Summary of Contents for Sonodyne ALAAP II
- Page 2 INTRODUCTION page 1 SAFETY INSTRUCTIONS page 1 UNPACKING page 1 CONTROLS & SWITCHES- REAR page 2 ~ 3 CONTROLS & SWITCHES- TOP page 4 ~ 5 OPERATIONS page 6 ~ 7 DUET MODE page 8 TROUBLESHOOTING page 9 SPECIFICATIONS - ALAAP page 10 SPECIFICATIONS - BANDISH page 11...
-
Page 3: Important Safety Instructions
INTRODUCTION Alaap , Bandish and Malhar are powered stereo speakers with digital connectivity. They have Bluetooth, optical and USB inputs plus a stereo line level input. The supplied remote control features power, volume, input selection, mute as well as play/pause, previous and next functions of the USB player. A 5V DC USB socket allows charging of smartphone while streaming music. - Page 4 1 2 3 1 2 3 1 2 3 • page 2...
- Page 5 1. OPTICAL INPUT –Connect the optical output of your CD/DVD player or set-top box or other audio source to this socket using an optical cable, for playing the audio output of the source device. 2. AUX INPUT - This is a line level stereo analog input via 3.5mm socket. You can connect the analog audio output of any audio source to these sockets.
- Page 6 • page 4...
- Page 7 1. STANDBY POWER switch and indicator - When power is applied to the unit and the power switch on rear is switched on, this indicator will glow red in colour. This indicates that the unit is in standby mode. Pressing the switch will switch on the unit, and the indicator will turn off.
- Page 8 • page 6...
- Page 9 1. Your remote control unit comes with battery fitted, but there is an insulating sticker to prevent it from making connections and getting drained. Open the battery compartment on the rear of the remote control by turning it anticlockwise, with a coin.
- Page 10 Link two Alaap / Bandish / Malhar speakers using this mode to cater to a wider area Can work with any of these combinations • Alaap + Alaap • Bandish + Bandish • Malhar + Malhar STEP 1 Power ( ) on unit 1 and unit 2 (Turn system on with the rocker type power switch at rear.
- Page 11 SYMPTOM SOLUTION No power on system Please check: • Alaap /Bandish / Malhar is connected to mains socket • Power switch (at rear) is turned ON • Please check the fuse at rear. If blown, replace with supplied spare fuse No audio in BT mode •...
-
Page 12: Remote Control
DESCRIPTION Powered table top stereo speaker ENCLOSURE ENCLOSURE TYPE Bass reflex, with dual passive radiator 2 x 3” woofer TRANSDUCER 2 x 1/2” Neodymium magnet silk-dome tweeter COMPLEMENTS 2 x 3” passive radiator INPUTS AUX (stereo unbalanced input ) ANALOG DIGITAL Optical, USB Audio, Bluetooth 5.0 Standby power... - Page 13 Powered table top stereo speaker DESCRIPTION ENCLOSURE ENCLOSURE TYPE Bass reflex, with dual passive radiator 2 x 4” woofer TRANSDUCER 2 x 1/2” Neodymium magnet silk-dome tweeter COMPLEMENTS 2 x 4” passive radiator INPUTS ANALOG AUX (stereo unbalanced input ) DIGITAL Optical, USB Audio, Bluetooth 5.0 Standby power...
- Page 14 DESCRIPTION Wireless music system ENCLOSURE ENCLOSURE TYPE Bass reflex, vented 2 x 5” Glass-fiber cone woofer TRANSDUCER 2 x 1” Neodymium magnet silk-dome tweeter COMPLEMENTS 2 x 5” Passive Radiator INPUTS AUX (stereo unbalanced input ) ANALOG DIGITAL Optical, USB Audio, Bluetooth Stereo Standby power CONTROLS AND Volume up/down and track forward/reverse for USB Audio...
- Page 15 This warranty is only given with respect to faulty workmanship and/ or materials and does not cover misuse or consequential damage. Claims under the warranty will be considered only if the product is returned to an authorised SONODYNE Service Centre directly, or through an authorized reseller.
- Page 16 If you have anything less than a 5 star experience, please contact us at response@sonodyne.com and we will make it right SONODYNE, India • H.O.: 98 NB Block E New Alipore, Kolkata 700053 sonodyneofficial +91 9830855260 sonodyneofficial 1 800 31 31 035 response@sonodyne.com...
