Clear Easy Fit
Baby Gate
INSTRUCTION MANUAL
IMPORTANT! READ AND FOLLOW
THESE INSTRUCTIONS
CAREFULLY AND KEEP
FOR FUTURE REFERENCE.
This product complies with safety standard EN 1930:2011 & ASTM F1004-23
73cm - 82cm
(28.8" - 32.3")
FITS OPENINGS
76cm
(30")
TALL
INSTALLATION VIDEO
Better Lives for Kids
Black #3154
White #3155
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Perma child safety 3154
Summary of Contents for Perma child safety 3154
- Page 1 INSTALLATION VIDEO Clear Easy Fit Baby Gate Better Lives for Kids INSTRUCTION MANUAL Black #3154 White #3155 73cm - 82cm 76cm (28.8” - 32.3”) (30”) FITS OPENINGS TALL IMPORTANT! READ AND FOLLOW THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE REFERENCE.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION General & Maintenance Warnings 04-05 Gate Placement 06-07 WHAT’S IN THE BOX Parts INSTALLATION Assemble & Test Fit Installation 10-11 OPERATION How to Operate Cleaning Instructions SUPPORT Warranty Certificate Warranty Card After Sales Support... - Page 3 SAFETY INFORMATION GENERAL The correct use, installation and maintenance of this product is crucial. Carefully read this instruction manual and keep in a safe place for future reference. MAINTENANCE Regularly check that the gate is functioning correctly, lubricate hinges and moving components.
-
Page 4: Warnings
WARNING INSTALLATION ALWAYS install and use gates / enclosures as directed, using all required parts. All parts should be obtained from after sales support. Barrier must be fitted between rigid surfaces such as plaster board, timber or hard wall. This product is intended for use with children from 6 to 24 months or small to medium pets from 4.5kg (10 lbs) up to 18kg (40 lbs). - Page 5 WARNING OPERATION Regularly check that the safety barrier is properly installed and secure. Before using this product, carefully inspect for any loose parts and whether any parts need to be tightened. Danger to older children if climbing over the product. Do not use the safety barrier if any components are damaged or missing.
- Page 6 SAFETY INFORMATION MOUNTINGS Gate must be installed in a structurally sound opening. Ensure mounting surface (wall, door, stair post, etc.) is strong, rigid and has an even mounting surface. If unsure, check with a qualified builder or trades person that the installation you intend is suitable and safe. NOTE: An adapter may be required to achieve an 'even' mounting surface.
- Page 7 SAFETY INFORMATION MOUNTINGS Suitable placement on stairs TOP OF STAIRS If safety barrier is used at top of the stairs, it should not be positioned below the top level. NOTE: Ensure gate is mounted minimum 25cm / 10” from top step tread. MIN 25cm / 10”...
-
Page 8: What's In The Box
WHAT’S IN THE BOX PARTS 1x Safety Gate 4x Adjuster Bolts 4x Adjuster Screws 4x Wall Cups 4x Adhesive Pads 4x Screws... -
Page 9: Installation
INSTALLATION ASSEMBLE & TEST FIT Step 1. Screw Adjuster Bolts and Adjuster Screws together (4x), then fit in the holes on the gate (2x Upper & 2x Lower). -
Page 10: Installation
INSTALLATION Step 2. Test fit gate in desired location, ensuring the bottom bar is flat on the floor and the gate is centred and plumb. Fit the Wall Cups, mark their position. INSTALL WALL CUPS Step 3. Peel & stick the Adhesive Pads to Wall Cups, then stick the Wall Cups into marked positions (4x). - Page 11 INSTALLATION ALIGN & ADJUST Step 4. Re-Install and align gate with Wall Cups. Turn & tighten the Adjuster Screws. Start with the lower portion first, then adjust the upper portion. Tighten equally until there is a 1.5mm / 1/16” gap in the lock mechanism.
-
Page 12: Operation
OPERATION HOW TO OPEN Slide Grip the Gate Panel and place thumb on the button. Slide back the button, and lift the Gate Panel upwards. Lift 90° Open gate in either direction. At 90 degrees, the gate will When released gate will swing stay open and will not close. -
Page 13: Cleaning Instructions
CLEANING INSTRUCTIONS Simply use a soft damp cloth to wipe gate, then wipe down with a clean cloth to dry. Do not use chemical or abrasive cleaners. SPARE PARTS Mounting Bolts Banister Adapter Rental Safe Wall Cups Scan the QR code to see Spare Parts or visit: permachildsafety.com... -
Page 14: Support
SUPPORT WARRANTY CERTIFICATE Congratulations! You have made an excellent choice of this quality product. Our commitment to quality also includes our service. Should you, contrary to expectations, experience defects due to manufacturing faults, we will provide you with a warranty against defects as follows: WARRANTY The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. -
Page 15: Warranty Card
SUPPORT WARRANTY CARD DETAILS: Clear Easy Fit Baby Gate PRODUCT NAME: Black #3154 / White #3155 PRODUCT NUMBER: YOUR NAME: ADDRESS: PHONE: EMAIL: DATE OF PURCHASE: LOCATION OF PURCHASE: We recommend that you keep a copy of your receipt, showing the date of purchase, with this warranty certificate and keep for your reference. - Page 16 Scan the QR code for Live Chat Support or visit: permachildsafety.com/contact-us Perma Child Safety @permachildsafety...
