- Page 1 Pre-installation Guide Plate processor 85/125/150/165 IMPORTANT Please follow the instructions in this guide when preparing the installation site prior to arrival and installation of the equipment. June 14th, 2024 Edition BA, Part No 51568 English (en-us) Original version...
- Page 2 ( Blank ) Pre-installation Guide Plate processor 85/125/150/165 June, 2024...
-
Page 3: About This Manual
About this manual About this manual This manual applies to the Plate Processor Plate processor 85/125/150/165. This manual is published by: Glunz & Jensen A/S Selandia Park 1 DK-4100 Ringsted Denmark Phone: +45 57 68 81 81 E-mail: gj@glunz-jensen.com Internet: www.glunz-jensen.com Copyright ©... -
Page 4: Table Of Contents
Free space around the equipment Dimensions Water supply and drains Water supply Drains for waste chemicals Electrical requirements Main power connection Main power outlet Power cable Electrical specifications Power supply requirements Power consumption Checklist Pre-installation Guide Plate processor 85/125/150/165 June, 2024... -
Page 5: Introduction
The operator must observe and/or act according to the information in order to CAUTION avoid any mechanical or electrical damage to the equipment. The operator must observe and/or act according to the information in order to avoid any personal injury. WARNING June, 2024 Pre-installation Guide|Plate processor 85/125/150/165... - Page 6 Pre-installation Guide Plate processor 85/125/150/165 June, 2024...
-
Page 7: Transportation
1660 mm (65.3") 1660 mm (65.3") Width (W) 1856 mm (73.1") 2252 mm (88.7") 2592 mm (102.0") 2722 mm (107.2") Height (H) 1494 mm (58.8") 1557 mm (61.3") 1557 mm (61.3") 1557 mm (61.3") June, 2024 Pre-installation Guide|Plate processor 85/125/150/165... -
Page 8: Weight
Check the Tilt watch and the Shock watch label that the red mark has not appeared and compare their serial numbers with those on the box label whether they match. Handling the crate The icons on the crate indicate how to handle the crate during transport and storage: Pre-installation Guide Plate processor 85/125/150/165 June, 2024... -
Page 9: Lifting The Crate
It is only possible to lift the equipment off the pallet using a forklift truck or a pallet mover. CAUTION: Make sure to provide a forklift designed and adequate for lifting a crate of the size and weight as specified in this manual. June, 2024 Pre-installation Guide|Plate processor 85/125/150/165... -
Page 10: Required Width Of Passage And Doorways
1450 mm (45.0") (57.1") (57.1") (57.1") Less than 1150 mm 1450 mm 1450 mm 1450 mm The Service Technician has (45.0") (57.1") (57.1") (57.1") to remove panels and perhaps disassemble parts of the equipment. Pre-installation Guide Plate processor 85/125/150/165 June, 2024... -
Page 11: Installation Requirements
105 × 40 cm (41.3 × 15.7") Plate processor 125 145 × 40 cm (57.1 × 15.7") Plate processor 150 175 × 40 cm (68.9 × 15.7") Plate processor 165 190 × 40 cm (74.8 × 15.7") June, 2024 Pre-installation Guide|Plate processor 85/125/150/165... -
Page 12: Space Requirements
The recommended minimum free space around the equipment is specified in the next illustration. CAUTION: For CTP On-line, the space requirements at the equipment front has to be decided separately. Pre-installation Guide Plate processor 85/125/150/165 June, 2024... -
Page 13: Dimensions
Plate processor Plate processor Plate processor Length 1070 mm (42.1") 1410 mm (55.5") 1410 mm (55.5") 1410 mm (55.5") (L1) Length 300 mm (11.8") 400 mm (15.7") 400 mm (15.7") 1000 mm (39.4") (L2) June, 2024 Pre-installation Guide|Plate processor 85/125/150/165... - Page 14 2037 mm (80.2") (L3) Height 802 - 882 mm (31.6 - 814 - 894 mm (32.0 - 814 - 894 mm (32.0 - 814 - 894 mm (32.0 - (H1) 34.7") 35.2") 35.2") 35.2") Pre-installation Guide Plate processor 85/125/150/165 June, 2024...
-
Page 15: Water Supply And Drains
545 mm (21.5") 755 mm (29.7") 910 mm (35.8") 990 mm (39.0") Prepare the installation site for water supply and drain connections according to the illustration. Please also refer to the "Space requirements" on page 12. June, 2024 Pre-installation Guide|Plate processor 85/125/150/165... -
Page 16: Water Supply
CAUTION: When establishing a central reception systems for waste chemicals, copper or brass should not be used in the drainage system as the chemicals involved are highly corrosive. Therefore plastic or rubber is recommended. Check with the chemicals supplier for details. Pre-installation Guide Plate processor 85/125/150/165 June, 2024... -
Page 17: Electrical Requirements
When deciding what type of cable to use, also consider the chemical resistance (chemicals may leak onto cable) and the mechanical resistance (operator may step onto cable). Provide for additional cable protection, e.g. cable covers, if cable is exposed to heavier transport such as fork-lift trucks etc. June, 2024 Pre-installation Guide|Plate processor 85/125/150/165... -
Page 18: Electrical Specifications
If using automatic circuit breakers make sure that they are Type D. CAUTION: If a circuit breaker of type ELCB, RCCB, or GFCI is used where leakage to ground is detected, the trip sensitivity must be 300 mA. Pre-installation Guide Plate processor 85/125/150/165 June, 2024... -
Page 19: Power Consumption
3400 W 5700 W (19400 5700 W (19400 5700 W (19400 (±10%), max. (11600BTU) BTU) BTU) BTU) In stand-by 500 W (1710 BTU) 500 W (1710 500 W (1710 500 W (1710 BTU) BTU) BTU) June, 2024 Pre-installation Guide|Plate processor 85/125/150/165... - Page 20 Pre-installation Guide Plate processor 85/125/150/165 June, 2024...
-
Page 21: Checklist
Has the customer provided/ordered all supplies (cables, fuses, etc.) necessary to connect the equipment to the mains? Is there a house electrician available? Are there any known problems in the building where the equipment will be installed? If YES, please describe which: June, 2024 Pre-installation Guide|Plate processor 85/125/150/165... - Page 22 Is warm water for cleaning of the equipment available? Heating and ventilation Is the capacity of the air condition/ventilation system adequate with regard to the BTU as specified in "Power consumption" on page 19? Comments and questions Pre-installation Guide Plate processor 85/125/150/165 June, 2024...
