Please read the guide in full before starting your build. If it is blatantly obvious you haven't read it
and contact us for help then don't be surprised if we tell you to read the guide again... harsh I know.
Parts List.
R1
2M2
R22
R2
220K
R23
R3
100K
R24
R4
47K
R25
R5
150R
R26
R6
15K
R27
R7
33K
R28
R8
15K
R29
R9
33K
R30
R10
33K
R31
R11
10K
R32
R12
10K
R33
R13
10K
R34
R14
10K
R35
R15
10K
R36
R16
20K
R37
R17
10K
R38
R18
10K
R39
R19
1K
R40
R20
15K
R41
R21
15K
www.Jedspeds.co.uk
Toy Boy Delay Kit
1M
C1
100N
33K
C2
27P
24K
C3
1U
470R
C4
2N7
15K
C5
2N7
15K
C6
220N
15K
C7
2N7
39K
C8
1N
1K
C9
1N
1K
C10
100N
100K
C11
100N
100K
C12
15N
1M
C13
4N7
22K
C14
10N
120K
C15
1U
220K
C16
2N7
1K5
C17
2N7
10K
C18
4U7
10K
C19
47N
100R
C20
2N7
C21
2N7
C22
4U7
BLEND
C23
1U
DELAY
C24
47N
DEPTH
C25
470N
FCBK
C26
1U
LEVEL
C27
10U
RATE
C28
2U2
CH/VBE
C29
2U2
D1
C30
470N
D2
C31
10U
REG1
C32
100N
IC1, 3 , 4
C33
47U
IC2
C34
100N
T1
C35
100N
C36
100U
C37
100N
C38
10U
C39
10U
10KB
50KB
100KB
10KA
1MA
1MB
SPDT ON ON
4001
3MM LED GREEN
LM7805
TL072 / 4558
PT2399
50K
Advertisement
Related Manuals for Jeds Peds Toy Boy Delay Kit
Summary of Contents for Jeds Peds Toy Boy Delay Kit
- Page 1 Toy Boy Delay Kit Please read the guide in full before starting your build. If it is blatantly obvious you haven’t read it and contact us for help then don’t be surprised if we tell you to read the guide again… harsh I know.
- Page 2 Kit Specific Notes • The trimmer is there to set the delay output before it hits the blend pot. Set this to tase. • The 3mm on board LED is there to reduce distortion on the PT2399. It may flicker, but it barely illuminates.
- Page 3 Some of our PCBs are now designed to use right angled mount pcb potentiometers. They mount from the rear as indicated by the pcb. We will provide right angled pots as stocked, this means that you may receive a “normal” pot on occasion and you will have to wire it. It’s not that inconvenient now is it.
- Page 4 Hooking up the Jacks Our kits come with mono jacks. They have two connections, a positive or the tip connection. And a negative, or sleeve connection. The tip connections will connect to the 3PDT as shown later in the guide unless there are instructions otherwise.
- Page 5 isn’t working the first thing I will ask is… “did it work without the switch?”, so make sure you follow this step. If your PCB is working you are ready to connect the board to the footswitch! Follow the next stages meticulously and all being well by the end of it you will have a lovely finished pedal! The next step involves undoing the tip wires from the PCB as they will now move to the 3PDT.
- Page 6 The 2k2 resistor can be any value up to 4k7. You will have a spare in the kit to use. Good luck and happy soldering! PCB Design Notes 1. All PCBs are designed by ourselves, and tested before sale.
- Page 7 2. Box caps are shown with a + polarity mark on the silk screen, this is irrelevant as the box caps are non-polarised so can go either way. 3. Spare ground points may be provided on the PCB layout, use them if you wish but there is no requirement to.
