- Page 1 ® TRC1600 E N E R G Y R E C O V E R Y V E N T I L A T O R Ins ta llation, Op era tion & M ain ten ance M a nua l S&P USA Ventilation Systems, LLC...
- Page 2 TRC1600 ABOUT S&P USA VENTILATION SYSTEMS TABLE OF CONTENTS TRC1600 info ...... 2-6 S&P USA Ventilation Systems (S&P USA) operations are based in Jacksonville, Florida. This geographically strategic location allows the shipment of products throughout the US and Canada. The Installation ......
- Page 3 TRC1600 Ventilation Type: Unit Dimensions & Weight: Static plate, heat and humidity transfer 60 3/4" L x 43" W x 35 3/4" H 406 lbs. Typical Airflow Range: 630-2,025 CFM Max. Shipping Dimensions & Weight (on AHRI 1060 Certified Core: Two L125-G5...
- Page 4 INSTALLATION TRC1600 SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL ®...
- Page 5 PLACEMENT OF THE TRC1600 PLACEMENT OF THE TRC1600 The TRC1600 is designed for installation in a sheltered location, out of the weather. The TRC1600 is designed for installation in a sheltered location, out of the weather. The preferred mounting location is sitting on a concrete floor (feet are provided on unit) or attached The preferred mounting location is sitting on a concrete floor (feet are provided on unit) or attached to a concrete wall.
- Page 6 (800) 627- 4499 support@renewaire.com Ducts connecting the TRC1600 to the outside must be insulated, with sealed vapor barrier on both inside and outside of the insulation. The exhaust outlet and fresh air inlet on the outside of the building should be at least ten feet apart to avoid cross-contamination.
- Page 7 DO NOT PLACE ANY PICK-UPS IN GARAGES, LOADING AREAS OR IN FUME HOODS! Make the ducts from the stale room air pick-ups to the TRC1600 as simple and direct as possible. DUCT FRESH AIR FROM THE TRC1600 INTO THE HEATED SPACE Supply Air from the TRC1600 often can be ducted into an existing HVAC air distribution system.
- Page 8 Follow SMACNA guidelines. RADIATED NOISE The TRC1600 is insulated with high-density fiberglass. This provides significant attenuation of radiated sound. The outlet ducts can be significant sources of radiated sound as well. The FA and EA ducts (outlet ducts) should be insulated for sound control. This insulation should start at the unit. At a minimum the first ten feet of duct should be insulated.
- Page 9 WARNING Secure the TRC1600 with straps or clamps so that it cannot fall or tip in the event of accident, structural failure or earthquake.
- Page 10 INSTALLATION TRC1600 WIRING SCHEMATICS Schematics shown are representative of standard units. See Unit Schematic label for detailed information. TRC1600 P1 SINGLE PHASE UNIT SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL ®...
- Page 11 INSTALLATION TRC1600 TRC1600 P3 THREE PHASE UNIT SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL ®...
- Page 12 INSTALLATION TRC1600 INSTALLATION INSTRUCTION LOW VOLTAGE CONTROL SYSTEM This ERV is provided with a Class II 24VAC power supply system that operates the unit’s contactors. The ERV’s 24VAC Power Supply can also be used to power the externally-installed controls system: up to 8VA of power is available.
- Page 13 INSTALLATION TRC1600 OBSERVE THESE LIMITS TO WIRE LENGTH AND GAUGE in order to ensure reliable operation of the control system. Wire Gauge Circuit Length 100' 150' 250' 400' 700' 1000' “Circuit Length” is distance from ERV to control device. CONTROL WIRING SCHEMATICS...
- Page 14 INSTALLATION TRC1600 AN EXTERNAL CONTROL USING UNIT'S UNIT INTERNAL CONTROL WIRING 24VAC POWER SUPPLY (SIMPLIFIED) 24VAC Available at Terminals 1 & 2 Unit's 24VAC Power Supply Connect Terminals 2 & 3 Isolation Relay Coil (Fresh Air) Isolation Relay Coil (Exhaust Air) Connect Terminals 4 &...
- Page 15 START-UP & OPERATION PRINCIPAL OF OPERATION The TRC1600 has one basic purpose: to exhaust air from a structure and bring in fresh air from outside, while transferring heating or cooling energy from the exhaust air to the supply air. The TRC1600 is a very simple device, and will accomplish this purpose as long as the blowers for both airstreams are able to move air through the energy-exchange core.
- Page 16 OPERATION TRC1600 MOTOR STARTERS This unit uses IEC-style motor starters to protect the motors against overload. IEC-style motor starters use overload relays to detect excessive current and interrupt the control circuit that engages the motor’s contactors. WARNING The overload relay output contacts 95 and 96 must remain in series with the low-voltage control circuit! Altering this will create a hazardous situation in which the motor is not protected against overload! Adhere to applicable local codes when adjusting the dial setting of the overload relays.
- Page 17 Pressure Ports (4) Typ . CAUTION The proper operating airflow range for this model is 630–2025 CFM. FIGURE F3 AIRFLOW DIAGRAM TRC1600 DIFFERENTIAL STATIC ACROSS CORE DSP vs. CFM 0.20 0.30 0.40 0.50 0.60 0.70 0.80...
- Page 18 OPERATION TRC1600 Pleated_Filter_PD_APR16 (2)20x20x2 MERV 8 (IOM) FILTER SPECIFICATIONS • (4) 20" x 20" x 2" (nominal) pleated filters. Actual size: 19.5" x 19.5" x 1.75" • Unit shipped with MERV-8 Filters. Minimum recommended effectiveness: MERV-6 NOTE: Pressure drop of standard filter...
- Page 19 MAINTENANCE TRC1600 SERVICE PARTS TRC1600 SERVICE PARTS SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL ®...
- Page 20 MAINTENANCE TRC1600 MAINTENANCE REQUIREMENTS WARNING Danger of injury from un-guarded drive belts in unit. Disconnect power to unit before opening door. Danger of injury if unit starts unexpectedly. Switch power off at service disconnect. Lock-out/tag-out the disconnect. TO CLEAN THE ENERGY EXCHANGE ELEMENT Vacuum the face of the energy exchange element yearly.
- Page 21 MAINTENANCE TRC1600 BLOWER INSPECTION Inspect blowers every time you change the filters. Confirm bearings are still secure to blower shaft. It should not be possible to move the blower shaft back and forth along its length. Confirm blower wheel is not rubbing against the blower inlet or housing by rotating wheel manually.
- Page 22 MAINTENANCE TRC1600 MAINTENANCE LOG ENTER DATES OF SERVICE OA FILTER RA FILTER INSPECTION/ CLEAN CLEAN INITIALS CHANGE CHANGE CLEANING CORE BLOWERS SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL ®...
- Page 23 MAINTENANCE TRC1600 MISCELLANEOUS SERVICE NOTES INITIALS DATE SERVICE SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL ®...
- Page 24 S&P USA VENTILATION SYSTEMS Enab ling the World t o Bre athe B et ter Air ® S&P USA VENTIL ATION SYSTEMS, LLC S&P CANADA VENTILATION PRODUCTS, INC. 6393 Powers Avenue 6710 Maritz Drive, Unit 7 Jacksonville, FL 32217 Mississauga, ON L5W 0A1, Canada SolerPalau-USA.com SolerPalauCanada.com 800.961.7370...
