Balboa BP501 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Equipment Booklet
for
Sousou SPA
2800 Richter Ave. Suite C, Oroville, CA 95965 z
voice:
(530)534-9910
fax:
(530)534-9915 z
email:
website:
www.tiledspas.com
sales@tiledspas.com z

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BP501 and is the answer not in the manual?

Questions and answers

James McCullough
February 25, 2025

i have a no comm error on a balboa 501 spa pak

0
1 comments:
Mr. Anderson
February 25, 2025

To fix a "No COM" error on a Balboa BP501 spa pack, follow these steps:

1. Power Off the Spa – Turn off the spa using the GFCI breaker to ensure safety.
2. Locate the Control Pack – It is typically found below the topside panel of the spa.
3. Remove the Control Pack Cover – Unscrew the two top screws to access the main board.
4. Perform Board Modifications – Specific modifications may be required to resolve the error.

These steps should help troubleshoot and fix the issue.

This answer is automatically generated

0
Shawn Totmin
May 19, 2025

Can I jumper the J44 terminal? It is the little white square pegs that supply 240V one leg goes to the heating element & the other 120V goes to the spa pump. My question is can I Jump the heating circuit from pin to pin?

0

Subscribe to Our Youtube Channel

Related Manuals for Balboa BP501

Summary of Contents for Balboa BP501

  • Page 1 Equipment Booklet Sousou SPA 2800 Richter Ave. Suite C, Oroville, CA 95965 z voice: (530)534-9910 fax: (530)534-9915 z email: website: www.tiledspas.com sales@tiledspas.com z...
  • Page 2 6/17/2016 • • • Nespa Tiled Spas Revolution Control Pack Transforming the Control of Hot Tubs GFCI It is required by code to install a Ground Fault Circuit Interrupter (GFCI) in the supply power for a spa. This device will trip the breaker if there is an unsafe electrical condition caused by a malfunctioning component or even the slightest short to ground.
  • Page 3 • Wi-Fi Ready • New Features in New Enclosure • The first of a new series of systems • Press & Hold Buttons for ease of use • Based on Balboa’s most popular model’s • Higher flame retardant and impact resistant materials...
  • Page 4 Incomparable System Reliability The BP501/601 is the first of a new series based on Balboa’s most popular models, utilizing advanced technology and higher flame retardent and impact resistant materials. Wi-Fi Enabled with press and hold buttons for ease of use, meet the newly designed BP501/601.
  • Page 5 Wireless Connection Wi-Fi Module (50350) Y-Cable 4 pin (25657) BP501 or BP601 Powerful, Yet Simple Userface A sleek new topside panel includes a large easy to read back-lit LCD with simple to follow end user menus. With new press and hold button technology, setting temperature and other common tasks have been simplified. User navigation is intuitive and easier than ever, reducing customer service help calls.
  • Page 6 MANUFACTURED UNDER ONE OR MORE OF THESE PATENTS: U.S. PATENTS: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 B2, CANADIAN PATENT: 2342614, AUSTRILIAN PATENT: 2373248 OTHER PATENTS BOTH FOREIGN AND DOMESTIC APPLIED FOR AND PENDING. ALL SOFTWARE COPYRIGHT BALBOA WATER GROUP. BP501/601_813 ©2013 Balboa Water Group.
  • Page 7 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 8 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 9 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 10 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 11 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 12 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 13 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 14 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 15 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 16 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 17 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 18 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 19 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 20 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 21 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 22 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 23 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 24 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 25 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 26 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 27 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 28 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 29 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 30 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 31 Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
  • Page 32 SuperFlo ® High Performance Pump Installation User's Guide IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS SAVE THESE INSTRUCTIONS...
  • Page 33 Customer Service If you have questions about ordering Pentair Water Pool and Spa ("Pentair") replacement parts, and pool products, please use the following contact information: Customer Service (8 A.M. to 5 P.M. — Eastern and Pacific Times) Phone: (800) 831-7133 Fax: (800) 284-4151 Technical Support Sanford, North Carolina (8 A.M.

  • Page 34: Table Of Contents

    Table of Contents Important Warning and Safety Instructions ................ii Section 1: Introduction ......................1 ® SuperFlo Pump Overview..................1 General Features .....................2 Section 2: Electrical Requirements ..................3 Wiring Installation .....................3 Section 3: Maintenance .....................5 Pump Strainer Basket ....................5 Cleaning the Pump Strainer Basket .................5 Winterizing .......................7 Electric Motor Care ....................7 Section 4: Servicing ......................8...
  • Page 35 Pentair Water Pool and Spa ® PUMP WARNING AND SAFETY INSTRUCTIONS For Pool and Spa Pumps (Non SVRS Pumps) ® ® ® (Pentair Water Pool and Spa , Sta-Rite , and Pentair Pool Products IMPORTANT SAFETY INSTRUCTIONS When installing and using this electrical equipment, basic safety precautions should always be followed, include the following: READ AND FOLLOW ALL INSTRUCTIONS To reduce the risk of injury, do not permit children to use this product.
  • Page 36 ® Pentair Water Pool and Spa PUMP WARNING AND SAFETY INSTRUCTIONS For Pool and Spa Pumps (Non SVRS Pumps) ® ® ® (Pentair Water Pool and Spa , Sta-Rite , and Pentair Pool Products ® Warnings and safety instructions for Pentair Water Pool and Spa pumps and other related products are available at: http://www.pentairpool.com/pool-owner/safety-warnings/ or call (800) 831-7133 for additional free copies of these instructions.
  • Page 37 ® Pentair Water Pool and Spa PUMP WARNING AND SAFETY INSTRUCTIONS For Pool and Spa Pumps (Non SVRS Pumps) (Pentair Water Pool and Spa ® , Sta-Rite ® , and Pentair Pool Products ® THE USE OF UNAPPROVED COVERS OR ALLOWING USE OF THE POOL OR SPA WHEN COVERS ARE MISSING, CRACKED OR BROKEN CAN RESULT IN BODY OR LIMB ENTRAPMENT, HAIR ENTANGLEMENT, BODY ENTRAPMENT, EVISCERATION AND/OR DEATH.
  • Page 38 ® Pentair Water Pool and Spa PUMP WARNING AND SAFETY INSTRUCTIONS For Pool and Spa Pumps (Non SVRS Pumps) (Pentair Water Pool and Spa ® , Sta-Rite ® , and Pentair Pool Products ® The Virginia Graeme Baker (VGB) Pool and Spa Safety Act creates new requirements for owners and operators of commercial swimming pools and spas.
  • Page 39 ® Pentair Water Pool and Spa PUMP WARNING AND SAFETY INSTRUCTIONS For Pool and Spa Pumps (Non SVRS Pumps) ® ® ® (Pentair Water Pool and Spa , Sta-Rite , and Pentair Pool Products General Installation Information • All work must be performed by a qualifi ed pool professional, and must conform to all national, state, and local codes.

  • Page 40: Section 1: Introduction

    Section 1 Introduction SuperFlo High Performance Pump Overview ® The perfect choice for all types of pools, the SuperFlo was specifically designed to be your best ® choice for a variety of inground pools. Thick walled body parts, a heavy duty 56 square flange motor, and highly engineered hydraulics make this rugged and tested design perfect for any pool, spa, water feature, or fountain.

  • Page 41: General Features

    General Features • Extremely quiet operation • Unionized fittings (1.5” and 2”) for simple replacement • Cam and Ramp lid for easy cleaning and maintenance ™ • Heavy-duty, high service factor 56 square flange motor for long life • Integral volute and pot reduce hydraulic noise •...

  • Page 42: Section 2: Electrical Requirements

    Section 2 Electrical Requirements This section describes how to wire the SuperFlo pump. ® Note: Before installing this product, read and follow all warning notices and instructions on pages ii-vi. Electrical Requirements and Wiring WARNING — Risk of electrical shock or electrocution. This pool pump must be installed by a licensed or certified electrician or a qualified pool serviceman in accordance with the National Electrical Code and all applicable local codes and ordinances.
  • Page 43 Wiring Installation, (Continued). 6. Permanently ground the motor using the green ground terminal located on the inside of the motor canopy or access plate, see Figure 1. Use the correct wire size and type specified by National Electrical Code. Make sure the ground wire is connected to an electrical service ground.

  • Page 44: Section 3: Maintenance

    Section 3 Maintenance This section describes how to maintain the SuperFlo pump. ® The Pump Strainer Basket This unit, sometimes referred to as the ‘Hair and Lint Pot’, is the unit in front of the volute. Inside the chamber is the basket which must be kept clean of leaves and debris at all times. View basket through the ‘See Through Lid’...
  • Page 45 Cleaning the Pump Strainer Basket, (Continued). 9. Reinstall the lid by placing the clamp and the lid on the pot; see Figure 10. Be sure the lid O-ring is properly placed. Seat the clamp and lid then turn clockwise until the handles are horizontal;...

  • Page 46: Winterizing

    Winterizing 1. If the air temperature drops below 35° F., the water in the pump can freeze and cause damage. Freeze damage is not warrantable. 2. To prevent freeze damage follow the procedures listed below: • Shut off electrical power for the pump at the house circuit breaker. •...

  • Page 47: Section 4: Servicing

    Section 4 Servicing This section describes how to service the SuperFlo pump. ® WARNING — Risk of electrical shock or electrocution. This pool pump must be installed by a licensed or certified electrician or a qualified pool serviceman in accordance with the National Electrical Code and all applicable local codes and ordinances. Improper installation will create an electrical hazard which could result in death or serious injury to pool users, installers, or others due to electrical shock, and may also cause damage to property.

  • Page 48: Pump Reassembly/Seal Replacement

    Pump Reassembly/Seal Replacement 1. When installing the replacement seal into the seal plate, use soapy water to wet the rubber boot before pressing it into the seal plate. 2. Remount the seal plate to the motor. 3. Before installing the rotating portion of the seal on the motor shaft, wet the motor shaft with soapy water and slide the seal onto the motor shaft.

  • Page 49: Section 5: Restart Instructions

    Section 5 Restart Instructions If the SuperFlo pump is installed below the water level of the pool, close return and suction lines prior to opening ® hair and lint pot on pump. Make sure to reopen valves prior to operating. CAUTION —...

  • Page 50: Section 6: Troubleshooting

    Section 6 Troubleshooting Use the following troubleshooting information to resolve possible problems with your SuperFlo pump. ® WARNING — risk OF elecTrical shOck Or elecTrOcuTiON. Improperly installation will create an electrical hazard which could result in death or serious injury to pool users, installers, or others due to electrical shock, and may also cause damage to property.

  • Page 51: Section 7: Technical Data

    Section 7 Technical Data Illustrated Parts List 22 20 Item Part Description Item Part Description SINGLE SPEED SUPERFLO MOTORS 355621 SCREW ¾-16 X 2¼ HEX HD, 4 req. 355018S ½, ¾ HP — (Almond) 072184 WASHER 3/8 in. S/S, 4 req. 355020S 1 HP —...

  • Page 52: Pump Curves

    Pump Curve Pentair Water Pool and Spa, Inc. Pentair Water Pool and Spa, Inc. Pump Performance Curve Pump Performance Curve SuperFlo ®Series ® SuperFlo Series 3450 RPM 2 HP 2 ½ HP 1750 RPM 1 ½HP 1 HP ½, ¾ HP 1 HP 1 ½...
  • Page 53 SUPERFLO ® HIGH PERFORMANCE PUMP INSTALLATION AND USER’S GUIDE IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS SAVE THESE INSTRUCTIONS...
  • Page 54 CUSTOMER SERVICE / TECHNICAL SUPPORT If you have questions about ordering Pentair Aquatic Systems replacement parts, and pool products, please contact: Customer Service and Technical Support, USA Sanford, North Carolina (8 A.M. to 4:30 P.M. ET) (8 A.M. to 4:30 P.M. — Eastern/Pacific Times) Phone: (919) 566-8000 Phone: (800) 831-7133 Fax: (919) 566-8920...

  • Page 55: Important Pump Warning And Safety Instructions

    IMPORTANT PUMP WARNING AND SAFETY INSTRUCTIONS General Warnings IMPORTANT NOTICE • Never open the inside of the drive motor enclosure. There is a This guide provides installation and operation instructions capacitor bank that holds a 230 VAC charge even when there is no for this product.
  • Page 56 Pentair Water Pool and Spa ® IMPORTANT SAFETY INSTRUCTIONS For Installation of Electrical Controls at Equipment Pad IMPORTANT PUMP WARNING AND SAFETY INSTRUCTIONS (ON/OFF Switches, Timers and Automation Load Center) For Installation of Electrical Controls at Equipment Pad (ON/OFF Body Entrapment: When a portion of the body is held against the drain Install all electrical controls at equipment pad, such as on/off switches, timers, and control systems, etc.

  • Page 57: Pump Overview

    PUMP OVERVIEW Pump Overview General Features The perfect choice for all types of pools, the SuperFlo • Extremely quiet operation ® High Performance Pump was specifically designed to be • Unionized fittings (1.5” and 2”) for simple your best choice for a variety of inground pools. replacement Thick walled body parts, a heavy duty 56 square flange •...

  • Page 58: Installation

    INSTALLATION Only a qualified plumbing professional should install the SuperFlo High Performance Pump. Refer to “Pump ® Warning And Safety Instructions” on pages iii - iv for additional installation and safety information. Location Be sure the pump location meets the following requirements: REAR CLEARANCE Note: Do not install this pump within an outer enclosure...

  • Page 59: Electrical Wiring Installation

    RISK OF ELECTRICAL SHOCK OR ELECTROCUTION. This pump must be installed by a licensed or certified electrician or a qualified service professional in accordance with the National Electrical Code and all applicable local codes and ordinances. Improper installation will create an electrical hazard which could result in death or serious injury to users, installers, or others due to electrical shock, and may also cause damage to property.

  • Page 60: Maintenance

    MAINTENANCE DO NOT open the strainer pot if pump fails to prime or if pump has been operating without water in the strainer pot. Pumps operated in these circumstances may experience a build up of vapor pressure and may contain scalding hot water. Opening the pump may cause serious personal injury.

  • Page 61: Servicing

    SERVICING Always disconnect power to the pump at the circuit breaker and disconnect the communication cable before servicing the pump. Failure to do so could result in death or serious injury to service people, users or others due to electric shock. Read all servicing instructions before working on the pump.

  • Page 62: Pump Reassembly

    DO NOT run the pump dry. If the pump is run dry, the mechanical seal will be damaged and the pump will start leaking. If this occurs, the damaged seal must be replaced. ALWAYS maintain proper water level. If the water level falls below the suction port, the pump will draw air through the suction port, losing the prime and causing the pump to run dry, resulting in a damaged seal.

  • Page 63: Troubleshooting

    TROUBLESHOOTING Problem Possible Cause Corrective Action Pump failure. Pump will not prime - Air leak, too much air. Check suction piping and valve glands on any suction gate valves. Secure lid on pump strainer pot and be sure lid gasket is in place. Check water level to be sure skimmer is not drawing air.

  • Page 64: Replacement Parts

    REPLACEMENT PARTS SuperFlo High Performance Pump Parts List ® 22 20 Item Part Description Item Part Description SINGLE SPEED SUPERFLO MOTORS 355621 SCREW ¾-16 X 2¼ HEX HD, 4 req. ½, ¾ HP — (Almond) 355018S 072184 WASHER 3/8 in. S/S, 4 req. 355020S 1 HP —...
  • Page 65 NOTES SUPERFLO High Performance Pump Installation and User’s Guide ®...
  • Page 66 *354707* LIT PKG. P/N 354707 1620 HAWKINS AVE., SANFORD, NC 27330 • (919) 566-8000 10951 WEST LOS ANGELES AVE., MOORPARK, CA 93021 • (805) 553-5000 WWW.PENTAIRPOOL.COM All Pentair trademarks and logos are owned by Pentair or one of its global affiliates. Pentair Aquatic Systems , SuperFlo , Cam and Ramp ™...
  • Page 67 Clean & Clear Cartridge Filter Owners Manual ® IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS SAVE THESE INSTRUCTIONS Table of Contents SECTION I. FILTER INSTALLATION ....................1 SECTION II. FILTER OPERATION ..................... 2 SECTION III. TROUBLESHOOTING....................6 SECTION IV. TECHNICAL DATA .......................

  • Page 68: Filter Operation

    WARNING Risk of electrical shock or electrocution. Position the filter and High Flow™ manual air relief valve to safely direct water drainage and purged air or water. Water discharged from an improperly positioned filter or valve can create an electrical hazard that can cause severe personal injury as well as damage property. 5.
  • Page 69 A. GENERAL INFORMATION 1. This filter operates under pressure. When the lock ring is installed properly and operated without air in the water system, this filter will operate in a safe manner. 2. The maximum working pressure of this filter is 50 psi. Never subject this filter to pressure in excess of this amount - even when conducting hydrostatic pressure tests.
  • Page 70 WARNING THIS FILTER OPERATES UNDER HIGH PRESSURE. WHEN ANY PART OF THE CIRCULATING SYSTEM (e.g., LOCK RING, PUMP, FILTER, VALVES, ETC.) IS SERVICED, AIR CAN ENTER THE SYSTEM AND BECOME PRESSURIZED. PRESSURIZED AIR CAN CAUSE THE LID TO BE BLOWN OFF WHICH CAN RESULT IN SEVERE INJURY, DEATH, OR PROPERTY DAMAGE.
  • Page 71 2. Open the filter High Flow™ manual air relief valve, (and the waste drain valve, or cap, if your system has one). NOTE Special care must be taken when cleaning cartridge element used in a swimming pool or spa using Baquacil as a sanitizer.

  • Page 72: Troubleshooting

    F. CLEANING THE HIGH FLOW™ MANUAL AIR RELIEF VALVE 1. Turn the pump off and shut off any automatic controls to ensure that the system is not inadvertently started during servicing. 2. OPEN THE HIGH FLOW™ MANUAL AIR RELIEF VALVE UNTIL IT SNAPS INTO THE FULL OPEN POSITION, THEN WAIT UNTIL ALL PRESSURE IS RELIEVED.

  • Page 73: Technical Data

    SECTION IV. TECHNICAL DATA A. Filter Pressure Loss Chart B. Flow Rate Table l a i l a i PRESSURE LOSS vs FLOW t r a d i r t r a d i r . t f (1) One GPM per sq. ft. shown, recommended flow rate for residential is .5 GPM per sq. ft. (2) Commercial flow rate is a maximum of .375 GPM per sq.
