- Page 1 ASSEMBLY INSTRUCTIONS RECLINING COMPACT POLPERRO CORNER SOFA & TWO BENCHES SKU: P0LPCORNBRWN / P0LPCORNGREY BSH-RCD-004B / BSH-RCD-004G IMPORTANT NOTICE THIS BOOKLET CONTAINS USEFUL INFORMATION ABOUT WARRANTY & CARE INSTRUCTIONS. PLEASE KEEP FOR FUTURE REFERENCE.
-
Page 2: Parts List
ASSEMBLY INSTRUCTIONS PARTS LIST Part Part Name Cambridge Corner Sofa Bench With Attachable Reclining Arm Cambridge Sofa Bench With Attachable Reclining Arm Left Reclining Arm Right Reclining Arm Large Tapered Cushion Small Tapered Cushion Base Cushion Back Cushion... - Page 3 ASSEMBLY INSTRUCTIONS PARTS LIST Part Part Name Bench Bench Cushion M8 x 25mm M8 x 35mm M8 x 45mm Allen Key Sofa Clip Hydraulic Pump (Attached To Benches)
-
Page 4: Safety Advice
• Please only use this product for its intended purpose as outdoor furniture within a residential environment. Failure to do so will void your warranty. • Barker And Stonehouse holds no responsibility for any damages caused due to normal wear and tear, incorrect assembly, misuse and/or negligence •... - Page 5 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 1 Slot the reclining left arm, onto the left hand sofa bench. TOP TIP Utilise the outer cardboard packaging where possible. This will protect your furniture when assembling and prevent damage.
- Page 6 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 2 Secure the reclining arm to the sofa using M8 x 25mm screw and allen key. left...
- Page 7 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 3 Secure the pump to the sofa using M8 x 35mm screw and allen key.
- Page 8 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 4 Secure the pump to the reclining arm using M8 x 45mm screw and allen key. left COMPLETE Assembly of sofa one is now complete!
- Page 9 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 5 Slot the right reclining arm, onto the corner sofa bench. TOP TIP Utilise the outer cardboard packaging where possible. This will protect your furniture when assembling and prevent damage.
- Page 10 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 6 Secure the right reclining arm to the sofa using M8 x 25mm screw and allen key.
- Page 11 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 7 Secure the pump to the sofa using M8 x 35mm screw and allen key...
- Page 12 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 8 Secure the pump to the right reclining arm using M8 x 45mm screw and allen key.
- Page 13 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 9 Secure the sofa frame using the sofa clips. Align the sofas and secure together by connecting the two inner parts of the frame. (Two people required)
- Page 14 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 10 Position the cushions onto the sofa set. Ensure the small and large tapered back cushions are placed in the correct corners of the sofa set. TOP TIP! Dont forget to remove the protective film from the feet!
- Page 15 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 11 Position the cushion onto the bench.
- Page 16 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 12 To recline the arm, position your back onto the arm. Pull the reclining leaver while moving your body backwards.
-
Page 17: Troubleshooting
ASSEMBLY INSTRUCTIONS TROUBLESHOOTING SCAN ME! CORRECT MECHANISM SPACING The correct placement of the reclining mechanism should look similar to this illustration. This mechanism is located under the chair and can be adjusted. INCORRECT MECHANISM SPACING In this illustration, the screw is too far through. -
Page 18: Care And Maintenance
ASSEMBLY INSTRUCTIONS CARE & MAINTENANCE Our range of Rattan Furniture is designed for continual outdoor use. The aluminium frame and weatherproof synthetic weave ensures that you can leave it outside all year round (excluding cushions). CUSHION CARE Whilst the cushions are showerproof, it is advised not to leave them out in the rain as this can make them dirty. - Page 19 ASSEMBLY INSTRUCTIONS...
