. -
Page 6: Setup And Operation
Connections between loudspeakers and brackets All LC (b) loudspeakers are equipped with slot nuts placed in the rear T-slot at delivery. All Fohhn brackets include fastening materials for connecting them to the loudspeaker. If you want to use other screws, their strength must be at least class 8.8; this corresponds to a tensile strength of 800 N/mm²... -
Page 7: Wiring
When anchoring the system to the wall, dynamic strength caused by the falling loudspeaker must also be considered. 3.2 Wiring All loudspeakers of the LC (b) series are passive systems designed for use with external amplifiers. Two terminal connectors, supplied at delivery, are used for wiring. They are suitable for wires with a cross section of up to 2,5 mm². -
Page 8: Operating Conditions
Fohhn. Do not carry our any servicing or repair on a system other than stated above. To find a Fohhn Service centre in your area, please contact us at the address on the back page of this manual. Keep the packaging that has been supplied with this system so that, in the event of any damage, it can be returned in its original packaging. -
Page 9: Technical Data
4. Technical data... -
Page 10: Accessories
5. Accessories WS-2 WS-4 WS-5 WLX-100 WLX-200 SB-S SB-L... -
Page 11: Eg Conformity (Ce Marking)
This loudspeaker complies with the currently applicable conditions of EMC law and as such, carries the CE marking. The relevant Declarations of Confirmity are available on request from Fohhn Audio AG. 7. WEEE Directives (Disposal) Electrical and electronic components must not be disposed of in standard household waste. - Page 12 FOHHN AUDIO AG Großer Forst 15 72622 Nürtingen Germany Tel. +49 7022 93323-0 Fax +49 7022 93324-0 www.fohhn.com info@fohhn.com Fohhn on Social Media...
