Summary of Contents for Taga Harmony Thunder Series
- Page 1 Thunder Series Active Subwoofers Instruction Manual Edition 06-19...
- Page 2 Introduction Thank you for purchasing this TAGA Harmony subwoofer. This subwoofer is a single driver and bassreflex construction with a high-current built-in amplifier. The high-power and high-current amplifier delivers deep, dynamic bass with very low noises and a perfect definition.
-
Page 3: Table Of Contents
Contents Safety Instructions Important Safety Instructions Unpacking the Subwoofer Placement Controls And Displays - Rear Panel Hooking Up The Subwoofer Operation Additional Information Kit content Notes... -
Page 4: Safety Instructions
Safety Instructions IMPORTANT READ THIS SECTION CAREFULLY BEFORE PROCEEDING! WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT REMOVE CHASSIS (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The triangle containing a lightning symbol is intended to alert the user to the presence of uninsulated dangerous voltages within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 5: Important Safety Instructions
Important Safety Instructions... -
Page 6: Unpacking The Subwoofer
Unpacking the subwoofer Place the carton with the subwoofer on the floor in the upside down position and open it from the bottom, remove the internal packaging which protects the subwoofer on the bottom. Carefully turn the carton with the subwoofer upside down. When the subwoofer is securely placed on the floor remove the carton and internal packaging - your subwoofer is ready for placement in your room. -
Page 7: Controls And Displays - Rear Panel
Controls and Displays - Rear Panel Available controls and inputs as well as their placement on the rear panel vary depending on the model. The above figure shows the Thunder SW-12 subwoofer rear panel. Rear Panel: POWER Status LED AUTO POWER Switch (ON and AUTO) PHASE Switch VOLUME Regulator CROSSOVER Regulator... -
Page 8: Hooking Up The Subwoofer
Hooking Up The Subwoofer 1. Make sure that the subwoofer is turned off (the POWER Switch is in the 0 (OFF) position and the Power Cable is removed). 2. Make sure that your audio equipment (amplifier/preamplifier/AV receiver) is turned off. 3. -
Page 9: Operation
Operation 1. Plug the Power Cable to the subwoofer and into the electrical outlet. 2. Turn on the subwoofer – press the POWER switch to 1 (ON). The POWER Status LED will be blinking for a few seconds and should turn on - otherwise the subwoofer is working in abnormal conditions –... -
Page 10: Additional Information
It is recommended to turn off (POWER 0-OFF) the subwoofer when not in use for a longer period oftime. We strongly advise to contact a professional installer or dealer in order to install TAGA Harmony products. We recommend using high quality TAGA Harmony cables and other installation accessories. Kit Content Subwoofer... -
Page 11: Notes
Notes... - Page 12 Your product is marked with the symbol as showed on the left. For EU (European Union) member users: This product has been tested and found in compliance with requirements of the European Community 2014/30/EU and 2014/35/EU directives. IMPORTANT! Your product is marked with the symbol as showed on the left. For EU (European Union) member users: According to the WEEE (Waste electrical and electronic equipment) Directive, do not dispose of this product as household waste or commercial waste.
