- Page 1 ASSEMBLY INSTRUCTIONS TIVERTON 1.3M ROUND DINING TABLE SKU: T1VEDINIBULK IMPORTANT NOTICE THIS BOOKLET CONTAINS USEFUL INFORMATION ABOUT WARRANTY & CARE INSTRUCTIONS. PLEASE KEEP FOR FUTURE REFERENCE.
-
Page 2: Parts List
ASSEMBLY INSTRUCTIONS PARTS LIST Part Part Name Table Top Glass Leg Support Parasol Ring, Reducer & Cap M6 x 25mm Screw M6 x 15mm Screw Washer Allen Key... - Page 3 • Please only use this product for its intended purpose as outdoor furniture within a residential environment. Failure to do so will void your warranty. • Barker And Stonehouse holds no responsibility for any damages caused due to normal wear and tear, incorrect assembly, misuse and/or negligence.
- Page 4 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 1 Loosely secure the leg onto the table top using the M6 x 15mm screws and washers. Do not tighten any screws at this step. TOP TIP! Utilise the outer cardboard packaging where possible. This will protect your table when assembling and prevent damage.
- Page 5 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 2 Loosely secure the second leg onto the table top using the M6 x 15mm screws and washers. Do not tighten any screws at this step.
- Page 6 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 3 Loosely secure the leg support to the inside of the legs using the M6 x 25mm screws and washers. Do not tighten any screws at this step. H F I...
- Page 7 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 4 Loosely secure the leg support to the inside of the legs using the M6 x 25mm screws and washers. ITS TIME! Tighten all the screws with the provided Allen key H F I...
- Page 8 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 5 Turn the table over. Add the glass to the table top ensuring the suction rings are flat. SAFETY WARNING! Always lift and secure the glass with two people.
- Page 9 ASSEMBLY INSTRUCTIONS ASSEMBLY STEP 6 Position the parasol ring into the centre of the table. Remove the ring reducers to accommodate the size of your parasol pole. If you are not using a parasol, cover the parasol ring with the blanket plate. Blanket Plate Up to 38mm Parasol...
- Page 10 ASSEMBLY INSTRUCTIONS CARE & MAINTENANCE ADVICE Please read the below Care & Maintenance tips to help protect your garden table: • To prolong the life of the tabletop we recommend you always use place mats and coasters when putting glasses and plates onto the glass. •...
- Page 11 ASSEMBLY INSTRUCTIONS...
