CARRIER BOARD POWER AND I/O CONNECTOR
The connector on the carrier board itself is is a JST B8B-PH-SM4-TB(LF)(SN), 8-position, 2mm pitch,
male pins, shrouded. The mating connector is the JST PHR-8. The female sockets are available
plain, with leads, and in pre-manufactured ribbon cable formats.
| PHR-8 Pin | M8 Pin | Function | Color | | :-------: | :----: | :-------- | :------------- | | 1 | 2 | VIN |
Red | | 2 | 1 | CAN_P | Yellow | | 3 | 7 | CAN_N | Blue | | 4 | 6 |
CAN_5V | Orange | | 5 | 5 | TX_SCL_D8 | Brown | | 6 | 4 | RX_SDA_D9 | Green
| | 7 | 3 | A3 | White | | 8 | 8 | GND | Black |
ADDITIONAL PERIPHERALS
GNSS_LOCK
Note: While the USER button exists inside the Tracker One, the Tracker One is a sealed unit and
opening it will void the warranty and may affect certifications, thus it is not practical to use. It can
be used with the Tracker Carrier Board.
Signal
Device OS Description
THERM
A0
NTC Thermistor
USER
A1
USER button
A2
GNSS lock indicator
GPIO1
A3
GPIO on power and I/O connector
MCU TX
TX
MCU serial TX, GPIO D8, Wire3 SCL
MCU RX
RX
MCU serial RX, GPIO D9, Wire3 SDA
