- Page 1 Bed Frame Assembly Instruction Guide BARKER AND STONEHOUSE...
- Page 2 Supplied Fittings x 4 x 4 x 5 01WM-01E 2019-05-19 Please check you have the correct fittings and read through before commencing with assembly BARKER AND STONEHOUSE...
- Page 3 Please move to step 4 if you aren’t using the legs Step 1 Step 2 Screw in optional leg, positioning the screw hole on Remove small plastic foot by unscrewing the inside. Do not over tighten Step 3 x4 Screws supplied with legs Use the supplied screw to secure the leg in place, stopping it from rotating out of position ( This step doesn’t apply to cylindrical legs) BARKER AND...
- Page 4 Step 4 Place the 2 frames together and put the two flat bars on each side. Slot bolt (E) through, starting with the flat bar that has square holes. Use a flanged nut (B) and tighten up using the spanner provided. Once completed, place the metal frame to one side.
- Page 5 Step 7 Slot the frame brackets (F) onto the side rails, footend and headboard in the desired position. Ensure all brackets are set at the same height level Step 8 Place metal frame onto the brackets and secure with bolt (D), washer (C) and flanged nut (B) as shown.
