POWER CONSUMPTION (TRACKER ONE ONE523 AND ONE524)
Parameter
Operating Current (uC on, peripherals and radio disabled)
Operating Current (uC on, cellular connecting to cloud)
Operating Current (uC on, cellular connected but idle)
Operating Current (uC on, cellular connected and transmitting) I
STOP mode sleep, GPIO wake-up
STOP mode sleep, analog wake-up
STOP mode sleep, RTC wake-up
STOP mode sleep, BLE wake-up, advertising
STOP mode sleep, BLE wake-up, connected
STOP mode sleep, serial wake-up
STOP mode sleep, cellular wake-up
STOP mode sleep, IMU wake-up
STOP mode sleep, CAN wake-up
STOP mode sleep, GPS wake-up
ULP mode sleep, GPIO wake-up
ULP mode sleep, analog wake-up
ULP mode sleep, RTC wake-up
ULP mode sleep, BLE wake-up, advertising
ULP mode sleep, BLE wake-up, connected
ULP mode sleep, serial wake-up
ULP mode sleep, cellular wake-up
ULP mode sleep, IMU wake-up
ULP mode sleep, CAN wake-up
ULP mode sleep, GPS wake-up
HIBERNATE mode sleep, GPIO wake-up
HIBERNATE mode sleep, analog wake-up
HIBERNATE mode sleep, external RTC wake-up
HIBERNATE mode sleep, IMU wake-up
HIBERNATE mode sleep, CAN wake-up
1
The min, and particularly peak, values may consist of very short transients. The typical (typ) values
are the best indicator of overall power consumption over time. The peak values indicate the
absolute minimum capacity of the power supply necessary, not overall consumption.
Symbol Min Typ Peak Unit
I
24.2 132 689
startup
I
51.2 112 594
cell_conn_cloud
I 50.9 60.2 197
cloud_idle
57.2 173 702
cloud_pub
I
778 1010 1390
stop_gpio
I 740 995 1390
stop_analog
I
758 993 1420
stop_intrtc
I
1050 2500
stop_ble_adv
I 521 1050 1920
stop_ble_conn
I
729 995 1390
stop_usart
I
19.2 21.5
stop_cell
I 741 1020 1460
stop_imu
I
884 1080 1490
stop_can
I
28.0 34.8 49.0
stop_gps
I 172 556
ulp_gpio
I
165 526
ulp_analog
I
164 561
ulp_intrtc
I 228 1810
ulp_ble_adv
I
231 1100
ulp_ble_conn
I
503 731 1169
ulp_usart
I 18.6 20.9 212
ulp_cell
I
194 534
imu_imu
I
45.1 247 609
can_can
I 27.4 33.9 48.0
ulp_gps
I
148 519
hib_gpio
I
141 515
hib_analog
I 140 525
hib_extrtc
I
178 544
hib_imu
I
222 608
hib_can
mA
mA
mA
mA
uA
uA
uA
uA
uA
uA
151 mA
uA
uA
mA
uA
uA
uA
uA
uA
uA
mA
uA
uA
mA
uA
uA
uA
uA
uA
