- Page 1 ASSEMBLY INSTRUCTIONS AMBLE RISING TABLE SKU: 5AMBCORNBRWN / 5AMBCORNGREY BSH-CD-6002B / BSH-CD-6002G IMPORTANT NOTICE THIS BOOKLET CONTAINS USEFUL INFORMATION ABOUT WARRANTY & CARE INSTRUCTIONS. PLEASE KEEP FOR FUTURE REFERENCE.
-
Page 2: Parts List
ASSEMBLY INSTRUCTIONS PARTS LIST Part Part Name Upper Table Base Table Top Lower Table Base Glass M6 x 40mm Screw Washer Allen Key... - Page 3 • Please only use this product for its intended purpose as outdoor furniture within a residential environment. Failure to do so will void your warranty. • Barker And Stonehouse holds no responsibility for any damages caused due to normal wear and tear, incorrect assembly, misuse and/or negligence.
- Page 4 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 1 Loosely secure the upper table base to the table top using M6 x 40mm screws, washers and the allen key. Once secure tighten all the bolts. E F G TOP TIP! Utilise the outer cardboard packaging where possible.
- Page 5 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 2 Secure the table top to the lower table base by positioning the legs onto the lower clips located on the inside of the frame and applying pressure downwards. (Two people required).
- Page 6 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 3 Secure the glass onto the table top ensuring the suction cups are flat. COMPLETE! Assembly of the table is now complete!
- Page 7 ASSEMBLY INSTRUCTIONS ADJUSTING THE RISING TABLE STEP 1 To adjust the table from the coffee table position, place your foot in the holes located either side the of table base (two people required).
- Page 8 ASSEMBLY INSTRUCTIONS OPERATING THE RISING TABLE STEP 2 Release the table top from the clips by lifting up the table top, while pushing the base down with your feet.
- Page 9 ASSEMBLY INSTRUCTIONS OPERATING THE RISING TABLE STEP 3 Move the table top 3 - 4cm to align it with the higher clips. Once aligned,gently lower the table top and press downwards to lock into place. TOP TIP! Dont forget to remove the protective film from the feet!
- Page 10 ASSEMBLY INSTRUCTIONS CARE & MAINTENANCE ADVICE Please read the below Care & Maintenance tips to help protect your garden table: • To prolong the life of the tabletop we recommend you always use place mats and coasters when putting glasses and plates onto the glass. •...
- Page 11 ASSEMBLY INSTRUCTIONS...
