Sig Sauer OPMOD KILO1400BDX Operator's Manual

5x20 mm laser rangefinder with ballistic data xchange
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2.0
KILO
®
2.0
KILO1400BDX™ 5x20 mm LASER RANGEFINDER
WITH BALLISTIC DATA XCHANGE™
OPERATOR'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OPMOD KILO1400BDX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sig Sauer OPMOD KILO1400BDX

Summary of Contents for Sig Sauer OPMOD KILO1400BDX

  • Page 1 KILO ® KILO1400BDX™ 5x20 mm LASER RANGEFINDER WITH BALLISTIC DATA XCHANGE™ OPERATOR’S MANUAL...

  • Page 2: Table Of Contents

    Specifications ......... . . 42 SIG SAUER Electro-Optics Infinite Guarantee™...

  • Page 3: Introduction

    ® Laser Rangefinder. The KILO1400BDX™ is part of a new, advanced family of rangefinders from SIG SAUER that features Low Energy Bluetooth with embedded Applied Ballistics Ultralight and the free downloadable SIG™ BDX App as part of SIG SAUER’s new Ballistic Data Xchange™ technology. All of SIG SAUER’s rangefinders feature the most advanced digital signal processing engine while streamlining the user interface for a no hassle, out of the box experience.

  • Page 4: Contents

    CONTENTS: • KILO1400BDX™ Digital Laser Rangefinder • CR2 Battery (1) • Premium Padded Ballistic Nylon Case • Lanyard • Quick Start Guide • Ballistic Group Card...

  • Page 5: Key Features

    KEY FEATURES: • SIG SAUER’S Patent Pending Ballistic Data Xchange™ Technology utilizes, low energy Bluetooth with embedded Applied Ballistics Ultralight and the free BDX™ App to sync custom gun profiles and environmental conditions to your KILO and pair your KILO to any BDX enabled riflescope or sight for ®...

  • Page 6: Product Identification

    PRODUCT IDENTIFICATION: A- Power / Range Button B- Eyecup / Diopter Focus Adjustment C- Mode Button D- Battery Compartment E- Lanyard Attachment Point...
  • Page 7 LIGHTWAVE™ DSP TECHNOLOGY SIG SAUER’s proprietary Lightwave DSP engine leverages HyperScan – an advanced power management technique that provides the fastest refresh rate in scan mode (4 times per second) even at distances up to a mile. Our DSP engine uses the latest generation field programmable gate array (FPGA) running sophisticated signal processing algorithms to reduce false positives while finding weak or distant targets.
  • Page 8 When combined with one of SIG SAUER’s BDX enabled riflescopes, the user ranges a target and the firing solution is instantly shared with the BDX riflescope where the holdover dot is selectively illuminated.
  • Page 9 QuickBOND™ allows you to quickly bond your KILO® to a SIERRA™ riflescope. On the SIERRA riflescope, insert the batteries and turn on to illumination setting 1. Then turn on the KILO by pressing and releasing the RANGE button. Press and hold down both the RANGE and MODE buttons for at least three seconds while looking through the KILO at the display.

  • Page 10: Operation

    GENERAL OPERATION Your rangefinder provides 4 modes of operation: AMR, LOS, ABU and Ballistic Group selection. When ABU is selected the user can pair the KILO® with a nearby smartphone where the BDX App should already be installed. The user configures a bullet profile in the app, which is actively synced with a paired rangefinder.
  • Page 11 MODES OF OPERATION - ANGLE MODIFED RANGE (AMR) AND LINE OF SIGHT (LOS) Angle modified range is the equivalent horizontal range to the target and is comparable to the “horizontal leg” of a triangle. AMR is also known as “rifleman’s rule” and uses the LOS range and angle of incline to calculate the horizontal distance the projectile travels between shooter and target.
  • Page 12 ANGLE MODIFIED RANGE Example: LOS range of 500 yards at 30’ decline is equivalent to an AMR range of 433 yards...
  • Page 13 APPLIED BALLISTICS ULTRALIGHT (ABU) Your rangefinder has an embedded ballistics solver developed by Sig Sauer, Applied Ballistics and nVisti. By pairing your KILO® with the free BDX App you can enter custom ballistics information for up to 25 bullet profiles and sync one at a time to your KILO. The active ballistic profile is now saved on your KILO, and when in ABU mode, will provide an accurate ballistic solution out to 800 yards maximum.
  • Page 14 Example: LOS range = 568.6 yards with 0.308 Barnes Elevation adjustment = 18.19 MOA Up Windage adjustment = 7.59 MOA Right...
  • Page 15 LIQUID CRYSTAL DISPLAY (LCD) The KILO1400BDX™ rangefinder features a High-Transmittance LCD for superior low-light performance. A – Circle center aiming feature B – Holdover Directional indicators (Up, Down, Left or Right) C – Target Selection: BEST or LAST target D – Low Energy Bluetooth indicator (on with ABU) E –...
  • Page 17 WARNING Safety and Operation Procedures The KILO® is classified as a Class 1M product. • Do not press the RANGE button while aiming at the human eye or while looking into the transmitting optics on the objective side. • Do not leave the KILO within reach of small children. •...
  • Page 18 OPERATION The KILO1400BDX™ is designed to get you up and running without the typical complexity of buried menus and programming modes. The rangefinders come out of box in the following configuration and can also be configured with the free BDX App: (a) Angle Modified Range (equivalent horizontal range) (b) Best Target (rangefinder returns the best or most likely target, not the first or last) (c) Units of Measure in Yards...
  • Page 19 SET UP Installing the Battery Remove the battery cap by turning the cap in a counter-clockwise direction. Insert (1) CR2 Primary Lithium battery (-) terminal side first. The (+) terminal should be facing out. Place the cap onto the (+) battery terminal and reinstall the battery cap by turning the cap in the clockwise direction.
  • Page 20 After installation of the battery and depressing the RANGE button, the status of the rangefinder is displayed: Installing the Lanyard Install the lanyard loop through the lanyard attachment point. Pass the lanyard back through the loop for secure attachment.
  • Page 21 DIOPTER ADJUSTMENT The diopter or focus adjustment is integral to the eyecup. The focus adjustment is used to bring the display into sharp focus along with the target image. The diopter adjustment can turn clockwise or counter-clockwise depending upon the user’s prescription. The eye relief can be adjusted by rolling the rubber eyecup over for users that may be wearing glasses.

  • Page 22: Display Information

    DISPLAY INFORMATION The display shows you the center aiming circle, the unit of measure (Y), Angle Modified Range mode (AMR) and the remaining battery status. The display will remain active for up to 30 seconds, or whatever timeout has been set within in the SIG BDX App. You can then press the RANGE button to determine range to target.

  • Page 23: Changing Modes Of Operation

    HyperScan MODE While the rangefinders support single button push ranging operation, it is highly recommended that you push and hold the RANGE button down to activate HyperScan mode. This mode allows you to scan targets at 4X/second which significantly improves ranging performance at extreme distances. As the ranging distances are updated very quickly in HyperScan mode, once you release the RANGE button the last acquired distance will be displayed.

  • Page 24: Programming Sequence

    RANGEFINDER CONFIGURATION – PROGRAMMING SEQUENCE Note – the rangefinder can more easily be programmed and configured by using the free Sig BDX App. 1. Mode Selection (AMR, LOS or ABU) To enter programming mode, press and release the RANGE button to wakeup the rangefinder. Once the display is visible, press and hold the MODE button for 2 seconds –...
  • Page 25 2. Target Selection (BEST or LAST) BEST or LAST should be flashing (BEST is the default setting). You can toggle between BEST or LAST by pressing and releasing the RANGE button. Confirm your selection by pressing and releasing the MODE button which will save your setting and index to the next setting for configuration. If you do not press and release the MODE button the rangefinder will save your selection and turn off.
  • Page 26 the RANGE button. Confirm your selection by pressing and releasing the MODE button which will save your setting and index to the next setting for configuration. If you do not press and release the MODE button the rangefinder will save your selection and turn off. The programming sequence for selecting a custom ballistic profile or ballistic group is grP1 >...
  • Page 27 DIGITAL BALLISTICS XCHANGE – DOWNLOADING AND CONFIGURING THE FREE BDX APP In this section you will download the BDX App, pair the App with your KILO® and create a custom bullet profile. 1. Turn Bluetooth on Check in Settings on your Android or iOS device to make sure that Bluetooth is on. If Bluetooth is off, switch it on.
  • Page 28 2. Download the BDX® App from the App Store / Google Play Store Go to the App Store or the Google Play store and download the SIG SAUER BDX App. Search for the word SIG SAUER or BDX.
  • Page 29 3. Launch the free SIG SAUER BDX® App and Pair with your KILO® (Enter your PIN code) On your smartphone, open the BDX App, click on PAIRING, turn on your KILO by pressing and releasing the RANGE button and then press “Scan for Devices” on the App. Your KILO should be listed below the KILO icon and “Select Device”.
  • Page 30 Make sure your KILO® stays on during the pairing process by periodically pressing and releasing the RANGE button. You will be prompted to look through your KILO for a PIN number. Type this PIN number into the open dialogue box within the App. The PIN in your KILO and the PIN entered on your smartphone must match.
  • Page 31 You may be prompted to update the software on your KILO. These software updates are mandatory and allow Sig Sauer to ensure that your BDX® App and KILO perform optimally. Most updates take less than 1 minute. Ensure that your KILO is turned on and that your smartphone has at least 25% battery life remaining before installing any software updates.
  • Page 32 4. Configure up to 25 custom bullet profiles The BDX® App allows you to create and modify up to 25 profiles. From the home screen of the App touch PROFILES. Only one profile can be active at any time and is denoted by the BDX Icon in blue to the right of the screen.
  • Page 33 After selecting a bullet manufacturer, select the actual bullet you intend to use. Once selected you will return to the Gun Profile page where you will need to click on the sync icon to the right to activate this profile. In this example the new profile is called “.223 Sierra” – be sure to activate this profile.
  • Page 34 RANGEFINDER HEADS-UP DISPLAY (HUD) From the home screen of your BDX® App select RANGEFINDERS to display the HUD. The HUD displays all range, environmental and ballistic information and allows you to configure your KILO®. KILO ID and Status Grey = disconnected / Blue = connected Back to Home Screen Help and Settings menu Elevation data...
  • Page 35 KILO® SETTINGS From the Settings menu you can fully configure the following: 1. Mode of Operation (LOS, AMR or ABU) 2. Target Mode (BEST or LAST) 3. Unit of Measure (Yards or Meters) 4. Sleep Timeout (30, 60, 120 or 180 seconds) 5.
  • Page 36 TEMPERATURE AND ALTITUDE Once your KILO® is paired and actively synced with your smartphone, when you enter the RANGEFINDER HUD screen your smartphone will automatically pull the local temperature and altitude from the closest weather station. If you are not in cell range you can manually update both temperature and altitude by touching on the white numbers in each field and manually updating these environmental conditions.
  • Page 37 MUZZLE VELOCITY (MV) CALIBRATION The most important input for calculating accurate Applied Ballistics solutions is getting your MV correct. You need to either chronograph your firearm or use the embedded MV Calibration routine built into the BDX® App. To use the MV Calibration routine make sure your scope is zeroed (i.e. at 100 yards) and verify that the BDX App is showing zero holdover values at the zero distance by ranging the target at the zero range and verifying the your holds are in fact zero Use the MV Calibration routine at the...
  • Page 38 MUZZLE VELOCITY (MV) CALIBRATION (continued) Now enter the elevation offset between point of impact and point of aim and select CONFIRM. In this example the 3 shot group was 7 inches low. A new MV of 2477 fps was calculated. Select YES to confirm and this MV will now be used for ballistic solutions going forward.
  • Page 39 CONFIGURING GLOBAL SETTINGS IN THE BDX® APP From the Home Screen of the BDX App you can configure Global Settings. Any field that is in white can be changed by touching on the unit of measure and toggling between values. The help menu is available to assist you.

  • Page 40: Frequently Asked Questions (Faqs)

    KILO. Relaunch the App, turn on your KILO and repeat the Pairing instructions in this manual. Q: I can’t locate the BDX App on the Apple or Android Stores. A: Search for Sig Sauer or BDX at the store.
  • Page 41 Q: My battery drains too fast. A: Most rangefinders will provide over 4000 individual range calculations using a fresh CR2 primary lithium battery. Your KILO® exceeds this specification. When heavily using SCAN mode the battery may appear to drain faster since your KILO is ranging 4x per second in HyperScan mode. This is normal operation but you should keep a spare CR2 battery when heading out to remote locations.
  • Page 42 KILO1400BDX™ 5x20 mm SPECIFICATIONS Magnification Objective Clear Aperture 20 mm Exit Pupil 4.0 mm Eye Relief 18 mm Angular (FOV) 7.5° FOV @ 100yds 39.5 ft Laser Divergence 2.00 x 0.25 MRAD Range Response Time .25 sec Scanning Range Resolution Under 100 yds .1 yds Max Range Reflective up to 1,400 yds Trees up to 1,000 yds Deer up to 800 yds...
  • Page 43 A – 3 in / 76 mm B – 4.3 in / 109 mm C – 1.4 in / 36 mm...
  • Page 44 WARNING LASER CLASS 1M LASER PRODUCT. INVISIBLE LASER RADIATION. DO NOT VIEW DIRECTLY WITH OPTICAL INSTRUMENTS (BINOCULARS OR TELESCOPES) This product complies with IEC 60825-1: 2014-05 Ed 3.0 and complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.

  • Page 45: Specifications

    • Reorient or relocate the receiving antenna • Increase the separation between this product and the receiver • Connect the equipment to an alternative outlet or receiver • Consult a technician. Shielded interference cable must be used with the equipment in order to comply with the limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules.
  • Page 46 FCC STATEMENT: This equipment generates uses and can radiate radio This device complies with Part 15 of the FCC rules. Operation frequency energy and, if not installed and used in accordance is subject to the following two conditions: with the instructions, may cause harmful interference to radio communications.
  • Page 47 INDUSTRY CANADA: L’exploitationestautorisée aux deux conditions suivantes: This device complies with Industry Canada licence RSS • l’appareil ne doit pas produire de brouillage, et standard(s). Operation is subject to the following two • l’utilisateur de l’appareildoit accepter tout brouillage conditions: radio électrique subi, mêmesi le brouillage est susceptible d’encompromettre le fonctionnement •...

  • Page 48: Sig Sauer Electro-Optics Infinite Guarantee

    Infinite Guarantee has your back, forever. Period. We will repair or replace your SIG SAUER product in the event it becomes damaged or defective, at no charge to you. If we cannot repair your product, we will replace it with a product in perfect working order of equal or better physical condition.
  • Page 49 Excludes electronic components. SIG SAUER Electronic & Tritium Component Limited 5-Year Warranty For components not included under the SIG SAUER Infinite Guarantee™, this ®...
  • Page 50 All trademarks, service marks, trade names, trade dress, product names and logos appearing in this manual are the property of their respective owners. No trademark or service mark appearing in this manual may be used without written consent of the mark’s owner. ©2021 SIG SAUER, Inc. All rights reserved. AN ISO 9001 REGISTERED COMPANY...
